SWC-62
COMMERCIAL AIR CONDITIONERS SDV6
USER & INSTALLATION MANUAL
INSTALLATION
& OWNER’S MANUAL
Thank you very much for purchasing our product.
Before using your unit, please read this manual carefully and keep it for future reference.
Wired Controller
This manual gives detailed description of the precautions
that should be brought to your attention during operation.
In order to ensure correct service of the wired controller
please read this manual carefully before using the unit.
For convenience of future reference, keep this manual after
reading it.
CONTENTS
1
About the documentation
For the user
1.2
1.1 01
03
Wired controller: Overview
Operation
Troubleshooting
FQA
2.1
2.2
2.3
2.4
05
51
52
GENERAL SAFETY PRECAUTIONS
2 OPERATION
06
Precautions for Installation
Basic Parameters
Accessories
Installation
Engineering Menu
3.1
3.2
3.3
3.4
3.5
55
3 INSTALLATION
56
57
58
67
1 GENERAL SAFETY PRECAUTIONS
1.1 About the documentation
The original documentation is written in English. All other
languages are translations.
The precautions described in this document cover very important
topics, follow them carefully.
All activities described in the installation manual must be
performed by an authorized installer.
1.1.1 Meaning of warnings and symbols
Indicates a situation that results in death or serious injury.
DANGER: RISK OF ELECTROCUTION
Indicates a situation that could result in electrocution.
DANGER: RISK OF BURNING
Indicates a situation that could result in burning because of
extreme hot or cold temperatures.
DANGER
1
Indicates a situation that could result in death or serious
injury.
Indicates a situation that could result in minor or moderate
injury.
Indicates a situation that could result in equipment or
property damage.
Indicates useful tips or additional information.
WARNING
CAUTION
NOTE
INFORMATION
i
2
1.2 For the user
If you are not sure how to operate the unit, contact your installer.
The appliance is not intended for use by persons, including
children, with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children must be supervised
to ensure that they do not play with the product.
Do NOT rinse the unit. This may cause electric shocks or
fire.
Do NOT place any objects or equipment on top of the
unit.
Do NOT sit, climb or stand on the unit.
CAUTION
NOTE
3
Units are marked with the following symbol:
This means that electrical and electronic products may not be
mixed with unsorted household waste. Do not try to dismantle the
system yourself: the dismantling of the system, treatment of the
refrigerant, of oil and of other parts must be done by an authorized
installer and must comply with applicable legislation. Units must be
treated at a specialized treatment facility for reuse, recycling and
recovery. By ensuring this product is disposed of correctly, you will
help to prevent potential negative consequences for the
environment and human health. For more information, contact
your installer or local authority.
4
2 OPERATION
On/OffRight keyOKMenu/Back Left key
Display
2.1 Wired controller: Overview
5
2.2 Operation
1. On/Off
2. Menu/Back Press " " to enter the menu selection screen.
Press " " again to return to the main interface.
3. Left/Right
key
Press " " " " to adjust the temperature and humidity.
4. Confirmation
Press " " to wake up the screen.
Icon description
Set temperature display
Timer off Timer on
Cooling
Auto
Heating
Dry
Press " ". The interface/operation button will light up and the
device will start. Under one-to-many individual control, the
screen will not die when the power-off button is pressed.
Press " " again. The screen/operation button will be off, and
the device will shut down.
6
Indoor temp.Fan
