SolarEdge StorEdge Interface SESTI-S4 Bedienungsanleitung

Installation Guide

StorEdge Interface

For the Single Phase Inverter with HD-

Wave Technology and SetApp

Configuration and LG Chem Batteries

Version 1.1

Contents

Disclaimers 2

Important Notice 2

Emission Compliance 2

Revision History 4

HANDLING AND SAFETY INSTRUCTIONS 5

Safety Symbols Information 5

IMPORTANT SAFETYINSTRUCTIONS 5

Chapter 1: Overview 7

The StorEdge Solution Components 7

Additional References 8

Installation Workflow 9

Installation Equipment List 10

Chapter 2: Connecting the Energy Meter 12

Chapter 3: StorEdge Interface Installation 13

Unpacking and Identifying the Product 13

Mounting the StorEdge Interface 13

Connecting the StorEdge Interface 14

Chapter 4: System Configuration 20

Setting up Communication with the Battery and Energy Meter 20

Configuring StorEdge Applications 21

Running a Battery Self-test 21

Appendix A: Troubleshooting 23

StorEdge Interface LEDs 23

Appendix B: Powering the LG Chem Battery Off and On 24

Appendix C: Connecting and Powering Systems with a DC DisconnectSwitch 25

StorEdge Interface Technical Specifications 27

Support Contact Information 29

StorEdge Interface Installation Guide MAN-01-00621-1.1

1 

Disclaimers

Important Notice

No part of this document may be reproduced, stored in a retrieval system or

transmitted, in any form or by any means, electronic, mechanical, photographic,

magnetic or otherwise, without the prior written permission of SolarEdge Inc.

The material furnished in this document is believed to be accurate and reliable.

However, SolarEdge assumes no responsibility for the use of this material. SolarEdge

reserves the right to make changes to the material at any time and without notice. You

may refer to the SolarEdge web site (www.solaredge.com) for the most updated version.

All company and brand products and service names are trademarks or registered

trademarks of their respective holders.

Patent marking notice: see http://www.solaredge.com/patent

The general terms and conditions of delivery of SolarEdge shall apply.

The content of these documents is continually reviewed and amended, where

necessary. However, discrepancies cannot be excluded. No guarantee is made for the

completeness of these documents.

The images contained in this document are for illustrative purposes only and may vary

depending on product models.

Emission Compliance

This equipment has been tested and found to comply with the limits applied by the

local regulations.

These limits are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the instructions,

may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, you are encouraged to try to correct

the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and the receiver.

Disclaimers 2

StorEdge Interface Installation Guide MAN-01-00621-1.1

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications not expressly approved by the party responsible for

compliance may void the user’s authority to operate the equipment.

StorEdge Interface Installation Guide MAN-01-00621-1.1

3 Emission Compliance

Revision History

Version 1.1 (September 2019)

Added

Running a Battery Self-test

on page 21.

Version 1.0 (July 2019)

First version of this guide

Revision History 4

StorEdge Interface Installation Guide MAN-01-00621-1.1

HANDLING AND SAFETY INSTRUCTIONS

During installation, testing and inspection, adherence to all the handling and safety

instructions is mandatory. Failure to do so may result in injury or loss of life and

damage to the equipment.

Safety Symbols Information

The following safety symbols are used in this document. Familiarize yourself with the

symbols and their meaning before installing or operating the system.

WARNING!

Denotes a hazard. It calls attention to a procedure that, if not correctly

performed or adhered to, could result in injury or loss of life. Do not proceed

beyond a warning note until the indicated conditions are fully understood and

met.

CAUTION!

Denotes a hazard. It calls attention to a procedure that, if not correctly

performed or adhered to, could result in damage or destruction of the

product. Do not proceed beyond a caution sign until the indicated conditions

are fully understood and met.

NOTE

Denotes additional information about the current subject.

IMPORTANTSAFETYFEATURE

Denotes information about safety issues.

Disposal requirements under the Waste Electrical and Electronic Equipment (WEEE)

regulations:

NOTE

Discard this product according to local regulations or send it back to SolarEdge.

