OWNER'S MANUAL
Video Sender
AUDIO/VIDEO EXTENDER SYSTEM
MODEL VK22A
(INCLUDES VT20A TRANSMITTER, VR20A RECEIVER,
AND UR23A UNIVERSAL BACKLIT REMOTE)
2
VK22A -4/97
INTRODUCTION
Your Wireless Video Sender kit consists of a transmitter base unit
which connects to your DSS receiver, and a receiver unit which
connects to the TV in another room. The Video Sender Transmitter
converts the A/V signal from your DSS into a radio signal and
transmits it (even through walls) to the Video Sender Receiver unit.
The Video Sender Receiver converts the signals back to A/V signals
which are fed through a cable to your TV's A/V input jacks.
When used with X-10 universal remotes your Video Sender also
allows you to operate your DSS while watching it in another room. By
purchasing an optional X-10 Powermid (Model PM5900) you can
control other A/V products such as VCRs, Cable Boxes, etc. while
watching a TV in another room.
There are just a few simple steps to follow to hook up your Video
Sender kit to a DSS, VCR or Cable Box.
WARNING:
To reduce the risk of fire or electric shock, do not expose this product
to rain or moisture.
3VK22A -4/97
IMPORTANT SAFETY INSTRUCTIONS
1. Read Instructions - All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions - The safety and operating instructions should be retained for
future reference.
3. Heed Warnings - All warnings on the product and in the operating instructions
should be adhered to.
4. Follow Instructions - All operating and use instructions should be followed.
5. Cleaning - Unplug this product from the wall outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
6. Attachments - Do not use attachments not recommended by the product
manufacturer as they may cause hazards.
7. Water and Moisture - Do not use this product near water - for Example, near a
bath tub, wash bowl, kitchen sink, or laundry tub, in a wet basement, or near a
swimming pool; and the like.
8. Accessories - Do not place this product on an unstable cart, stand, tripod,
bracket, or table. The product may fall, causing serious injury to a child or
adult, and serious damage to the product. Use only with a cart, stand, tripod,
bracket, or table recommended by the manufacturer, or sold with the product.
Any mounting of the product should follow the manufacturers instructions, and
should use a mounting accessory recommended by the manufacturer.
9. A product and cart combination should be moved with care.
Quick stops, excessive force and uneven surfaces may cause the
product and cart combination to overturn.
10. Ventilation - Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect if from overheating,
and these openings must not be blocked or covered. The openings should never
be blocked by placing the product on a bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturers instructions have
been adhered to.
11. Power Sources - This product should be operated only from the type of power
4
VK22A -4/97
source indicated on the marking label. If you are not sure of the type or power
supply to your home, consult your product dealer or local power company. For
products intended to operate from battery power, or other sources, refer to the
operating instructions.
12. Grounding or Polarization - This product is equipped with a polarized
alternating current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature. If
you are unable to insert the plug fully into the cutlet, try reversing the plug. If the
plug should still fail to fit, contact your electrician to replace your obsolete
outlet. Do not defeat the safety purpose of the polarized plug.
13. Power-Cord Protection - Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the product.
14. Lightning - For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from
the wall outlet and disconnect the antenna or cable system. This will prevent
damage to the product due to lightning and power-line surges.
15. Overloading - Do not overload wall outlets, extension cords, or integral
convenience receptacles as this can result in a risk of fire or electric shock.
16. Object and Liquid Entry - Never push objects of any kind into this product
through openings as they may touch dangerous voltage points or short-out parts
that could result in a fire or electric shock. Never spill liquid of any kind on the
product.
17. Servicing - Do not attempt to service this product yourself as opening or
removing covers may expose you to dangerous voltage or other hazards. Refer
all servicing to qualified service personnel.
18. Damage Requiring Service - Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
a) When the power-supply cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
5VK22A -4/97
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an
improper adjustment of other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to its
normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a
need for service.
19. Heat - The product should be situated away from heat sources such as
radiators, heat registers, stoves, or other products including amplifiers) that
produce heat.
FCC CAUTION
THIS DEVICE COMPLIES WITH PART 15 OF THE FCC RULES.
OPERATION IS SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1)THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE, AND
(2)THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
This equipment generates and uses radio frequency energy, and if not installed and
used properly, that is, in strict accordance with the manufacturers instructions, it may
cause interference to radio and television reception. It has been type tested and
found to comply with the limits for remote control devices in accordance with the
specifications in Sub-Parts B and C of Part 15 of FCC Rules, which are designed to
provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause interference to radio or television reception,
which can be determined by unplugging the equipment, try to correct the interference
by one or more of the following measures.
