SOMFY INSTRUCTIONS

TELIS RTS REMOTE CONTROLS

SINGLE & FIVE CHANNEL

Part #’s

1810632 Telis 1 RTS Pure

1810633 Telis 5 RTS Pure

1810639 Telis 1 RTS Silver

1810641 Telis 5 RTS Silver

1810650 Telis 1 RTS Lounge

1810652 Telis 5 RTS Lounge

1810643 Telis 1 RTS Patio

1810645 Telis 5 RTS Patio

Channel

Selector

Programming

Button

STOP

DOWN

BACKFive Channel

Version

STOP

DOWN

Single Channel

Version

LED

Indicator

Light

LED Lights

PROGRAMMING – ADDING A NEW REMOTE OR OPERATING CHANNEL

Adding a Telis 1 RTS Transmitter only:

1. Using the previously programmed Telis

remote, press and hold the programming

button on back of remote until

window covering “jogs.”

Adding a Telis 5 RTS Transmitter only:

1. Using the previously programmed Telis

remote, press and hold the programming

button on back of remote until window

covering “jogs.”

2. Using the new Telis 1 remote,

briefly press the programming

button until the window covering

“jogs.” Window covering has

now learned the commands of

the new Telis remote.

A previously programmed remote can be used in order to add a new remote or channel to the Motorized Window Covering.

If a Telis Transmitter has not been previously programmed, please refer to the installation instructions of the relevant RTS

motorized window covering.

C-0001

Pen

BACK VIEW

Programming

Button

Pen

BACK VIEW

Programming

Button

Pen

2. Using the new Telis 5 remote, select

the desired channel using the CHANNEL

SELECTOR BUTTON. (The LED will illuminate

each time the Channel Selector Button is

pressed, indicating the selected channel)

3. Using the Telis 5 remote, briefly press the

programming button until the motorized

window covering “jogs”. The RTS motorized

window covering has now learned the

commands of the new Telis 5 remote.

Previously

programmed remote

New Telis 1

remote to be added

Channel

Selector

BACK VIEW

Programming

Button

Pen

PAGE 1 REV 6

LED Lights

New Telis 5

remote to

be added

BACK VIEW

Programming

Button

Pen

Previously

programmed remote

my my

NOTE: IN CASE OF A LOST TRANSMITTER, PROFESSIONAL PROGRAMMING ASSISTANCE IS REQUIRED. PLEASE CONTACT SOMFY

AT somfytech@somfy.com OR YOUR LOCAL DEALER AT www.somfysystems.com/locatedealer.

REPLACING THE BATTERY

1. Using a small screwdriver loosen the

screws on the reverse side of the remote

control and remove the back cover.

2. Replace the battery with one

2430 Lithium 3V battery.

PROGRAMMING - SETTING A FAVORITE POSITION (MY)

2. Press ans hold the “MY” ( ) Button until the

window covering “jogs.” Favorite position is

now recorded.

Telis 1 RTS Transmitter only:

1. Using the UP ( ) or DOWN ( ) Buttons,

activate the window covering to a desired

position, for example halfway Open or

Closed. Briefly press the “MY” ( ) (stop)

Button to stop the window covering

once position is reached.

C-0001

In addition to standard OPEN and CLOSE features, the Telis remote enables the user to pre-establish a favorite stop location. a.k.a. “MY”

favorite position. An example could be to command the RTS motorized window covering to a 50% or 75% open or closed position

when the “MY” button is briefly pressed.

Telis 5 RTS Transmitter only:

1a. Using the Telis 5 remote, select the

appropriate channel using the CHANNEL

SELECTOR BUTTON. (The LED lights will

illuminate each time the Channel Selector

Button is pressed, indicating the selected

channel)

1b. Using the UP ( ) or DOWN ( )

Buttons, activate window covering

to a desired position, for example

halfway Open or Closed. Briefly

press the “MY” ( ) (stop) Button

to stop the window covering once

position is reached.

Telis 1 RTS Transmitter only:

1. Use the UP ( ) or DOWN ( )Buttons to

open or close the window covering.

If a specific position is necessary,

briefly press the “MY” ( ) (stop)

Button to stop the window covering

once position is reached.

Telis 5 RTS Transmitter only:

1. Using the Telis 5 remote, select

the appropriate channel using the

CHANNEL SELECTOR BUTTON. (The LED

lights will illuminate each time the

Channel Selector Button is pressed,

indicating the selected channel)

2. Using the UP ( ) or DOWN ( )

Buttons to open or close the

window covering. If a specific

position is necessary, briefly press

the “MY” (stop) ( ) Button to

stop the window covering once

position is reached.

Channel

Selector

LED Lights

Channel

Selector

LED Lights

my my

3. Favorite “MY” ( ) position can be activated

from any previous window covering position.

Example: Briefly press the “MY”( ) button

while window coverings in a Open or Closed

position.

OPERATING THE MOTORIZED WINDOW COVERING

Note: Activating window covering to a

Favorite position while already “in-motion”

will require two brief presses of the “MY”

(stop) button.

Window covering MUST BE in a stationary

(Stopped) position before the “MY” favorite

position can be activated.
