Smeg SW Range Bedienungsanleitung
SW ... R
UK Instructions for use
DE Bedienungsanleitung
FR Mode d’emploi
NL Gebruiksaanwijzing
ES Instrucciones para el uso
2
GB
Thank you for purchasing your new
refrigerator from Smeg. Please note that
these instructions apply to all refrigerators
in the SW range. Illustrations and ttings
may therefore not necessarily correspond
exactly to your model.
Warning
As the refrigerant used in this appliance is a
ammable gas (Isobutane R600a), special
care must be taken to prevent damage
to the refrigerant circuit and piping during
transport and installation.
If damage does occur, avoid sparks or
naked ame in the vicinity of the appliance,
ensure that the room is well ventilated,
disconnect the power supply, and contact
your supplier.
The unit must only be serviced by quali-
ed technicians from an approved service
centre.
Old appliances
Old refrigerators and freezers are often
tted with complicated latches that can
only be opened from the outside. If you
have one of these old units stored away
somewhere, or if you scrap one, remember
to destroy the latch rst in order to prevent
children from being exposed to great dan-
ger by getting locked inside the unit.
Before use
Before operating your new appliance,
please read the following instructions care-
fully as they contain important information
on safety, installation, operation and main-
tenance. Keep the instructions for future
reference.
On receipt, check to ensure that the appli-
ance has not been damaged during trans-
port. Transport damage should be reported
to the local distributor before the refrigerator
is put to use.
Remove the packaging. Clean the inside of
the cabinet using warm water with a mild
detergent. Rinse with clean water and dry
thoroughly (see cleaning instructions). Use
a soft cloth.
If during transport the appliance has been
laid down, or if it has been stored in cold
surroundings (colder than +5°C), it must be
allowed to stabilise in an upright position for
at least an hour before being switched on.
Contents
Get to know your refrigerator............3
Installation and start-up....................4
Reversing the door...........................7
Electrical connection.........................8
Operation and function.....................9
Layout and ttings..........................10
Defrosting,
cleaning and maintenance..............11
Fault nding....................................12
Spare parts and service.................13
Disposal..........................................14
3
GB
Get to know your refrigerator
Control panel
Lighting
Bottle rack
Nameplate
Shelf with storage boxes
Door shelf
Glass shelf
Sealing strip
Door handle
Crisper bins
Kick plate
Adjustable feet
g.1
4
GB
600 600
600 600
600 600
600 600
g. 2
g. 3
Placement
For safety and operational reasons, the
appliance must not be installed outdoors.
The appliance should be placed on a level
surface in a dry, well ventilated room (max.
75% relative air humidity). Never place the
appliance close to sources of heat such as
cookers or radiators, and avoid placing it in
direct sunlight.
Room temperature
The climate class is stated on the
nameplate (see g. 1 on page 3 and g. 17
on page 13). This species the optimum
room temperature.
Climate class Optimum room tem-
perature
SN +10 ºC to +32 ºC
N+16 ºC to +32 ºC
ST +18 ºC to +38 ºC
T+18 ºC to +43 ºC
Installation
The surface on which the appliance is to be
placed must be level. Do not use a frame or
similar.
The appliance can be installed as a free-
standing unit against a wall, built into a
kitchen element, or lined up with other
appliances (gs 2-3).
After installation, the plug should be
accessible.
Installation and start-up
5
GB
1650/1950
100
100
1560/1860
g. 6 g. 7
600
610
g. 4
Ventilation
It is important that the appliance be
well ventilated and that air can circulate
unhindered above, below and around it. The
gures below illustrate how the necessary
air circulation can be ensured (gs 6-7).
The appliance viewed from
above
If the appliance is placed beside a wall,
there must be sufcient room for its door
to be opened wide enough to allow the
shelves to be pulled out (g. 4).
Distance pieces
The distance pieces on the rear of the
appliance ensure sufcient air circulation.
Fit the distance pieces supplied with the
appliance as shown in g. 5.
g. 5
6
GB
Setting up
It is important that the appliance be
absolutely level. To level the appliance,
remove the kick plate below the door and
screw the adjustable feet up or down (gs
8-9). If necessary, it is possible to adjust the
back feet before the upright is installed. Use
a spirit level to check that the appliance is
absolutely level.
