Sonible D24 Bedienungsanleitung

d:24

owner‘s manual

d:24 owner‘s manual 2

sonible og

Brockmanngasse 6 / 14

8010 Graz

Austria

+43 316 / 91 22 88

[email protected]

www.sonible.com

manual version 1.0

rmware version v1.0.0

Graz, 10.07.2015

3d:24 owner‘s manual

TABLE OF CONTENTS

1 Important Safety Instructions 4

1.1 Important Service Instructions

1.2 WEEE Recycling / Disposal Instructions

2 Introduction 8

2.1 Main Features

2.2 Unpacking and Inspection

2.3 Scope of Delivery

2.4 Responsibility of the User

3 Installation & Common Caveats 14

3.1 Mounting

3.2 Air flow and thermal management

3.3 Protection Circuitries

4 Overview 18

4.1 Front panel

4.2 Rear panel

5 Control Surface 24

5.1 Meter screen

5.2 System Screen

5.3 Network screen

5.4 Stealth Screen

6 Remote Control 34

7 Panic mute switch 36

8 Pinouts of Connectors 38

8.1 DSub25

8.2 speakON NL8

8.3 Bridging

9 Maintenance & Update 40

9.1 Maintenance

9.2 Firmware update

10 Specifications 42

11 Signal Flow 44

12 Mechanics & Dimensions 45

13 Declaration of Conformity 46

13.1 CE Declaration of Conformity

13.2 RoHS

13.3 WEEE / Note on Disposal

14 Warranty 48

15 Legal Disclaimer 49

d:24 owner‘s manual 4

1 IMPORTANT SAFETY INSTRUCTIONS

The lightning flash with arrowhead symbol, within

an equilateral triangle is intended to alert the user

to the presence of uninsulated ”dangerous volta-

ge” within the product’s enclosure that may be of

sufcent magnitude to constitute a risk of electric

shock to persons.

WARNING: To reduce the risk of re or electrical shock, do not

expose this appliance to rain or moisture.

AVIS: Risqué De Choc Electrique – Ne Pas Ouvrir

CAUTION: To reduce the risk of electrical shock, grounding of

the centre pin of the power plug must be maintained.

This equipment conforms to the require-

ments of the EMC Directive 2004/108/

EC and the requirements of the Low

Voltage Directive 2006/95/EC. Standards

applied: EMC Emission EN55103-1, E3

EMC Immunity EN55103-2, E3, with S/N

below 1% at normal operation level. Elec-

trical Safety EN60065, Class I

FOR

RECYCLING

INFORMATION

VISIT:

www.sonible.com

The exclamation point within an equilateral triang-

le is intended to alert the user to the presence of

important operating and maintance (servicing) ins-

tructions in the literature accompanying the appli-

ance.

5d:24 owner‘s manual

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not cover any ventilation openings. Install in accordance with

the manufacturer’s instructions.

8. Do not install near heat sources such as radiators, heat registers,

stoves, or other apparatus (including ampliers) that produce heat.

9. Do not defeat the safety purpose of the polarized or the groun-

ding-type plug. A polarized plug has two blades with one wider than

the other. A grounding type plug has two blades and a third groun-

ding prong. The wide blade or the third prong are provided for your

safety. If the provided plug does not t into your outlet, consult an

electrician for replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched par-

ticularly at plugs, convenience receptacles, and the point where

they exit from the apparatus.

11. Only use attachments/accessories specied by the manufac-

turer.

12. Use only with the cart, tripod, bracket, or table

specied by the manufacturer, or sold with the appa-

ratus. When a cart is used, use caution when moving

the cart/apparatus combination to avoid injury from

tip-over.

13. Unplug this apparatus during lightning storms or when unused

for a long period of time.

14. Refer all servicing to qualied service personnel. Servicing is

required when the apparatus has been damaged in any way, such

as power-supply cord or plug is damaged, liquid has been spilled

or orbjects have fallen into the apparatus, the apparatus has been

exposed to rain or moisture, does not operate normally, or has been

dropped.

15. Do not expose this equipment to dripping or splashing and

ensure that no objects lled with liquids, such as vases, are placed

on the equipment.

16. To completely disconnect this equipment from the AC Mains,

disconnect the power supply cord plug from the AC receptacle.

17. The mains plug of the power supply cord shall remain readily

operable.

18. No naked flame sources, such as lighted candles, should be

placed on the apparatus.

19. The product should be connected to a mains socket outlet with

a protective earthing connection.

d:24 owner‘s manual 6

1.1 Important Service Instructions

CAUTION: These servicing instructions are for use by qualied personnel only. To reduce the risk of electric shock, do not perform

any other servicing than that contained in the owner‘s manual unless you are qualied to do so. Refer all servicing to qualied service

personnel.

1. Security regulations as stated in the EN 60065 (VDE 0860 / IEC

65) and the CSA E65 - 94 have to be obeyed when servicing the

appliance.

2. Use of a mains separator transformer is mandatory during main-

tenance while the appliance is opened, needs to be operated and is

connected to the mains.

3. Switch off the power before retrotting any extensions, changing

the mains voltage or the output voltage.

4. The minimum distance between parts carrying mains voltage

and any accessible metal piece (metal enclosure), respectively bet-

ween the mains poles has to be 3mm and needs to be minded

at all times. The minimum distance between parts carrying mains

voltage and any switches or breakers that are not connected to the

mains (secondary parts) has to be 6 mm and needs to be minded

at all times.

5. Replacing special components that are marked in the circuit dia-

gram using the security symbol (Note) is only permissible when

using original parts.

