Siyata Mobile UR7 Bedienungsanleitung
UR7
POWERFUL
SMART
CLAMSHELL
FOR A RUGGED
WORLD
User Guide
2
4G LTE
SMART RUGGED
CLAMSHELL
DEDICATED PTT
BUTTON
DUAL SPEAKER
ENSURES EXCELLENT SOUND QUALITY
QUALCOMM SNAPDRAGON 210
MSM8909, QUAD CORE, 1.2GHZ
ANDROID OS
* Additional Accessories Available
3
Thank you for purchasing UR7
The Siyata UR7 is the first LTE rugged smartphone
in a clamshell form factor. This powerful device
is based on a Qualcomm Snapdragon chipset
supporting 4G LTE.
This IP67 device boasts 4G speed, crystal clear
cellular call quality via dual speakers, dedicated PTT
and SOS buttons, touch screen and more packaged
in an ergonomic clamshell form factor making it best
in class for a rugged world.
Please read this manual and safety section to ensure
safe and pleasant use of the device.
Warranty is valid for one year with an invoice from
an authorized Siyata Mobile Inc. dealer showing the
purchase date.
If you have any questions or require support, please
contact us at: support@siyatamobile.com
For more information, please visit our website at
www.siyatamobile.com
4
Table Of Contents
1 Your UR7 ........................................................... 6
1.1 Keys and Connectors ............................................. 6
1.2 Getting started ...................................................... 8
1.3 Home screen ......................................................... 9
2 Basic Operations.............................................. 12
2.1 Making a call ....................................................... 12
2.2 Answering or rejecting a call ............................... 12
2.3 Call log................................................................. 13
3 Messaging ....................................................... 13
3.1 Write a message.................................................. 13
3.2 Edit Text............................................................... 14
4 Contacts .......................................................... 14
4.1 Search for a Contact ............................................ 14
4.2 Add a New Contact.............................................. 14
4.3 Edit a Contact ...................................................... 15
4.4 Importing, exporting and sharing contacts ......... 15
4.5 Synchronizing contacts in multiple accounts ...... 15
5 Accounts.......................................................... 16
6 Settings Menu ................................................. 16
7 Troubleshooting .............................................. 17
8 Safety use........................................................ 23
Prolonged exposure to music at full volume on the music
player may damage the listener’s hearing. Set your phone
volume safely. Use only headphones recommended by Siyata
Mobile.
5
Box Content
Your purchased UR7 device includes the following
Original items:
UR7 Device
Battery
AC adapter
Micro USB cable
User Guide
Note: We have made every effort to ensure that the
product arrives complete and in working order. If
you discover any problems with this product, please
contact the point of sale immediately.
6
1 Your UR7
1.1 Keys and Connectors
Touchscreen
Recently used
application
Call Key
Softkey
Voice mail
Change
language
Speaker
Back
End key
Navigation
keys
Home Key
Silent/
Vibration
7
Softkey Flashlight
Headset
connector
PTT key
Volume up
Volume
down
Micro USB
connector
Camera SOS key
On home screen – touch and hold on empty
place to see available options: Settings, Widgets,
Wallpapers.
Short press: Back to home screen.
Go back to the previous menu or screen.
8
1.2 Getting started
1.2.1 Set-up
Removing the back cover
Using a coin or other similar object, turn the screw
on the back cover, then pull off the cover.
Removing the battery
Remove the back cover and then remove the
battery.
Inserting and Removing the SIM cards
Please power off your phone and remove the
battery before inserting or removing the SIM cards.
Place the SIM cards with the chip facing downwards
and slide it into its housing. Make sure that it is
correctly inserted. Lock the clip over the SIM cards.
To remove the cards, release the clip and slide it out.
Installing and removing the microSD card
Insert the microSD card into the slot with the golden
contact facing downwards. To remove the card,
press and slide it out.
1.2.2 Power on / Power off the phone
Hold down key until the phone powers on.
Hold down key until the phone options appear.
Select Power Off.
9
1.3 Home screen
1.3.1 Home screen display
The home screen allows you to organize your
applications and folders on home screen itself. In
this way you can keep your most useful applications
at hand.
Your home screen provides you with up to date
information such as the weather, calendar, next
meetings, notifications, new messages, missed calls,
new mail, etc. The home screen allows you to create
shortcuts to chosen applications and folders.
You can change the home screen display by touching
the home key.
1.3.2 Using the touchscreen
Touch: To access an application, touch it with
your finger.
Touch and Hold: To enter the available options for
an item, touch and hold the item. For example,
select a contact in Contacts, touch and hold this
contact, an options list will then appear on screen.
Drag: Place your finger on the screen to drag an
object to another location.
Slide/Swipe: Slide the screen to scroll up and
down the applications, images, web pages… at
your convenience.
Flick: Similar to swiping, but flicking makes it
move faster.
10
Pinch/Spread: Place the fingers of one hand
on the screen surface and draw them apart or
together to scale an element on the screen.
Rotate: Automatically change the screen
orientation from portrait to landscape by turning
the phone sideways to have a better screen view.
1.3.3 Status bar
From the status bar you can view the time, battery
status, Network and notifications.
Cellular data Hotspot
Cast Battery
Data Saver Airplane mode
Flashlight Do not disturb
Bluetooth Auto-rotate
WLAN /
Wi-Fi Location
Notification panel
Touch and drag down the status bar to open the
notifications panel. Touch and drag up to close it.
