Table of Contents S1500e Series
iv
Performing a Point-to-Point Connection ..............15
Installing the Unit ................................................17
Performing Serial Connections ...............................18
Configuring the I/Os ............................................20
Alarms .........................................................21
Audio ...........................................................21
Performing a Hardware Reset ................................24
Status LEDs ........................................................25
System LED on the S1500e and S1502e .............26
System LED on the S1504e and S1508e .............27
Video LEDs on the S1504e and S1508e ..............27
Chapter 4 Setting Parameters with the CLI ........ 29
Getting Started ...................................................30
Starting the CLI with Telnet .............................30
Using the CLI ................................................31
Serial Port ..........................................................32
Access Management .............................................33
User Accounts ................................................33
Security ........................................................34
System Status ....................................................35
Network .............................................................36
Advanced Menu ...................................................37
Load Default Configuration ....................................38
Reboot System ...................................................38
Chapter 5 On-Screen Display (OSD)..................... 39
Quadrant 2: SmartSight Logo and Video Message .....40
Quadrant 3: Receiver Setup Details ........................41
Appendix A Factory Default Configuration .......... 43
Appendix B RS-485 Multidrop Connections ......... 45
Appendix C DHCP Support and APIPA Service.... 47
Appendix D DTE and DCE Connections................ 49
Appendix E CLI with SConfigurator ..................... 53
Appendix F CLI with HyperTerminal .................... 57
Appendix G Audio Pinouts.................................... 63
Appendix H Technical Specifications.................. 65
Glossary................................................................... 69
Index ........................................................................ 75
Compliance.............................................................. 79
