Solplanet Ailogger Bedienungsanleitung


UM0033_Ai-Logger_EN_V02_0123                                                                   1
Table of Contents
Safety Precautions .................................................................................................................. 3
1 Safety instructions......................................................................................................... 3
2Personnel requirements................................................................................................. 3
3 System installation........................................................................................................ 3
4 Operation...................................................................................................................... 3
5 Maintenance and replacement .................................................................................... 3
Product overview.................................................................................................................... 4
1Product overview........................................................................................................... 4
2Networking application ................................................................................................ 4
3 Features ....................................................................................................................... 4
4 Appearance.................................................................................................................. 5
Device Installation .................................................................................................................. 6
1 Installation process ....................................................................................................... 6
2 Check before installation..............................................................................................7
3 Get installation tools ready...........................................................................................7
4 Choose an installation location.................................................................................... 8
5 Install Ai-Logger........................................................................................................... 9
5.1 Desktop installation ........................................................................................... 9
5.2 Wall-mounted installation ................................................................................10
5.3 Rail installation ..................................................................................................11
Electrical connection............................................................................................................. 13
1 Connection Instructions .............................................................................................. 13
2 Connecting to Inverter ............................................................................................... 14
2.1 Connect to Huatuo............................................................................................ 14
2.2 Connect to multiple inverters .......................................................................... 15
3 Connect to a smart meter........................................................................................... 16
4Connect through Ethernet cable ................................................................................. 16
5Connect to Ripple Control Receiver............................................................................ 17
System Operation.................................................................................................................. 19
1 System Power-On Process........................................................................................... 19
WEB interface operation....................................................................................................... 21
1 WEB interface description........................................................................................... 21
1.1 WEB page menu................................................................................................. 21
1.2 WEB interface layout ............................................................................................... 24
2 Prepare and log in to the WEB................................................................................... 24
3 Overview.................................................................................................................... 26
3.1 Plant operation information ............................................................................. 26
3.2 Fault warning................................................................................................... 26
3.3 System power generation ............................................................................... 26
3.4 Performance data.............................................................................................27
3.5 Device running information ............................................................................ 28
4 Device Monitoring ..................................................................................................... 28
4.1 Ai-Logger.......................................................................................................... 28

                                                                   UM0033_Ai-Logger_EN_V02_0123
4.2 Inverter ............................................................................................................ 28
4.4 Weather station............................................................................................... 36
4.5 Smart Meter .................................................................................................... 38
5 Settings ...................................................................................................................... 39
5.1 User Parameters ............................................................................................... 39
5.2 Communication parameters ............................................................................ 41
6 Maintenance .............................................................................................................. 42
6.1 Firmware upgrade............................................................................................ 42
6.2 Security Settings ............................................................................................. 43
6.3 Device Management ....................................................................................... 43
Grid dispatch ........................................................................................................................ 46
1 Power Regulation Instructions .................................................................................... 46
2Active power schedule .................................................................................................47
2.1 Unlimited............................................................................................................47
2.2 Dry contact remote control ............................................................................. 48
2.3 Fix active power percentage limited (open loop) ............................................ 48
2.4 Setting anti-backflow parameters ................................................................... 49
3 Reactive power regulation ......................................................................................... 50
3.1 No output.......................................................................................................... 50
3.2 Dry contact remote control ............................................................................. 50
3.3 Reactive power fixed value control .................................................................. 51
3.4 Power factor fixed value control.......................................................................52
3.5 Grid connection with limited power factor ......................................................52
Device Maintenance............................................................................................................. 53
1 Routine Maintenance.................................................................................................. 53
2 Troubleshooting ......................................................................................................... 53
Scrap Ai-Logger ................................................................................................................... 55
Technical data ..................................................................................................................... 55
Manage system domain name list ....................................................................................... 56
Contact Us........................................................................................................................... 56



UM0033_Ai-Logger_EN_V02_0123 3

1 Safety Precautions

1.1 Safety instructions

This section describes the safety precautions to be followed during the installation and

operation of the Ai-Logger.

1.2 Personnel requirements

1. Ai-Logger can only be operated by trained professional electrical technicians.

2. Operators should be quite familiar with the composition and working principle of the

entire grid-connected PV system, as well as the relevant standards of the

country/region where the project is located.

