Smeg CB30PFNF Bedienungsanleitung
FRIGORIFERO CON
CONGELATORE
Istruzioni per l'uso
Nel ringraziarvi per avere acquistato questo
prodotto SMEG, vi raccomandiamo di leggere
attentamente le seguenti istruzioni e di conservare
questo manuale per eventuali consultazioni future.
KÜHL-/GEFRIERSCHRANK-
KOMBINATION
Benutzerhandbuch
Bitte lesen Sie dieses Benutzerhandbuch vor dem
Betrieb sorgfältig durch und bewahren Sie es zum
späteren Gebrauch auf.
FRIDGE-FREEZER
User's Guide
Please read this User's Guide carefully
before operating and keep it handy for
reference at all times.
Registration
Important Safety Instruction
Identification of Parts
Temperature Control
Extra Freezer
Self Test
Door Alarm
Extra Fresh
Ice Making
Defrosting
Folding Shelf
Storing Food
General Information
Lamp Replacement
To Reverse the Doors
Cleaning
Trouble Shooting
24
24
29
30
32
32
32
33
34
34
35
36
37
38
38
39
40
Introduction
Operation
Suggestion On
Food storage
Care and
Maintenance
Trouble Shooting
Table of Contents
*Refer to Installation Insturction for details.
23
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Important Safety Instruction
To avoid any risk of personal injury, material
damage or incorrect use of the appliance, be sure to
observe the following safety precautions. (After
reading these owner’s instructions, please keep
them in a safe place for reference). Remember to
hand them over to any subsequent owner.
24
Introduction
Introduction
Registration
The model and serial number are found on the rear of
this unit. This number is unique to this unit and not
available to others. You should record requested
information here and retain this guide as a permanent
record of your purchase. Staple your receipt here.
Indicates that a
danger of death
or serious injury
exists
Warning
Indicates that a
risk of personal
injury or
material
damage exists
Caution
25
Introduction
Precaution
Important Safety Instruction
•This fridge-freezer must be properly installed and
located in accordance with the Installation Instruction
before it is used.
•Before you install this fridge-freezer reference to
installation manual.
•Never unplug your fridge-freezer by pulling on the
power cord. Always grip plug firmly and pull straight
out from the outlet.
•When moving your appliance away from the wall, be
careful not to roll over or damage the power cord.
•After your fridge-freezer is in operation, do not touch
the cold surfaces in the freezer compartment,
particularly when hands are damp or wet. Skin may
adhere to these extremely cold surfaces.
•Pull out the power plug prior to cleaning the fridge-
freezer.
Never damage, serverely bend, pull out, or twist the
power cord because power cord damage may cause a
fire or electronic shock.
Never place glass products in the freezer because they
may be broken when their inner contents are frozen.
•Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
•Do not insert the power plug with wet hands.
You may receive an electric shock.
•Do not install the fridge/freezer in a damp place, where
it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or fire.
Warning
Introduction
Important Safety Instruction
The supply plug of the refrigerator-freezer should be
placed in easy accessible position for quick disconnection
in emergency.
It will cause electric shock or fire.
Accessibility of
Supply Plug
Do not modify or
extend the Power
Cord length.
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Supply Cord
Replacement
Don't store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
Don't store
In the event of an electric short circuit, grounding
earthing) reduces the risk of electric shock by providing
an escape wire for the electric current. In order to prevent
possible electric shock, this appliance must be grounded.
Improper use of the grounding plug can result in an
electric shock. Consult a qualified electrician or service
person if the grounding instructions are not completely
understood, or if you have doubts on whether the
appliance is properly grounded.
Grounding
(Earthing)
Danger Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not easily
climb inside.
•Do not disassemble, repair or alter the appliance.
It may cause fire or abnormal operations, which may
lead to injury.
•Pull the power plug out of the socket before replacing
the interior light in the refrigerator.
Otherwise, there is a risk of electric shock.
•
If possible, connect the fridge-freezer to its own
individual electrical outlet to prevent it and other
appliances or household lights from causing an overload.
26
Introduction
Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the
appliance require special disposal procedures. When
disposal, please consult with service agent or a
similarly qualified person.
Important Safety Instruction
Warning
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite or
cause an eye injury. If a leak is detected, avoid any
naked flames or potential sources of ignition and air
the room in which the appliance is standing for
several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the size
of the room in which the appliance may be sited depends
on the amount of refrigerant used. The room must be
1m2in size for every 8g of R600a refrigerant inside the
appliance. The amount of refrigerant in your particular
appliance is shown on the identification plate inside the
appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
27
28
Introduction
Important Safety Instruction
•
If the wall socket is loose, do not insert the power
plug.
It may cause electric shock or fire.
•
Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull it
straight out from the outlet.
You may disconnect a wire and cause a short circuit.
•
Do not use a wet or damp cloth when cleaning the
plug. Remove any foreign matter from the power
plug pins.
Otherwise, there is a risk of fire.
•
Do not put your hands into the bottom area of the
appliance.
Any Sharp edges may cause personal injury.
•
After unplugging the appliance, wait for at least
five minutes before plugging it again to the wall
socket.
Abnormal operation of the freezer may cause material
damage.
•
If the appliance is not to be used for a long time,
pull out the power plug.
Any deterioration in the insulation may cause fire.
•
Do not let children touch or play with the control
panel on the front of the appliance.
•
The refrigerant used in fridge/freezer and the
gases in the insulation material require special
disposal procedures. Ensure that none of the pipes
on the back of the appliances are damaged prior
to disposal.
Caution
29
Introduction
Identification of Parts
Lamp
Dairy Corner
Egg Tray
Door Basket
Bottle Guide
2Bottle
Door Basket
Removable
Glass Shelf
Folding Shelf
Snack Bin
Multi-Air Flow Duct
Vegetable Drawer
Used to keep fruits
and vegetables crisp
Extra Fresh
Ice Tray
Ice Bank
Freezer
Compartment
Leveling Screw
30
Operation
Temperature Control
Display Panel For
Temperature Control
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
Adjusting the
temperatures and
functions
Temperature Adjustment Button
for Refrigerator Compartment
Display Panel
Temperature Adjustment Button
for Extra Fresh Compartment
PowerExtra Freezer
Temperature Adjustment Button
for Freezer Compartment
Operation
•
The initial Temperature of the Freezer and Refrigerator
Compartment is -20°C and 3°C respectively.
You can now adjust the temperature of the
compartments as you want.
How to adjust the
temperature in the
refrigerator and
freezer
compartment
•
If you push button more than 3 seconds
you can switch on or off the Refrigerator.
Power
The actual inner temperature varies depending on the
food status, as the indicated setting temperature is a
target temperature, not actual temperature within
refrigerator.
Refrigeration function is weak in the initial time. Please
adjust temperature as above after using refrigerator for
minimum 2~3 days.
Note
•
When you press the
temperature control button,
the temperature of the
Freezer or Refrigerator part is
change by 1 degree.
31
