Simplicity 4562 Einrichtungshandbuch

Attachment

Illustrated

Parts List

Rev. 04/2007

500 N. Spring Street / PO Box 997

Port Washington, WI 53074-0997 USA

www.simplicitymfg.com

MANUFACTURING, INC.

. No. Descri

tion

Attachment

1694496 48" Turbo Collector Legacy XL

1734846

Part No.:

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

48" Turbo - Mounting Group ................................................................................................................................ 4

48" Turbo - Turbo Blower Assembly .................................................................................................................... 6

48" Turbo - Mounting Group

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986434D2

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694496 - 48" Turbo Collector Le

TP 400-4562-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

48" Turbo - Mounting Group

Footnotes

KNOB, Plastic1 1700669SM 1

COVER, Belt (Includes Ref. No. 3 & 6)2 1700728SM 1

POP-RIVET, 3/16 x 5/163 2828707SM 2

NUT, Push, 5/164 1933988SM 1

NUT, Hex Flange, #10-325 1928919SM 2

HINGE6 1700649SM 1

PLUG, Mower Cover7 1674020SM 1

COVER, LH Mower8 1700013SM 1

SCREW, Rd Hd Machine, #10-32 x 3/89 1922121SM 2

CAPSCREW, Hex Hd, 7/16-14 x 2-1/410 1927120SM 1

PULLEY ASSEMBLY11 1679903ASM 1

PIN, Cotter12 1918447SM 2

ROD, Pivot13 1700853SM 1

NUT, Hex, 3/8-1614 1916950SM 2

WASHER, Lock, 3/815 1916965SM 2

CAPSCREW, Hex Hd, 3/8-16 x 116 1921210SM 2

HINGE ASSEMBLY, Front, 48"17 1727403SM 1

BRACKET, LH Pivot18 1700801ASM 1

CAPSCREW, Hex Hd, 5/16-18 x 7/819 1923325SM 2

NUT, Hex, 7/16-1420 1918213SM 2

WASHER, Lock, 7/1621 1918199SM 2

BRACKET, RH Pivot22 1700802ASM 1

NUT, Hex, 5/16-1823 1917372SM 4

WASHER, Lock, 5/1624 1917356SM 4

SPRING, Torsion25 1700851SM 1

CAPSCREW, Hex Hd, 7/16-14 x 2-3/426 1926110SM 2

HINGE ASSEMBLY, Rear, 48"27 1725998ASM 1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694496 - 48" Turbo Collector Le

TP 400-4562-00-AT-SMA

48" Turbo - Turbo Blower Assembly

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986434D1

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694496 - 48" Turbo Collector Le

TP 400-4562-00-AT-SMA

PART NO. DESCRIPTIONREF NO QTY.

48" Turbo - Turbo Blower Assembly

Footnotes

PLATE, Mounting1 1727404ASM 1

CAPSCREW, Hex Hd,1/4-20 x 5/82 1921959SM 9

CAPSCREW, Hex Hd,1/4-20 x 2-1/43 1960346SM 1

STOP, Deflector4 1700936SM 1

CAPSCREW, Hex Hd, 1/4-20 x 7/85 1924009SM 1

NUT, Hex Flange Whiz Lock, 5/16-186 1927557SM 6

RETAINER, Bearing7 1665982ASM 4

BEARING8 2108202SM 2

DECAL, Danger9 1700259SM 1

HOUSING, Blower (Incl. Ref. No. 9)10 1706654SM 1

HOOK, Stone Guard11 1679900SM 1

NUT, Hex Flange Whiz Lock, 1/4-2012 1960608SM 9

NUT, Push, 5/1613 1933988SM 6

WASHER, Plain,1/214 1676435SM 1

CARRIAGE BOLT, 5/16-18 x 3/415 1931333SM 6

FAN ASSEMBLY (5 Blade)16 1706631ASM 1

KEY, Woodruff, 3/1617 2860403SM 1

CARRIAGE BOLT, 3/8-16 x 1-1/418 1960268SM 1

NUT, Hex Jam Lock, 3/8-1619 1928731SM 3

PLATE, Shroud20 1706652ASM 1

STOP, Belt21 2170397SM 1

WASHER, 5/1622 1919326SM 1

COVER, Top23 1702553SM 1

WASHER, 3/824 1924940SM 5

SETSCREW, Sqr Hd, 5/16-18 x 3/825 1960619SM 2

PULLEY, Driven26 1706634SM 1

SPACER27 1666114SM 1

CAPSCREW, Hex Hd, 3/8-16 x 1-1/228 1921969SM 1

SPRING, Extension29 1679554SM 1

PULLEY, Idler, Adjustable30 2174561SM 1

IDLER ARM ASSEMBLY31 1701827ASM 1

CAPSCREW, Hex Hd, 3/8-16 x 132 1921210SM 1

WASHER, 3/8 Special33 2157424SM 1

WASHER, Lock, 5/1634 1917356SM 1

NUT, Hex, 5/16-1835 1917372SM 1

PULLEY, Idler, Fixed36 2154534SM 1

CAPSCREW, Hex Hd, 1/4-20 x 3/437 1923341SM 2

S-HOOK39 1672689SM 1

NUT, Hex Nylon Lock, 1/4-2040 1920397SM 4

The above parts group applies to the following Mfg. Nos.:

Briggs and Stratton Yard Power Products Group

1694496 - 48" Turbo Collector Le

TP 400-4562-00-AT-SMA