If the appliance is to be placed on a soft
surface, e.g. oorboards or a carpet, it is
best to recheck whether the appliance is still
level after a period of time as the underlying
surface may give under the weight of the
appliance.
g. 8
g. 9
Do not tilt the upright more than 7 degrees
to avoid damaging the oor.
>7º
<7º
g. 10
g. 11
7
GB
Reversing the door
The door can be changed from right-hinged to left-hinged and vice versa as follows:
1. Lay the appliance on its back with the
door uppermost.
2. Remove the upper hinge.
3. Move the plastic plugs to where the
upper hinge was tted.
4. Lift off the door and lay it aside.
10. Remember to pull the pin in the door
closer towards the side before tting
the door..
6. Loosen lock nut with the fork wrench
enclosed and move the pin.
11. Ret the door.
12. Fit the upper hinge.
9. Remove the door closer and ret it on
the opposite side.
5. Remove the kick plate by pulling it
outwards and upwards.
7. Remove the lower hinge. Rotate the
hinge through 180° and ret it on the
opposite side of the appliance.
8. Ret the kick plate
15. After reversing the door(s), it is important to check that the sealing strip provides a tight seal all the way round. If it does not, carefully
heat the strip all the way round using a hair dryer. Then ease the strip outwards slightly so that it forms a tight seal against the cabinet.
Be careful not to heat the strip so much that it melts!
13. Remove the door handle and ret it on
the opposite side. Ret the caps.
14. The appliance must be allowed to
stabilise in an upright position for at
least 1 hour before being switched on.
8
GB
The appliance is intended for connection
to alternating current. The required volt-
age (V) and frequency (Hz) are stated on
the nameplate inside the appliance. Power
must be connected via an independent wall
socket outlet.
Technical data
This appliance complies with CE marking
regulations, directives and standards.
Low Voltage Directive 73/23/EEC.
EMC Directive 89/336/EEC.
Council Directive 92/75/EEC on the en-
ergy labelling of household appliances as
subsequently amended by 94/2/EC and
2003/66/EC.
Directive 96/57/EC on energy efciency re-
quirements, and subsequent amendments.
Electrical connection
9
GB
The thermostat button can be set
from 1 (less cold) to 7 (more cold). A
suitable setting must be found by trial
and error. Start by setting the button to
4. Check the temperature, then adjust
the setting upwards or downwards as
required. Usually, a temperature of 5°C
is recommended for items stored in a
refrigerator. To check the temperature,
place a thermometer in a glass of water
positioned in the centre of the cabinet for 12
hours. The average temperature is usually
found in the centre of the cabinet.
The chiller section corresponds to an
old-fashioned larder. The temperature
uctuates between +8ºC and +12ºC.
Temperature control of chiller
section:
The refrigerator and chiller sections
are separated by a temperature plate,
positioned above the crisper bins.
Thermostat button
Lighting
Control lamp
01
2
3
4
5
6
7
Thermostat button
Lighting
Control lamp
S
S
O
I
!
Thermometer
S = Super freeze
O = Alarm off / super freeze off
= Akustisk alarm
01
2
3
4
5
6
7
Operation and function
g. 12
10
GB
Glass shelves
The shelves are made of tempered glass
and can be repositioned within the cabinet.
To move the shelves, the door must be
opened 90°. To remove a shelf, pull it
forwards and lower it. The shelf can then be
removed and placed in the desired position.
From the top and downwards, the shelves
are suitable for storing bakery products,
ready-made meals, dairy products, meat
products and sliced meat.
Storage boxes
The storage boxes can either be placed in
the door or on the glass shelves. The tight-
tting lids prevent items stored in the boxes
from drying out. The boxes are ideal for
storing items such as butter and cheese.
Bottle rack
The bottle rack is ideal for both large and
small bottles.
Crisper bins
The crisper bins are ideal for storing fruit
and vegetables. The shelf above the bins
functions as a lid, maintaining humidity and
preventing the items stored in the bins from
drying out.
Glass shelf with slide damper
The slide damper above the crisper bins
allows the temperature and humidity in the
bins to be regulated.
- Opening the damper reduces the
temperature and humidity.
- Closing the damper increases the
temperature and humidity.
Shelves in the door
The shelves in the door are practically
positioned with the box shelf at the top, the
egg holder in the middle and door shelves
at the bottom. They provide ample space for
storing large and small bottles, cartons, jars
and tubs. All shelves can be repositioned.
Layout and ttings
g. 13
g. 14
g. 15
