Smeg FQ75XPED Bedienungsanleitung

Manual de instrucciones

Instruction Manual

Manuale di istruzioni

ﬁn

Notice d'Utilisation

Bruksanvisning

Bedienungsanleitung

Käyttöohje

Bruksanvisning

Gebruiksaanwijzing

FQ75XPED

Please read this manual before using the product!

Dear Customer,

We'd like you to make the best use of our product, which has been manufactured in modern facilities

with care and meticulous quality controls.

Thus, we advice you to read the entire user manual before you use the product. In case the product

changes hands, do not forget to hand the guide to its new owner along with the product.

This guide will help you use the product quickly and safely.

• Please read the user guide carefully before installing and operating the product.

• Always observe the applicable safety instructions.

• Keep the user guide within easy reach for future use.

• Please read any other documents provided with the product.

Keep in mind that this user guide may apply to several product models. The guide clearly indicates any

variations of different models.

CImportant information and use-

ful tips.

ARisk of life and property.

BRisk of electric shock.

The product’s packaging is made of

recyclable materials, in accordan-

ce with the National Environment

Legislation.

2 / 24 EN Refrigerator / User Guide

1 Safety and environment instructions3

1.1. General safety. . . . . . . . . . . . . . . . . . . . . . . 3

1.1.1 HC warning. . . . . . . . . . . . . . . . . . . . . . . . 4

1.1.2 For models with water fountain . . . . . . . . . 4

1.2. Intended use. . . . . . . . . . . . . . . . . . . . . . . . 5

1.3. Child safety. . . . . . . . . . . . . . . . . . . . . . . . . 5

1.4. Compliance with WEEE Directive and

Disposing of the Waste Product . . . . . . . . . 5

1.5. Compliance with RoHS Directive . . . . . . . . . 5

1.6. Package information . . . . . . . . . . . . . . . . . . 5

2 Refrigerator 6

3 Installation 7

3.1. Right place for installation . . . . . . . . . . . . . . 7

3.2. Attaching the plastic wedges . . . . . . . . . . . . 7

3.3. Adjusting the stands . . . . . . . . . . . . . . . . . . 8

3.4. Power connection . . . . . . . . . . . . . . . . . . . . 8

3.5. Water connection . . . . . . . . . . . . . . . . . . . . 8

3.6. Connecting water hose to the product . . . . . 9

3.7. Connecting to water mains . . . . . . . . . . . . . 9

3.8. For products using water carboy . . . . . . . . 10

3.9. Fixing external filter on the wall (Optional) . . 11

4 Preparation 13

4.1. What to do for energy saving. . . . . . . . . . . 13

4.2. First Use. . . . . . . . . . . . . . . . . . . . . . . . . . 13

5 Using the product 14

5.1. Indicator panel . . . . . . . . . . . . . . . . . . . . . 14

5.2. Activating the water filter replacing alert . . 16

5.3. Taking ice / water . . . . . . . . . . . . . . . . . . . 16

5.4. Dripping tray. . . . . . . . . . . . . . . . . . . . . . . 17

5.5. Zero degree compartment. . . . . . . . . . . . . 17

5.6. Vegetable bin . . . . . . . . . . . . . . . . . . 17

5.7. Multi zone storage compartment . . . . . . . 18

5.8. Rotating storage compartment . . . . . . . . . 18

5.9. Blue light . . . . . . . . . . . . . . . . . . . . . . . . . 18

5.10. Ionizer . . . . . . . . . . . . . . . . . . . . . . . . . . 18

5.11. Minibar. . . . . . . . . . . . . . . . . . . . . . . . . . 18

5.12.Freezing fresh food . . . . . . . . . . . . . . . . . 19

5.13.Recommendations for storing frozen foods 19

5.14.Deep freezer details. . . . . . . . . . . . . . . . . 19

5.15.Placing the food. . . . . . . . . . . . . . . . . . . . 20

5.16.Door open alert . . . . . . . . . . . . . . . . . . . . 20

5.17.Interior light . . . . . . . . . . . . . . . . . . . . . . . 20

6 Maintenance and cleaning 21

6.1. Preventing malodour . . . . . . . . . . . . . . . . . 21

6.2. Protecting plastic surfaces . . . . . . . . . . . . 21

6.3. Cleaning the ice tray . . . . . . . . . . . . . . . . . 21

7 Troubleshooting 22

Table of Contents

3 / 24 EN

Refrigerator / User Guide

1 Safety and environment instructions

