Sonoff B02 Bedienungsanleitung
SONOFF TECHNOLOGIES CO., LTD. English
5
1. Install the device
OFF
The device works under 220-240V AC only.
2. Download APP
3. Power on
→ → → → →
1S 1S 1S 1S 1S
Operating Instruction
To avoid electric shock, please turn off the power before installing the device.
eWeLink
eWeLink
Android™ & iOS
After powering on, the device will enter the quick pairing mode (Touch) during the
first use. The device enters the “breathing mode”.
The device will exit the quick pairing mode (Touch) if not paired within 3mins. If
you want to enter this mode, please press the manual switch three times repeatedly
at an interval of every 1s (Off-ON-Off-ON-Off-ON). The "breathing mode" indicates
the light enters quick pairing mode.
SONOFF TECHNOLOGIES CO., LTD. English
6
4.Add the device
Select Wi-Fi SSID with ITEAD-****** and enter the password 12345678, and then
go back to eWeLink APP and tap “Next”. Be patient until pairing completes.
2. Tap “+” and select “ Compatible Pairing Mode ” on APP.
Sca n QR co de
GSM dev ices an d devic es with Q R co
de can be a dded in t his mod e.
Sou nd Pa ir ing
Add dev ice in th is mode i f your
devic e s uppor t this fe ature .
QuickPairing
WIFIdevicescanbeaddedinthismo
de(makesurethedeviceisinpairin g
mode).
AddDevice
Tap “+” and select “ Quick Pairing ”, then operate following the prompt on the app.
If you fail to enter Quick Pairing Mode (Touch), please try “Compatible Pairing Mode ”
to pair.
Compatible Pairing Mode
1. Press the light switch 5 times repeatedly at an interval of every 1s (Off-ON-Off-ON-
Off-ON-Off-ON-Off-ON) when the light is on. The "quick flash" indicates the device
enters the compatible pairing mode.
Usage of being an ordinary bulb
Power on the bulb, it will enter quick pairing mode (The bulb change from bright to
dim and cycle the mode), after 10s, if power off, it will go solid and keep warm light
at the highest brightness.
SONOFF TECHNOLOGIES CO., LTD. English
7
Lampshade
E27 lamp screw base
Product Introduction
B02-B-A60/B05-B-A60
220-240V AC 50Hz
806Lm
2700K-6500K
9W
≥Ra80
E27
60x118mm
B02-B-A60:60g/B05-B-A60:63g
10000h
Android&iOS
IEEE802.11b/g/n2.4GHz
B02-B-A60 is a dual-color LED smart bulb. B05-B-A60 is a RGB LED smart bulb.
Heatsink
Color temperature
Rated power
Weight
Lamp base
CRI
Wi-Fi
Life Expectancy
Dimension
Luminous Flux
Input
Model
Operating systems
Specifications
SONOFF TECHNOLOGIES CO., LTD. English
8
SONOFF LED is a LED smart bulb that allows users to adjust the brightness and color,
and remotely turn on/off the connected devices via your smartphone, schedule it
on/off and share it to your family to control together.
Stepless dimming Group control
Scene Mode
Press the light switch 3 times repeatedly at an interval of every 1s (Off-ON-Off-ON-
Off-ON) when the light is on. The "breathing mode" indicates the device enters the
quick pairing mode (Touch).
→ → → → →
1S 1S 1S 1S 1S
Why my device stays “Offline”?
Camera Feature
Remote Control Single/Countdown
Timing
Share Control
Voice Control
Sync Status
Please reset the device to factory defaults if you want to use other Wi-Fi networks,
then reconnect the network.
Factory Reset
Common Problems
① Maybe you have entered a wrong Wi-Fi password.
② Maybe there's too much distance between the switch your router or the environment
causes interference, consider getting close to the router. If failed, please add it
again.
③ The 5G Wi-Fi network is not supported and only supports the 2.4GHz wireless
network.
④ Maybe the MAC address filtering is open. Please turn it off.
Features
Smart scene
If none of the a bov e met hods solved the problem , you can open the mobile
datanetwork on your phone to create a Wi-Fi hotspot, then add the device again.
Shenzhen Sonoff Technologies Co., Ltd.
MADE IN CHINA
https://sonoff.tech/usermanuals
Hereby, Shenzhen Sonoff Technologies Co., Ltd. declares that the radio equipment
type B02-B-A60/B05-B-A60 is in compliance with Directive 2014/53/EU.The full
text of the EU declaration of conformity is available at the following internet address:
1001, BLDG8, Lianhua Industrial Park, shenzhen, GD, China
ZIP code: 518000 Website: sonoff.tech
PF
>0.5 ≥80
Ra Hg
10000Hrs
