ZR10
2K QHD 30X HYBRID ZOOM
GIMBAL CAMERA
USER MANUAL
V1.0
July 2022
ZR10 User Manual V1.0
2
2022 SIYI Technology Copyright
Thank you for purchasing SIYI’s product.
ZR10 is an HD hybrid zoom gimbal camera completely developed by SIYI
Technology, featuring 4 mega pixels of resolution, 10X optical zoom and up to 30X
hybrid zoom, can record video at 2K resolution by TF card. ZR10’s 3-axis stabilizing
technology with FOC control help maintain an absolutely stable image during flight.
And the HDR and starlight feature can help expand drone missions to 24/7. In a
word, ZR10 is a rare and good payload for multi-rotors, VTOLs, and robotics.
To ensure you a good experience of ZR10 gimbal camera, please read this manual
carefully. If you have any issue using the product, please consult the manual or
check the online pages of ZR10 on SIYI official website (http://www.siyi.biz) or SIYI
official store (https://shop.siyi.biz/products/zr10). You can also write an email to SIYI
official A/S center (support@siyi.biz).
ZR10 User Manual V1.0
3
2022 SIYI Technology Copyright
SIYI User Group - Facebook
SIYI Official Store (https://shop.siyi.biz)
SIYI Official AliExpress Store (https://siyi.aliexpress.com)
SIYI YouTube Channel (https://www.youtube.com/c/SIYITech)
ZR10 User Manual V1.0
4
2022 SIYI Technology Copyright
CONTENT
READ TIPS.................................................................................................................................................................1
Icons.........................................................................................................................................................................1
Safety.......................................................................................................................................................................1
Storage/Carrying/Recycling..................................................................................................................................2
1 INTRODUCTION....................................................................................................................................................3
1.1 Product Features.............................................................................................................................................3
1.2 Parts..................................................................................................................................................................5
1.2.1 At a Glance...............................................................................................................................................5
1.2.2 Ports on ZR10 ..........................................................................................................................................7
1.3 Technical Specification...................................................................................................................................9
1.4 Packing List....................................................................................................................................................10
1.5 Indicator Definition ........................................................................................................................................11
2 GET READY TO USE ZR10...............................................................................................................................12
2.1 Installation......................................................................................................................................................12
3 GIMBAL CONTROL.............................................................................................................................................13
3.1 Control ZR10 Gimbal Camera from SIYI FPV App on MK15 Smart Controller...................................13
3.1.1 Preparation..............................................................................................................................................13
3.1.2 Gimbal Pitch and Yaw Rotation...........................................................................................................15
3.1.3 Zoom and Focus....................................................................................................................................15
3.1.4 Photography and Video Recording.....................................................................................................15
3.2 Control ZR10 Gimbal Camera through S.Bus / PPM Signal (Taking an Example of MK15 Smart
Controller) .............................................................................................................................................................16
3.2.1 Preparation..............................................................................................................................................16
3.2.2 Gimbal Pitch and Yaw Rotation (Taking an Example of MK15 Dials)...........................................19
3.1.3 Zoom and Focus (Taking an Example of MK15 Switches) .............................................................19
3.1.4 Photography and Video Recording (Taking an Example of MK15 Buttons).................................20
3.3 UART / UDP Control.....................................................................................................................................21
4 VIDEO OUTPUT...................................................................................................................................................22
4.1 Output and Display Video Stream on MK15 Smart Controller...............................................................22
4.2 Output Video Stream through HM30 Full HD Image Transmission System........................................22
4.3 Output Video Stream to Third-Party Image Transmission Systems......................................................24
ZR10 User Manual V1.0
5
2022 SIYI Technology Copyright
4.4 Solutions to No Image..................................................................................................................................25
4.4.1 Video Output to An Android Device....................................................................................................26
4.4.2 Video Output to A Windows Device....................................................................................................27
4.5 Common IP Addresses ................................................................................................................................29
5 SIYI FPV APP.......................................................................................................................................................30
5.1 Settings...........................................................................................................................................................32
5.2 Link Status......................................................................................................................................................33
5.3 Gimbal Camera..............................................................................................................................................33
5.4 About SIYI FPV..............................................................................................................................................35
6 Firmware Upgrade and Configuration...............................................................................................................36
6.1 Gimbal / Zoom Firmware Update................................................................................................................36
6.2 Camera Firmware Update............................................................................................................................39
6.3 Gimbal Camera Configuration.....................................................................................................................40
6.3.1 Gimbal Camera Control Channels......................................................................................................41
6.3.2 Camera Specs........................................................................................................................................42
8 After-sale Service.................................................................................................................................................43
8.1 Repair Service...............................................................................................................................................43
8.2 Warranty.........................................................................................................................................................44
8.2.1 7-Day Return & Refund.........................................................................................................................44
8.2.2 15-Day Replacement.............................................................................................................................45
8.2.3 1-Year Warranty Repair........................................................................................................................47
ZR10 User Manual V1.0
1 2022 SIYI Technology, All Rights Reserved
READ TIPS
Icons
Please pay more attention to content indicated with the following marks:
DANGER Dangerous manipulation probably leads to human injuries.