IMPORTANT SAFETYINSTRUCTIONS

SAVETHESEINSTRUCTIONS



WARNING!

The inverter cover must be opened only after shutting off the inverter ON/OFF

switch located at the bottom of the inverter. This disables the DC voltage inside

the inverter. Wait five minutes before opening the cover. Otherwise, there is a

risk of electric shock from energy stored in the capacitors.

StorEdge Interface Installation Guide MAN-01-00621-1.1

5 HANDLING AND SAFETY INSTRUCTIONS

WARNING!

Do not remove the StorEdge Interface cover before five minutes have elapsed

after disconnecting all sources of power, and shutting OFFthe inverter and the

StorEdge Interface.

WARNING!

Before operating the system, ensure that the power cable and wall outlet have

been grounded properly.

WARNING!

When handling the battery, adhere to all manufacturer safety instructions.

WARNING!

The battery must be powered off before and during wiring.

To power off the battery:

1. Turn off the circuit breaker.

2. Turn off the disconnect/auxiliary power switch.

To power the battery back on:

1. Turn on the disconnect/auxiliary power switch.

2. Turn on the circuit breaker.

For details, see

Powering the LG Chem Battery Off and On

on page 24.

CAUTION!

This unit must be operated under the specified operating conditions as

described in the technical specifications supplied with the unit.

NOTE

The battery used must be NRTL certified.

NOTE

For battery decommissioning and disposal, follow the manufacturer

requirements and instructions.

NOTE

The StorEdge Interface is IP65 rated. Unused connectors and glands should be

sealed with the provided seals.

NOTE

The symbol appears at grounding points on the SolarEdge equipment. This

symbol may also be used in this manual.

HANDLING AND SAFETY INSTRUCTIONS 6

StorEdge Interface Installation Guide MAN-01-00621-1.1

Chapter 1: Overview

SolarEdge’s StorEdge™ solution for Smart Energy Management uses the StorEdge

Interface to connect the battery to the inverter.

Power is stored in the battery and can be used for various applications such as

maximized self-consumption and time of use profile programming. For backup power,

an inverter specifically designed for backup applications is required; this inverter is not

in the scope of this document.

The StorEdge Solution Components

The Inverter - manages the battery and system energy, in addition to its traditional

functionality as a DC-optimized PV inverter.

The Energy Meter - is used by the inverter for export, import, production and

consumption readings, and for Smart Energy Management applications, such as:

export limitation and maximizing self-consumption.

The StorEdge Interface - The StorEdge Interface connects the battery to the

inverter through fuses, and supplies control and monitoring signals to the battery

for operation.

One battery - a DC-coupled battery designed to work with the SolarEdge system.

StorEdge Interface Installation Guide MAN-01-00621-1.1

7 Chapter 1: Overview

Figure 1: StorEdge system components

NOTE

Additional SolarEdge inverters (without batteries) can be connected over

RS485. The inverters will participate in export limitation and Smart Energy

Management.

PV modules connected to power optimizers are not mandatory for charge/

discharge profile programming.

Additional References

This document describes basic system connection and configuration - PVsystem

(power optimizer strings), one inverter, one battery, and one meter.

For additional configuration options refer to the StorEdge Solution Applications -

Connection and Configuration Guide, available at:

Chapter 1: Overview 8

StorEdge Interface Installation Guide MAN-01-00621-1.1

https://www.solaredge.com/sites/default/files/storedge_applications_

connection_and_configuration_guide.pdf



If your inverter has an LCDdisplay (it is not SetApp configurable), refer to

this guide for StorEdge Interface installation and configuration:

https://www.solaredge.com/sites/default/files/storedge_interface_

installation_with_LG_and_HD_wave.pdf

Installation Workflow

When installing the StorEdge system, follow this workflow to ensure all the components

are connected and functioning correctly.

Plan the StorEdge system layout:

The battery and StorEdge Interface will connect to the DC side of the inverter.

Since the inverter DC connections are on its left side, it is recommended to

position the battery and interface to the left of the inverter to simplify wiring.

