0101001100100100010010110010101010011010010

Model Number::

Features

•Up to 11 Mbps wireless LAN

•Up to 1,155 ft. operating range

•2.4GHz frequency band

• Direct Sequence Spread

Spectrum (DSSS)

•Ad-Hoc or infastructure mode

•64-bit or 128-bit WEP encryption

•LEDs monitor network activity

Benefits

•Instant access to shared information

without the need to plug in

•Networkmanagers can set up, move, or

expand a new LAN with no need for

installation or moving wires

•11 Mbps performance will meet most

foreseeable networking needs

•Wireless LANs are tremendously conven-

ient, help to enhance productivity, and

provide a real cost benefit over traditional

wired networks (no installation or mainten-

nance expenses)

•Plug-and-play; no configuration needed

Compatibility

•IEEE 802.11b

•Windows

98/Me/NT/2000/XP

The SMC2632W is an IEEE 802.11b - compliant 11 Mbps

wireless PC card. It meets the needs of small business

and corporate users who require an 11 Mbps wireless

connection to an existing LAN. This new adapter fea-

tures an operating range of up to 1,155 feet, an ad-hoc

mode for peer-to-peer networking, and true plug-and-

play installation in all notebook computers.

Great for mobile users, temporary work sites, and a

range of other applications, wireless technology pro-

vides optimal mobility, simple and flexible installation

options and excellent scalability in supporting addi-

tional PCs. The technology is also ideal for use with

cable modems, xDSL, or SOHO applications.

In the typical wireless configuration, an Access Point

(SMC2655W) connects to a wired network. Each

Access Point supports up to 64 users, with a maximum

range of 1,800 feet. Users access the LAN via SMC wire-

less adapters in their notebooks or desktops.The wire-

less LAN adapters interface between the client

Network Operating System and the Access Point. In a

peer-to-peer configuration,one wireless card is needed

for each computer, but no Access Point is required.

SMC2632W

wireless

EZ ConnectTM

11 Mbps Wireless PC Card

Benefits

38 Tesla

Irvine, CA 92618

1-800-SMC-4YOU

www.smc.com

Product Description

EZ Connect 11 Mbps Wireless PC CardSMC2632W

0101001100100100010010110010101010011010010

SPECIFICATIONS

SMC2632W

wireless

Data Rates

11, 5.5, 2, 1 Mbps

Operating Range

Up to 1,155 ft

Network Configuration

Ad-hoc (peer-to-peer)

Infrastructure

Radio Signal Type

Direct Sequence Spread Spectrum (DSSS)

Encryption

64-bit or 128-bit WEP

Operating Frequency

US & Canada: 2.400-2.4835 GHz

Europe & Japan: 2.400-2.497 GHz

Sensitivity

-83dBm (typical)

Modulation

DBPSK, DQPSK, CCK

Output Power

+19dBm (typical)

Operating Systems

Windows 98/Me/NT/2000/XP

Power Consumption

3.3V DC

500mA TX

230mA RX

Dimensions

Type II PCMCIA + antenna

115x54x8mm

Weight

39g

Temperature

Operating: 0° to 50° C

Storage: -20° to 70° C

Humidity

0% to 95% (non-condensing)

Network Connection

IEEE 802.11b – 11 Mbps via antenna

Antenna

Built-in PCB antenna

LED Indicators

Link Status

EMC/Safety Compliances

CE Mark

EN55022 Class B

EN55024

IEC 6100-4-2/3/4/6/11

ETS 300 826

ETS 300 326

Emissions

FCC Class B, ETS 300-328, RCR STD-33

CSA/NRTL (C22.2.950, UL 1950)

Vibration/Shock/Drop

IEC 68-2-34/IEC 68-2-27/IEC 68-2-32

Standards

IEEE 802.11b

Warranty

Limited lifetime

EZ ConnectTM

11 Mbps Wireless PC Card