6. Altering the circuitry without prior consent or advice is not legiti-

mate.

7. Any work security regulations that are applicable at the locations

where the appliance is being serviced have to be strictly obeyed.

This applies also to any regulations about the work place itself.

8. All instructions concerning the handling of MOS-circuits have to

be observed.

SAFETY COMPONENT

(MUST BE REPLACED BY ORIGINAL PART)

7d:24 owner‘s manual

1.2 WEEE Recycling / Disposal Instructions

The Wheelie Bin symbol found on the product or in the manual in-

dicates that this product must not be disposed of with other waste.

It is in our category the manufacturer’s responsibility to properly

dispose of their waste electrical and electronic equipment (WEEE)

at the end of its life. Due to the differences in each EU country’s ma-

nagement of WEEE, please contact your local distributor. We are

committed to facilitate our own electronic-waste-management-

system, for the free of charge return of all sonible OG products.

Arrangements are made with the dealer where you purchased the

equipment from, for the returning of all unusable equipment at no

cost, to the factory in Graz, for environmental protective disposal.

Due to line current harmonics, we recommend that you contact

your supply authority before connection.

d:24 owner‘s manual 8

2 INTRODUCTION

Thank you for choosing sonible d:24 for your sound reinforcement

system installation.

The sonible d:24 is a no compromise 24 channel power amplier

for high-end multichannel setups. With its clear focus on profes-

sional interfacing, audio quality and minimum packing density, the

d:24 offers high flexibility in different application scenarios.

Whether you are planning to use the d:24 in a xed installation se-

tup, for acoustical measurements or during live concerts, we built

the amp for durability, reliability and compatibility. We are condent

that you will be pleased with the benets and overall quality of this

innovative and versatile amp.

This manual will guide you through the features and functionalities

of the multichannel amp. Please read this manual carefully to be-

come fully acquainted with the conguration options and control

layers of the amp.

Please feel free to contact us and send any questions, comments

and suggestions to [email protected].

We are looking forward to hearing from you!

9d:24 owner‘s manual

2.1 Main Features

The d:24 provides a number of features and technologies that offer

you maximum flexibility to realize sophisticated projects in sound

reinforcement.

compactness

Using high grade class D amplifying technology and very efcient

switch mode power supplies, the d:24 provides you a unique

packing density. With 24 mid-range amplication channels packed

in a 3RU housing, optional digital inputs and with a weight of less

than 20kg, the d:24 is the clear technological leader in the market.

user interface

The d:24 can conveniently be congured and monitored via a

7“ touch display.

remote

When connected to a LAN, the d:24 can be remote controlled via an

interactive web application.

protection

The d:24 incorporates several security precautions.

• DC error, over current and over voltage protection at the spe-

aker outputs to avoid damage of speakers and ampliers

• low inrush circuitry for soft startup of the system (this ensures

that the main fuse does not trip if one or more power ampli-

ers are switched on simultaneously)

• dedicated hardware panic mute connection

options

The analog d:24 main frame can optionally be equipped with a

MADI in/output card called “mio” or a DANTE® network in/output

card called “dio”.

d:24 owner‘s manual 10

2.2 Unpacking and Inspection

Carefully open the packing and take out the power amplier. In-

spect the power amp’s enclosure for damages that might have

happened during transportation. Each amplier is examined and

tested in detail before leaving the manufacturing site to ensure

that it arrives in perfect condition at your place. Please inform the

transport company immediately, if the power amplier shows any

damage. Being the addressee, you are the only person who can

claim damages in transit. Keep the cardboard box and all packing

materials for inspection by the transport company.

Please do not ship the power amp in any other but its original packing!

Keeping the cardboard box including all packing materials is also

recommended, if the power amplier shows no external damages.

When shipping the power amp, make sure to always use its original

box and packing materials. Packing the power amplier like it was

packed by the manufacturer guarantees optimum protection from

transport damage.

Andere Handbücher für d24

Inhaltsverzeichnis

Andere sonible Aufnahmegeräte Handbücher

sonible

sonible missing link ml:1 Gebrauchs- und Pflegehandbuch

Beliebte Aufnahmegeräte Handbücher anderer Marken

KV2 Audio

KV2 Audio 500 Series Bedienungsanleitung

Robotics Technologies

Robotics Technologies microBus-Cam II Bedienungsanleitung

Seca

Seca 460 Bedienungsanleitung

Cognex

Cognex MVS-8000 Series Bedienungsanleitung

Mect

Mect MPNC006 Series Bedienungsanleitung

Bad Caf

Bad Caf THE LEASH Bedienungsanleitung

Strymon

Strymon NIGHTSKY Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric 16CH DIGITAL RECORDER DX-TL5000U Bedienungsanleitung

Tews Technologies

Tews Technologies TPMC465 Bedienungsanleitung

Honeywell

Honeywell Excel 50 Bedienungsanleitung

SeaLevel

SeaLevel COMM+8.LPCI Bedienungsanleitung

Arturia

Arturia AUDIOFUSE STUDIO Bedienungsanleitung

Rukra

Rukra RK-1240 Bedienungsanleitung

Samson

Samson SCOM Bedienungsanleitung

Dynacord

Dynacord DPS260 Bedienungsanleitung

Nice

Nice Core Bedienungsanleitung

Pyle Pro

Pyle Pro PSS8 Bedienungsanleitung

RF-System

RF-System TinyGate Gebrauchs- und Pflegehandbuch

sonible d24 Bedienungsanleitung

Beliebte Aufnahmegeräte Handbücher anderer Marken