The total distance between the battery and the inverter, including StorEdge

Interface, should not exceed the maximum distance shown in the figure below:

Figure 2: System Layout

Step 1 - PVsystem installation - modules, power optimizers and inverter(s). Refer to the

following chapters of the

SolarEdge Installation Guide

supplied with the inverter and

available at https://www.solaredge.com/sites/default/files/se_hd_wave_

inverter_SetApp_installation_guide.pdf:

Installing the Power Optimizers (if applicable)

Installing the Inverter

Connecting the AC and the Strings to the Inverter

Activating the inverter- as described in the Commissioning chapter of the

SolarEdge

Installation Guide

, using the activation card supplied with the inverter.

Pairing the system - as described in the Commissioning chapter of the

SolarEdge

StorEdge Interface Installation Guide MAN-01-00621-1.1

9 Installation Workflow

Inhaltsverzeichnis

Andere SolarEdge Wechselrichter Handbücher

SolarEdge

SolarEdge storedge Bedienungsanleitung

SolarEdge

SolarEdge SE8K-N4 Bedienungsanleitung

SolarEdge

SolarEdge StorEdge Solution with Backup Bedienungsanleitung

SolarEdge

SolarEdge RESU10H Prime Series Bedienungsanleitung

SolarEdge

SolarEdge SE5000H-AU Bedienungsanleitung

SolarEdge

SolarEdge SEK-I Series Bedienungsanleitung

SolarEdge

SolarEdge SE7600A-US Bedienungsanleitung

SolarEdge

SolarEdge SE12.5k Bedienungsanleitung

SolarEdge

SolarEdge StorEdge SE7600A-US1 Bedienungsanleitung

SolarEdge

SolarEdge Power Optimizer Bedienungsanleitung

SolarEdge

SolarEdge Dry-Contact switch Bedienungsanleitung

SolarEdge

SolarEdge storedge Bedienungsanleitung

SolarEdge

SolarEdge Energy Bank Bedienungsanleitung

SolarEdge

SolarEdge Power Harvesting System Bedienungsanleitung

SolarEdge

SolarEdge SE3000H-US Bedienungsanleitung

SolarEdge

SolarEdge SE K Series Bedienungsanleitung

SolarEdge

SolarEdge StorEdge SE5000H-O4 Bedienungsanleitung

SolarEdge

SolarEdge StorEdge SE7600A-USS Bedienungsanleitung

SolarEdge

SolarEdge Home Hub Inverter Three Phase Bedienungsanleitung

SolarEdge

SolarEdge StorEdge SE5000-xxS0 series Bedienungsanleitung

SolarEdge

SolarEdge SE15K Bedienungsanleitung

SolarEdge

SolarEdge SE8000H-AU Bedienungsanleitung

SolarEdge

SolarEdge SE3000H-US Bedienungsanleitung

SolarEdge

SolarEdge Solar Inverter Bedienungsanleitung

Beliebte Wechselrichter Handbücher anderer Marken

Fourgroup

Fourgroup Easy Bedienungsanleitung

Velleman

Velleman PI300M Bedienungsanleitung

Sungrow

Sungrow SG350HX-US Bedienungsanleitung

WilTec

WilTec 61897 Bedienungsanleitung

SMA

SMA SUNNY BOY STORAGE 2.5 Bedienungsanleitung

Simplicity

Simplicity LANDLORD 316 Bedienungsanleitung

Santak

Santak SMAX 3000 Bedienungsanleitung

ATON

ATON RA.Store-3 Bedienungsanleitung

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Bedienungsanleitung

Tektronix

Tektronix CFG250 Bedienungsanleitung

Champion

Champion 200989 Bedienungsanleitung

Vanner

Vanner 20-500 Series Bedienungsanleitung

GE GEP Bedienungsanleitung

Astrel Group

Astrel Group Power Reducer Kurzanleitung

MULTIQUIP

MULTIQUIP GDP-5H Leitfaden

GoWISE

GoWISE PS1007 Bedienungsanleitung

Promate

Promate PM13500D ES Bedienungsanleitung

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Bedienungsanleitung