WARNING Warnings on manipulation possibly leads to human injuries.
CAUTION Cautions on what manipulation may lead to property loss.
Prohibited Mandatory Mark
Safety
ZR10 HD Hybrid Zoom Gimbal Camera is designed for professional application in
specific industries, which has been done necessary configuration before delivery, it
is forbidden to disassemble the gimbal or to change its mechanical structure. And
don’t add more payload to ZR10’s gimbal other than its own camera. Gimbal camera
is designed with very precise structure, users who approach to the equipment
should have at least the basic knowledge to operate it. Irregular or irresponsible
manipulations to the device may cause damage, property loss, or human injuries.
Users under 14 years’ old should follow an experienced trainer’s guide.
ZR10 User Manual V1.0
2 2022 SIYI Technology, All Rights Reserved
Disassembling or modification to the system is prohibited without permission from
its manufacturer, SIYI Technology.
Storage/Carrying/Recycling
When your SIYI products are stand idle, or you are bringing it outdoors, or the
system reached service life, then please do read the precautions below.
CAUTION
Always place your SIYI products at places where babies or kids do not reach.
DANGER
SIYI products should be placed in places with below conditions:
Not too hot (above 60℃) or too cold (under -20℃).
Not under direct sunshine or too dusty or too wet.
Not on an unstable holder which lacks solid supports or may cause vibration.
Not nearby steam or other heat sources.
ZR10 User Manual V1.0
3 2022 SIYI Technology, All Rights Reserved
1 INTRODUCTION
1.1 Product Features
10X Optical Zoom, 30X Hybrid Zoom
ZR10 gimbal camera supports 30x hybrid zoom, offering clear view beyond
hundreds of meters. ZR10’s fast and accurate algorithm makes it focus quickly and
quite easy to output high-quality videos.
4MP CMOS
2K Recording
ZR10 comes with a CMOS of 400 megabits of effective pixels. Video resolution is
up to 2560x1440. Recording supports Class 10 high-speed MicroSD card to present
to customers videos with full of elegant details.
3-Axis Gimbal Stabilizer
High-Precision FOC Control
ZR10 gimbal camera is applied with industry-level 3-axis stabilizing technology and
high-precision FOC control algorithms, which reduces most image shaking and
ensure that the image is always stable even if the aircraft or the vehicle is in vigorous
movement, and the camera will continuously output stable and clear images in long
focus.
ZR10 User Manual V1.0
4 2022 SIYI Technology, All Rights Reserved
High Dynamic Range
Starlight Night Vision Camera
The HDR feature in ZR10 can precisely capture details of highlights and shadows
in dynamic scenes, getting away of low light or backlight. The ultra-sensitive
starlight CMOS can keep image bright even in low light environment.
Applications
Asset Inspection
ZR10’s 30x hybrid zoom camera, working with HD image transmission devices, can
be applied in various asset inspection scenes such as power plant, construction site,
etc. Especially in inspecting very dangerous assets such as electric towers and wind
turbines, drones equipped with ZR10 zoom camera can secure ground operators
with enough distance to finish inspection by checking the received zoom images
over the air efficiently and safely.
Fire Control and Rescue
In emergent situations such rescue in fire control scenes, firefighters need to see
the full picture as fast as possible. ZR10 is zoom feature can help firefighters quickly
see what is happening and transfer important real-time images to the command
center, so they can deploy or adjust rescue force in time. Then the rescue task can
be finished in high level and high efficiency.
Traffic Monitoring
ZR10 User Manual V1.0
5 2022 SIYI Technology, All Rights Reserved
To see the full scene, and to check a specific spot, traffic coordinators just need to
hover their drones equipped with ZR10 gimbal camera in safe space over the target
position, then they can monitor the road traffic in real-time. The monitoring images
can be zoomed in when they check details or zoomed out when they stream images
of the whole scene.
1.2 Parts
1.2.1 At a Glance