This section provides the safety

instructions necessary to prevent

the risk of injury and material

damage. Failure to observe these

instructions will invalidate all

types of product warranty.

1.1.General safety

• This product should not be

used by persons with physical,

sensory and mental disabilities,

without sufficient knowledge

and experience or by children.

The device can only be

used by such persons under

supervision and instruction of

a person responsible for their

safety. Children should not be

allowed to play with this device.

• In case of malfunction, unplug

the device.

• After unplugging, wait at least

5 minutes before plugging

in again. Unplug the product

when not in use. Do not touch

the plug with wet hands! Do

not pull the cable to plug off,

always hold the plug.

• Wipe the power plug’s tip with

a dry cloth before plugging in.

• Do not plug in the refrigerator if

the socket is loose.

• Unplug the product during

installation, maintenance,

cleaning and repair.

• If the product will not be used

for a while, unplug the product

and remove any food inside.

• Do not use steam or steamed

cleaning materials for cleaning

the refrigerator and melting the

ice inside. Steam may contact

the electrified areas and cause

short circuit or electric shock!

• Do not wash the product by

spraying or pouring water on it!

Danger of electric shock!

• In case of malfunction, do not

use the product, as it may

cause electric shock. Contact

the authorized service before

doing anything.

• Plug the product into an

earthed socket. Earthing

must be done by a qualified

electrician.

• If the product has LED type

lighting, contact the authorized

service for replacing or in case

of any problem.

• Do not touch frozen food with

wet hands! It may adhere to

your hands!

• Do not place liquids in bottles

and cans into the freezer

compartment. They may burst

out!

• Place liquids in upright position

after tightly closing the lid.

4 / 24 EN Refrigerator / User Guide

Safety and environment instructions

• Do not spray flammable

substances near the product,

as it may burn or explode.

• Do not keep flammable

materials and products with

flammable gas (sprays, etc.) in

the refrigerator.

• Do not place containers

holding liquids on top of the

product. Splashing water on

an electrified part may cause

electric shock and risk of fire.

• Exposing the product to rain,

snow, sunlight and wind will

cause electrical danger. When

relocating the product, do not

pull by holding the door handle.

The handle may come off.

• Take care to avoid trapping any

part of your hands or body in

any of the moving parts inside

the product.

• Do not step or lean on the door,

drawers and similar parts of

the refrigerator. This will cause

the product to fall down and

cause damage to the parts.

• Take care not to trap the power

cable.

1.1.1 HC warning

If the product comprises a cooling

system using R600a gas, take

care to avoid damaging the

cooling system and its pipe while

using and moving the product.

This gas is flammable. If the

cooling system is damaged, keep

the product away from sources

of fire and ventilate the room

immediately.

CThe label on the inner left

side indicates the type of

gas used in the product.

1.1.2 For models with

water fountain

• In order to operate the water

circuit of the refrigerator

smoothly, the water mains

pressure must be between

1-8 bars. For conditions where

water mains pressure exceeds

5 bars a pressure regulator

should be used. If the water

mains pressure exceeds 8

bars then the refrigerator’s

water circuit should not be

5 / 24 EN

Refrigerator / User Guide

Safety and environment instructions

connected to the water mains.

If you lack the knowledge of

how to measure the water

mains pressure, please seek

a professional support.Use

drinking water only.

1.2.Intended use

• This product is designed for

home use. It is not intended for

commercial use.

• The product should be used to

store food and beverages only.