Reorient the antenna of the radio/TV experiencing the interference.
Relocate the equipment with respect to the radio/TV.
Move the equipment away from the radio/TV.
Plug the equipment into an outlet on a different electrical circuit from the radio/TV
experiencing the interference.
If necessary, consult your local Dealer for additional suggestions.
NOTE: Modifications to this product will void the user's authority to operate this
equipment.
6
VK22A -4/97
CONTENTS
CONTROLS AND CONNECTIONS ........................................ 8
VIDEO SENDER TRANSMITTER ............................................. 8
VIDEO SENDER RECEIVER .................................................. 9
CONNECTING UP........................................................... 10
HOOKING UP THE VIDEO SENDER TRANSMITTER ................... 10
HOOKING UP THE VIDEO SENDER RECEIVER ........................ 12
IFYOU WANT TO USE YOUR VIDEO SENDER TO TRANSMIT
FROM YOUR STEREO SYSTEM ONLY.................................... 13
FINE TUNING YOUR VIDEO SENDER ................................ 14
REMOTE EXTENDER FEATURE ........................................... 15
SETTING UPTHE SUPERREMOTE..................................... 16
BUTTON DESCRIPTIONS .................................................. 16
INSTALLING BATTERIES .................................................... 17
SETTING UP FOR TV, VCR, CABLE BOX AND SATELLITE ......... 18
CODE LISTINGS ............................................................ 19
USING AUX ................................................................ 33
SEARCHING FOR CODES ................................................. 34
IDENTIFYING CODES FOUND WITH CODE SEARCH ................. 35
SETTING THE SLEEP TIMER ............................................... 37
7VK22A -4/97
X-10 HOME AUTOMATION .......................................... 38
CONTROLLERS AND MODULES .......................................... 38
HOUSECODES AND UNIT CODES ....................................... 39
INSTALLING X-10 COMPONENTS .................................. 39
TRANSCEIVER MODULE ................................................... 39
LAMP MODULE ............................................................ 40
CONTROLLING X-10 MODULES WITH THE SUPERREMOTE....... 41
SETTING THE X-10 SLEEP TIMER...................................... 42
CHANGING THE X-10 HOUSECODE .................................. 43
USING AN IR MINI CONTROLLER (IR543)........................ 44
EXPANDING YOUR SYSTEM............................................ 45
TROUBLESHOOTING ........................................................ 47
8
VK22A -4/97
Antenna for
IR Extender
Feature IR Extender
Jack
A/V Input
Jacks
Power Cord
2.4 GHz
Video
Antenna
Power On/
Off Switch
Channel
Switch
CONTROLS AND CONNECTIONS
VIDEO SENDER TRANSMITTER
9VK22A -4/97
A/V Output
Jacks
Power Cord
Channel
Switch
2.4 GHz
Video
Antenna
TV Output
Connector
TV Channel
Switch
Power On/
Off Switch
VIDEO SENDER RECEIVER
10
VK22A -4/97
AUDIO
VIDEO LR
VIDEO LR
DSS
AUDIO
TV
ANTENN
A
TO TV
ANTENN
IN
OUT
OUT
UHF/VHF
AUDIO
VIDEO LR
VIDEO LR
DSS
AUDIO
TV
UHF/VHF
TO TV ANTENNA
TO TV
ANTENNA
a) Connections for a TV
with A/V OUT jacks.
b) Connections for a TV
without A/V OUT
jacks.
A/V Cable Coaxial
Cable
CONNECTING UP
HOOKING UP THE VIDEO SENDER TRANSMITTER
1. Connect one set of Audio/Video cables to the VIDEO and AUDIO
jacks of your Video Sender Transmitter. Take care to match the
colors of the plugs on the cable with the jacks on the Video
Sender Transmitter.
2. Connect the other end of the cable to the Audio/Video OUT jacks
on your TV. Take care to match the colors of the plugs on the
cable with the jacks on the TV. If the jacks on the TV are colored
differently, connect the yellow plug to the jack labelled VIDEO, the
red plug to the jack labelled AUDIO RIGHT and the white plug to
the jack labeled AUDIO LEFT.
Note: If your TV does not include Audio/Video OUT jacks, you
will need to remake the connections as shown in diagram b) using
the TV antenna (coaxial) connections to link up the DSS Receiver/
Cable Box/VCR to your TV.
