Sitecom WL-351 Bedienungsanleitung

WL-351

Wireless Gigabit Router 300N X3

WL-368

Wireless Gigabit Router 300N X2

(802.11bgn)

User Manual

TABLE OF CONTENTS

.....................................................................................................................1

1KEY FEATURES ................................................................................................................................... 4

2PACKAGE CONTENTS ...................................................................................................................... 5

3PRODUCT LAYOUT ............................................................................................................................ 6

4NETWORK + SYSTEM REQUIREMENTS ..................................................................................... 8

5WL-351 368 PLACEMENT ................................................................................................................. 8

6SETUP LAN, WAN ................................................................................................................................ 9

7PC NETWORK ADAPTER SETUP ................................................................................................. 10

8BRING UP THE WL-351 368 ............................................................................................................ 14

9 INITIAL SETUP WL-351 368 ........................................................................................................... 14

10 CONFIGURATION WIZARD ........................................................................................................ 23

11 WIRELESS SETTINGS ................................................................................................................... 25

12 FIREWALL SETTINGS .................................................................................................................. 36

13 ADVANCED SETTINGS ................................................................................................................ 42

14 TOOLBOX SETTINGS .................................................................................................................. 53

Introduction

Congratulations on our purchase of the WL-351/368 Wireless Gigabit Router

300N. The WL-351/368 is compliant with 802.11n and up to 6 times faster

than standard 802.11g based routers while still being compatible with

802.11g & 802.11b gadgets. The WL-351/368 is not onl a Wireless Access

Point, but also doubles as a 4-port full-duplex Gigabit switch that connects

our wired-Ethernet devices together at 10/100/1000 Mbps speeds.

At 300 Mbps wireless transmission rate, the Access Point built into the Router

uses advanced MIMO (Multi-Input, Multi-Output) technolog to transmit

multiple streams of data in a single wireless channel, giving ou seamless

access to multimedia content. The robust RF signal travels farther, eliminates

dead spots and extends the network range. For data protection and privac ,

the WL-351/368 encodes all wireless transmissions with WEP, WPA, or WPA2

encr ption.

With the inbuilt DHCP Server & powerful SPI firewall, the WL-351/368

protects our computers against intruders and most known Internet attacks

and also provides safe VPN pass-through. With the incredible speed and QoS

function of 802.11n, the WL-351/368 is ideal for media-centric applications

like streaming video, gaming, and VoIP telephon to run multiple media-

intense data streams through the network at the same time, with no

degradation in performance.

1 Key Features

Features Advantages

Incredible Data Rate up to

300Mbps*

Heavy data payloads such as

MPEG video streaming

IEEE 802.11n Compliant and

backward compatible with 802.11b/

Fully Interoperable with IEEE

802 11b / IEEE802 11g

compliant devices with legacy

protection

Four 10/100/1000 Mbps gigabit

Switch Ports (Auto-Crossover)

Scalability, extend your network

Firewall supports Virtual Server

Mapping, DMZ, IP Filter, ICMP

Blocking, SPI

Avoids the attacks of Hackers or

Viruses from Internet

Support 802.1x authenticator,

802.11i (WPA/WPA2, AES), VPN

pass-through

Provide mutual authentication

(Client and dynamic encryption

keys to enhance security

WDS (Wireless Distribution S stem) Make wireless AP and Bridge

mode simultaneously as a

wireless repeater

* Theoretical wireless signal rate based on IEEE standard of 802.11a, b, g, n chipset used. Actual

throughput ma var . Network conditions and environmental factors lower actual throughput rate.

All specifications are subject to change without notice.

2 Package Contents

Open the package carefull , and make sure that none of the items listed

below are missing. Do not discard the packing materials, in case of return;

the unit must be shipped back in its original package.

1. The WL-351/368 Router

2. A 220V~240V Power Adapter

3. A Quick Install Guide

4. A CD (User’s Manual)

5. A Warrant card

6. An UTP cable

3 Product Layout

Port Description

Power connector Connect the 12V DC adapter to this port

LAN (Yellow) Connect our PC’s or network devices to this port

WAN (Blue) Connect our ADSL/Cable modem to this port

Backlabel

The backlabel describes the IP address, login details, SSID, securit code and

WPS button functionalit .

Button Description

WPS BUTTON

Press 2 seconds for WPS mode

Press 10 seconds to reset the router

Press 15 Seconds to reset the router to factor defaults.

Network + System Requirements

To begin using the WL-351/368, make sure ou meet the following as minimum

requirements:

•PC/Notebook.

•Operating S stem – Microsoft Windows XP/2000/VISTA

•1 Free Ethernet port.

•WiFi card/USB dongle (802.11 b/g/n) – optional.

•External xDSL (ADSL) or Cable modem with an Ethernet port (RJ-45).

•PC with a Web-Browser (Internet Explorer, Safari, Firefox, Opera)

•Ethernet compatible CAT5 cables.

5 WL-351/368 Placement

You can place the WL-351/368 on a desk or other flat surface, or ou can mount

it on a wall. For optimal performance, place our Wireless Broadband Router in

the center of our office (or our home) in a location that is awa from an

potential source of interference, such as a metal wall or microwave oven. This

location must be close to a power connection and our ADSL/Cable modem.

6 Setup LAN, WAN

WAN connection:

LAN connection:

7 PC Network Adapter setup

Windows XP

•Enter [Start Menu]  select [Control panel]  select [Network].

•Select [Local Area Connection]) icon=>select [properties]