• Do not keep sensitive

products requiring controlled

temperatures (vaccines,

heat sensitive medication,

medical supplies, etc.) in the

refrigerator.

• The manufacturer assumes no

responsibility for any damage

due to misuse or mishandling.

• The product’s bench life is

10 years. The spare parts

necessary for the product to

function will be available for

this period.

1.3.Child safety

• Keep packaging materials out

of children’s reach.

• Do not allow the children to

play with the product.

• If the product’s door comprises

a lock, keep the key out of

children’s reach.

1.4. Compliance with WEEE Directive

and Disposing of the Waste Product

This product complies with EU WEEE

Directive (2012/19/EU). This product bears a

classification symbol for waste electrical and

electronic equipment (WEEE).

This product has been manufactured

with high quality parts and materials

which can be reused and are suitable

for recycling. Do not dispose of the

waste product with normal domestic

and other wastes at the end of its

service life. Take it to the collection

center for the recycling of electrical and

electronic equipment. Please consult your local

authorities to learn about these collection

centers.

1.5. Compliance with RoHS Directive

• This product complies with EU WEEE Directive

(2011/65/EU). It does not contain harmful and

prohibited materials specified in the Directive.

1.6. Package information

• Packaging materials of the product are

manufactured from recyclable materials in

accordance with our National Environment

Regulations. Do not dispose of the packaging

materials together with the domestic or other

wastes. Take them to the packaging material

collection points designated by the local

authorities.

6 / 24 EN Refrigerator / User Guide

2 Refrigerator

C*Optional: Figures in this user guide are schematic and may not be exactly match your product. If your

product does not comprise the relevant parts, the information pertains to other models.

1. Cooler compartment

2. Butter cheese rack

3. Glass rack

4. Eggholder

5. Odour filter

6. Minibar inner cover

7. Zero degree compartments

8. Vegetable bins

9. Cooler compartment door shelves

10. Door rack under storage container

11. Multizone compartment glass racks

12. Freezer compartment door shelves

13. Multi Zone / Flexi Zone / Cool Control

compartment food storage compartments

14. Multizone compartment

15. Freezer compartment

16. Frozen or fresh food storage compartment

17. Freezer

18. Ice stock compartment

1415

7 / 24 EN

Refrigerator / User Guide

3 Installation

3.1. Right place for installation

Contact the Authorized Service for the product's

installation. To ready the product for installation,

see the information in the user guide and make

sure the electric and water utilities are as required.

If not, call an electrician and plumber to arrange

the utilities as necessary.

BWARNING: The manufacturer assumes

no responsibility for any damage caused

by the work carried out by unauthorized

persons.

BWARNING: The product’s power cable

must be unplugged during installation.

Failure to do so may result in death or

serious injuries!

AWARNING: : If the door span is too

narrow for the product to pass, remove

the door and turn the product sideways; if

this does not work, contact the authorized

service.

•Placetheproductonaflatsurfacetoavoid

vibration.

•Placetheproductatleast30cmawayfromthe

heater, stove and similar sources of heat and at

least 5 cm away from electric ovens.

•Donotexposetheproducttodirectsunlightor

keep in damp environments.

•Theproductrequiresadequateaircirculationto

function efficiently. If the product will be placed

in an alcove, remember to leave at least 5 cm

distance between the product and the ceiling

and the walls.

•Donotinstalltheproductinenvironmentswith

temperatures below -5°C.

3.2. Attaching the plastic wedges

Use the plastic wedges in the provided with

the product to provide sufficient space for air

circulation between the product and the wall.

To attach the wedges, remove the screws on the

product and use the screws provided with the wedges.

Attach 2 plastic wedges on the ventilation cover

shown as j in the figure.

8 / 24 EN Refrigerator / User Guide

Installation

3.3. Adjusting the stands

If the product is not in balanced position, adjust the

front adjustable stands by rotating right or left.

3.5. Water connection

(Optional)

AWARNING: Unplug the product and

the water pump (if available) during

connection.

