Sonoff SNZB-01 Bedienungsanleitung

SNZB-01

User manual V 1.0

Wireless Switch

eWeLink

The device can be operated intelligently via working with the

SONOFF ZigBee Bridge to communicate with other devices.

The device can work wit h other gateways supporting ZigBee 3. 0

wireless protocol. Detailed information is in accordance with the

ﬁnal product.

Operation instruction

1. Download APP

2. Pull out the battery insulation sheet

CR2450

3. Add sub-devices

Connect the Bridge before adding the sub-device

Access eWeLink APP, select the Bridge that you want to connect,

and tap “Add” to add a sub-device. Then long press “RST” reset

button on the device for 5s until the LED indicator ﬂashes three

times, which means the device has entered the pairing mode, and

be patient until pairing completes.

ZBB rid ge

Add ed: 0

No ch ild de vice, pleas e add.

Add

If the addition failed, move the sub-device closer to the Bridge and try again.

Specifications

Model

Battery model

Working voltage

Wireless connection

Working temperature

Working humidity

Material

Dimension

SNZB-01

CR2450

ZigBee (IEEE 802.15.4)

-10~40℃

10-90%RH (non-condensing)

43x43x16mm

CR2450

Reset button LED indicator

Manual switch

SNZB-01 is a ZigBee low-energy wireless switch that allows you to

move to any place. Peel and stick. Connect it with the Bridge and

you can create a smart scene to trigger other devices.

Low-energy Low battery notification Smart scene

You can select to press once, press twice or long press the wireless

switch to control the connected device for various functions.

Product Introduction

Features

Button action instruction

Conne cting

Kee p the de vic e clo se

eno ugh to t he hu b.

25s

Add Devic e

Loo king f or dev ice

3 devices Found

SONOFF ZigBee Bridge supports

connecting multiple sub-devices at the

same time.

Power the Bridge on, access the Bridge page in the eWeLink APP,

and tap “Add”. Then set the sub-device to be paired to the pairing

mode, and be patient until the pairing completes.

ZBB rid ge

Add ed: 0

No ch ild de vice, pleas e add.

Add

Delete sub-devices

Long press the reset button on the sub-device for 5s until the LED

indicator flashes three times. In this case, the sub-device is deleted

from the Bridge successfully.

Users can delete sub-devices directly from the sub-device page on APP.

CR2450

1. Placed on the desktop for use.

2. Tear off the protective film of the 3M adhesive and stick the

device on the desired area.

Do not install on the metal surface, otherwise it will affect the wireless

communication distance.

Installation methods

The device weight is less than 1 kg.

The installation height of less than 2 m is recommended.