1.3 System installation

1. Before installing the Ai-Logger, make sure it is not electrically connected and powered

on.

2. Please install Ai-Logger in a well ventilated environment to ensure unaffected system

performance.

3. Please make sure that the cooling holes of the Ai-Logger are not blocked.

4. During the installation process, please do not touch other parts inside the case except

the terminals at the bottom of the box.

1.4 Operation

1.5 Maintenance and replacement

1. Ai-Logger is maintained as a whole unit, if there is any fault inside the case, please

contact your dealer.

2. To maintain Ai-Logger, you need to be familiar with and understand the contents of this

manual, and have appropriate tools and test equipment.

3. During the maintenance process, please observe electrostatic protection standards and

wear anti-static gloves.

Notice

●Operators should read this manual carefully. Equipment damage caused by storage,

handling, installation and use of Ai-Logger not in accordance with the contents of

this manual is not covered by the warranty.

Notice

●Please strictly follow the safety precautions listed in this manual and other related

documents

●When operating the equipment, obey local regulations and codes.

4 UM0033_Ai-Logger_EN_V02_0123

2 Product overview

Overview of functions, networking application, features, appearance and monitoring panel

of Ai-Logger.

2.1 Product overview

Functions: Ai-Logger is a special device for PV system monitoring and management

platform, with functions such as interface aggregation, protocol conversion, data

acquisition, data storage, centralized monitoring and centralized maintenance for each PV

system device.

2.2 Networking application

Ai-Logger is suitable for PV systems,

1. Can monitor AISWEI's inverters.

2. Support third-party weather station and smart meter access using standard MODBUS

protocol RS485 interface.

3. Support access to multi-function meters through DLT645 protocol.

The networking application of Ai-Logger, as shown in the figure

2.3 Features

Ai-Logger features centralized monitoring, graphic data, easy maintenance, grid dispatch,

and intelligent management.

1. Centralized monitoring

a) Centrally manage up to 80 devices.

b) The PV system can be monitored and managed through the embedded WEB

which can be used to view real-time information of power plants, equipment,

fault information and set remote parameters.

2. Graphic data

a) In addition to power information and real-time monitoring information, the

embedded WEB can also display power plant and equipment performance data

in graphic tables and curves.

3. Easy maintenance

a) Use the USB port to upgrade firmware and export data of Ai-Logger or inverter

by inserting a USB stick.

AISWEI Power Plant

Management System

Grid Dispatch Receiver

Smart meter

PV Array

Inverter

Grid

Dry Contact

Embedded Web

Environment Monitor

UM0033_Ai-Logger_EN_V02_0123 5

b) Use the embedded WEB to upgrade firmware and export data of Ai-Logger or

inverter.

4. Grid dispatch

a) Support grid dispatch and active power derating at the same time.

5. Intelligent management

a) Ai-Logger can automatically scan and identify AISWEI's inverters.

b) Equipment of third-party manufacturers can also be connected if it supports

the standard MODBUS-RTU protocol.

c) Ai-Logger can automatically assign RS485 addresses to connected inverters

and supports changing names according to device serial numbers for easy

remote configuration and maintenance.

d) Support remote setting of inverter parameters.

2.4 Appearance

Schematic overview of Ai-Logger

Front view

Top view

Back view

Bottom view

6 UM0033_Ai-Logger_EN_V02_0123

3 Device Installation

Below are Ai-Logger installation instructions, please read carefully to help you install this

product better.

Background information: Choose a suitable mounting location and mounting surface

3.1 Installation process

Ai-Logger installation process overview.

The installation process of Ai-Logger is shown in the figure.

Installation Process Description

Step

Operation

Description

Check before installation

Before unpacking, check outer packaging for

damage; after unpacking, check if anything is

missing and whether there is any obvious external

damage.

Ready to install tools

Before installing Ai-Logger, you need to have the

appropriate tools ready for smooth installation and

wiring.

Choose an installation

location

Choose an appropriate location and install Ai-

Logger to ensure that Ai-Logger can work normally

and efficiently.

Install Ai-Logger

Ai-Logger can be installed on desktops, walls and

rails.