The product’s water mains, filter and carboy

connections must be rendered by authorizer

service. The product can be connected to a carboy

or directly to the water mains, depending on the

model. To establish the connection, the water hose

must first be connected to the product.

Check to see the following parts are supplied with

your product’s model:

3.4. Power connection

AWARNING: Do not use extension or multi

sockets in power connection.

BWARNING: Damaged power cable must

be replaced by Authorized Service.

CWhen placing two coolers in adjacent

position, leave at least 4 cm distance

between the two units.

• Our firm will not assume responsibility for any

damages due to usage without earthing and

power connection in compliance with national

regulations.

• The power cable plug must be easily

accessible after installation.

• Connect the refrigerator to an earthed socket

with 220-240V/50 Hz voltage. The plug must

comprise a 10-16A fuse.

• Do not use multi-group plug with or without

extension cable between the wall socket and

the refrigerator.

1. Connector (1 piece): Used to attach the water

hose to the rear of the product.

2. Hose clip (3 pieces): Used to fix the water

hose on the wall.

3. Water hose (1 piece, 5 meter diameter 1/4

inches): Used for the water connection.

4. Faucet adapter (1 piece): Comprises a porous

filter, used for connection to the cold water

mains.

5. Water filter (1 piece *Optional): Used to

connect the mains water to the product. Water

filter is not required if carboy connection is

available.

9 / 24 EN

Refrigerator / User Guide

Installation

3.6. Connecting water

hose to the product

To connect the water hose to the product,

follow the instructions below.

1. Remove the connector on the hose nozzle

adaptor in the back of the product and run the

hose through the connector.

2. Push the water hose down tightly and connect

to the hose nozzle adaptor.

3. Tighten the connector manually to fix on the

hose nozzle adaptor. You may also tighten the

connector using a pipe wrench or pliers.

3.7. Connecting to water mains

(Optional)

To use the product by connecting to the cold water

mains, a standard 1/2” valve connector must be

installed to the cold water mains in your home. If

the connector is not available or if you are unsure,

consult a qualified plumber.

1. Detach the connector (1) from the faucet

adaptor (2).

2. Connect the faucet adaptor to the water mains

valve.

3. Attach the connector around the water hose.

4. Connect the other end of the hose to the

water mains (See Section 3.7) or, to use

carboy, to the water pump (See Section 3.8).

Andere Handbücher für FQ75XPED

Inhaltsverzeichnis

Andere Smeg Kühlschrank Handbücher

Smeg

Smeg Refrigerator SRA416TP3 Schulungshandbuch

Smeg

Smeg C3170NE Bedienungsanleitung

Smeg

Smeg FC182PSN Bedienungsanleitung

Smeg

Smeg CF35PBF Bedienungsanleitung

Smeg

Smeg UD7140LSP Bedienungsanleitung

Smeg

Smeg FL227APZD Bedienungsanleitung

Smeg

Smeg FQ60XDAIE Bedienungsanleitung

Smeg

Smeg FR298SENF Benutzerhandbuch

Smeg

Smeg FR 320 P Bedienungsanleitung

Smeg

Smeg FAB50RCR Bedienungsanleitung

Smeg

Smeg FC380A Bedienungsanleitung

Smeg

Smeg CR326AP1 Bedienungsanleitung

Smeg

Smeg FL1022P Bedienungsanleitung

Smeg

Smeg FAB32RRD5UK Bedienungsanleitung

Smeg

Smeg FR 320 P Bedienungsanleitung

Smeg

Smeg S 34 STRP Bedienungsanleitung

Smeg

Smeg FD238A Benutzerhandbuch

Smeg

Smeg FR138SE Bedienungsanleitung

Smeg

Smeg FC310AL Montageanleitung

Smeg

Smeg FAB28MCUS Bedienungsanleitung

Smeg

Smeg FC370B2PE Bedienungsanleitung

Smeg

Smeg FQ60XP Bedienungsanleitung

Smeg

Smeg RFD50XZA Bedienungsanleitung

Smeg

Smeg FAB30LRD5UK Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