Start

Check before

installation

Ready to install

tools

Choose an

installation location

Install Ailogger

End

UM0033_Ai-Logger_EN_V02_0123 7

3.2 Check before installation

Check outer packaging: Before unpacking the Ai-Logger, check the outer packaging for

visible damage such as holes, cracks, or other signs of possible internal damage. If

abnormal, do not open it, contact your dealer as soon as possible.

Check the delivery: After unpacking the Ai-Logger, please check the delivery to see if

anything is missing and whether there is any obvious external damage. In case of any

damage or if anything is missing, please contact your dealer.

Ai logger

WiFi antenna

3.3 Get installation tools ready

Before installing Ai-Logger, you need to have the appropriate tools ready for smooth

installation and wiring.

Tools

Reference picture

Model

User

Impact drill

When wall-

mounted, it is used

to punch holes in

the wall.

Diagonal plier

Cut the cable ties.

Wire stripper

Strip off the cable

skin.

Rubber hammer

Tap the expansion

bolts into the holes.

Utility knife

Unpacking etc.

8 UM0033_Ai-Logger_EN_V02_0123

Wire cutter

Cut the cable.

Marker

Making marks.

Vacuum cleaner

After drilling holes

in the wall, clean the

dust on the site.

Steel tape

Measure distance.

Safety goggles

It is worn by the

operator when

punching.

Dust mask

It is worn by the

operator when

punching.

3.4 Choose an installation location

Choose an appropriate location and install Ai-Logger to ensure that Ai-Logger can work

normally and efficiently.

Please take the following into consideration when selecting an installation location.

1. Ai-Logger is rated IP20, do not place Ai-Logger outdoors.

2. Do not place the Ai-Logger in an easily accessible environment to avoid damage to the

Ai-Logger.

3. The ambient temperature should be kept at -20℃~+60℃, and avoid direct sunlight.

4. The ambient humidity of the installation location cannot exceed 95%. Excessive

humidity may cause damage to internal components.

5. Ensure that the RS485 communication distance does not exceed 1000m, and the

Ethernet communication distance does not exceed 100m.

6. It is recommended to install the Ai-Logger at an appropriate height.

7. Do not turn Ai-Logger upside down. When the cooling holes are facing upward, dust

might fall in and affect the life of the Ai-Logger.

8. The installation method and location must be suitable for the weight and size of the Ai-

Logger.

9. Make sure the cable connection area is facing down when mounting on walls or rails.

UM0033_Ai-Logger_EN_V02_0123 9

10. The distance between Ai-Logger and surrounding objects should meet the following

conditions: the distance between the two sides is ≥500mm; the distance from the top is

≥500mm; the distance from the ground is ≥1500mm, as shown in the figure.

3.5 Install Ai-Logger

There are three installation methods for the Ai-Logger: desktop installation, wall-mounted

installation, and rail installation.

3.5.1 Desktop installation

How to install Ai-Logger on desktop

●First install the antenna by screwing clockwise in the thread on Ai-Logger, the

antenna can be bent 90°and rotated 360°after installation.

Inhaltsverzeichnis

Beliebte Datenlogger Handbücher anderer Marken

TESTO

TESTO 176 Bedienungsanleitung

HT Italia

HT Italia XL421 Bedienungsanleitung

HBM

HBM SOMAT XR CX22B-R Bedienungsanleitung

Agtrix

Agtrix 380i Bedienungsanleitung

Hobo

Hobo H8 Pro Bedienungsanleitung

Beijing ART Tech

Beijing ART Tech PCI2320 Bedienungsanleitung

Athena

Athena GET SL1 Bedienungsanleitung

Motec Systems

Motec Systems C185 Bedienungsanleitung

Beijing ART Tech

Beijing ART Tech USB2832 Bedienungsanleitung

Rotronic

Rotronic HygroLog HL20 Bedienungsanleitung

MRC

MRC DW-6092 Bedienungsanleitung

Racelogic

Racelogic VBOX LapTimer Bedienungsanleitung

Edu-Logger

Edu-Logger 900-240 Bedienungsanleitung

Elma

Elma DT173 Bedienungsanleitung

MadgeTech

MadgeTech PRTemp140 Technisches Datenblatt

Comet

Comet U0121M Bedienungsanleitung

pico Technology

pico Technology PT-104 Bedienungsanleitung

Soil Instruments

Soil Instruments GTecLink Bedienungsanleitung
