Sony Ericsson K600i Bedienungsanleitung

This is the Internet version of the user's guide. © Print only for private use. 1

Contents Sony Ericsson K600i

Getting started . . . . . . . . . . . . . . . . . . 4

Assemble the phone, SIM card, battery, make

a call.

Getting to know your phone . . . . . . . . 8

Phone overview, use the menus, enter letters,

activity menu, file manager.

Calling . . . . . . . . . . . . . . . . . . . . . . . . 18

Calls, video calls, contacts, voice control,

call options.

Messaging . . . . . . . . . . . . . . . . . . . . . 37

Text messaging, picture messaging, voice messaging,

email, My friends.

Imaging . . . . . . . . . . . . . . . . . . . . . . . 47

Camera, video recorder, pictures, PhotoDJ™.

Entertainment . . . . . . . . . . . . . . . . . . 52

Media player, radio, PlayNow™, ringtones, MusicDJ™,

VideoDJ™, sound recorder, themes, games.

Connectivity . . . . . . . . . . . . . . . . . . . . 62

Internet and email settings, browsing, synchronizing,

Bluetooth, infrared, USB cable.

More features . . . . . . . . . . . . . . . . . . . 72

Time and date, alarm clock, calendar, tasks, Java™

applications, SIM card lock, etc.

Troubleshooting . . . . . . . . . . . . . . . . . 81

Why doesn’t the phone work the way I want?

Additional information . . . . . . . . . . . . 86

Sony Ericsson Consumer Web site, safe and efficient

use, warranty, declaration of conformity.

Icons . . . . . . . . . . . . . . . . . . . . . . . . . 94

Icon descriptions

Index . . . . . . . . . . . . . . . . . . . . . . . . . 96

This is the Internet version of the user's guide. © Print only for private use.

Sony Ericsson

UMTS-GSM 900/1800/1900

First edition (April 2005)

This user guide is published by Sony Ericsson

Mobile Communications AB, without any warranty.

Improvements and changes to this user guide

necessitated by typographical errors, inaccuracies

of current information, or improvements to programs

and/or equipment, may be made by Sony Ericsson

Mobile Communications AB at any time and without

notice. Such changes will, however, be incorporated

into new editions of this user guide.

©Sony Ericsson Mobile Communications AB, 2005

Publication number: EN/LZT 108 7739 R1A

Please note:

Some of the services in this user guide are not

supported by all networks. This also applies to

the GSM International Emergency Number 112.

Please contact your network operator or service

provider if you are in doubt whether you can use

a particular service or not.

Please read the Guidelines for safe and efficient

use and the Limited warranty chapters before you

use your mobile phone.

Your mobile phone has the capability to download,

store and forward additional content, e.g. ringtones.

The use of such content may be restricted or prohibited

by rights of third parties, including but not limited to

restriction under applicable copyright laws. You,

and not Sony Ericsson, are entirely responsible for

additional content that you download to or forward

from your mobile phone. Prior to your use of any

additional content, please verify that your intended

use is properly licensed or is otherwise authorized.

Sony Ericsson does not guarantee the accuracy,

integrity or quality of any additional content or any

other third party content. Under no circumstances will

Sony Ericsson be liable in any way for your improper

use of additional content or other third party content.

The Bluetooth word mark and logos are owned by

the Bluetooth SIG, Inc. and any use of such marks by

Sony Ericsson is under license.

3GPP is a trademark of ETSI in France and other

jurisdictions.

QuickShare™, PlayNow™, MusicDJ™, PhotoDJ™

and VideoDJ™ are trademarks or registered

trademarks of Sony Ericsson Mobile

Communications AB.

Real is a trademark or a registered trademark

of RealNetworks, Inc.

Microsoft, Windows and PowerPoint are either

registered trademarks or trademarks of Microsoft

Corporation in the U.S and other countries.

This is the Internet version of the user's guide. © Print only for private use. 3

Mac OS is a trademark of Apple Computer, Inc.,

registered in the U.S. and other countries.

T9™ Text Input is a trademark or a registered

trademark of Tegic Communications.

T9™ Text Input is licensed under one or more of

the following: U.S. Pat. Nos. 5,818,437, 5,953,541,

5,187,480, 5,945,928, and 6,011,554; Canadian Pat.

No. 1,331,057, United Kingdom Pat. No. 2238414B;

Hong Kong Standard Pat. No. HK0940329; Republic

of Singapore Pat. No. 51383; Euro.Pat. No. 0 842

463(96927260.8) DE/DK, FI, FR, IT, NL, PT, ES, SE,

GB; and additional patents are pending worldwide.

Java and all Java based trademarks and logos are

trademarks or registered trademarks of Sun

Microsystems, Inc. in the U.S. and other countries.

End-user license agreement for Sun™ Java™ J2ME™.

1Restrictions: Software is confidential copyrighted

information of Sun and title to all copies is retained

by Sun and/or its licensors. Customer shall not

modify, decompile, disassemble, decrypt, extract,

or otherwise reverse engineer Software. Software

may not be leased, assigned, or sublicensed, in

whole or in part.

2Export Regulations: Software, including technical

data, is subject to U.S. export control laws, including

the U.S. Export Administration Act and its associated

regulations, and may be subject to export or import

regulations in other countries. Customer agrees to

comply strictly with all such regulations and

acknowledges that it has the responsibility to obtain

licenses to export, re-export, or import Software.

Software may not be downloaded, or otherwise

exported or re-exported (i) into, or to a national

or resident of, Cuba, Iraq, Iran, North Korea, Libya,

Sudan, Syria (as such listing may be revised from

time to time) or any country to which the U.S. has

embargoed goods; or (ii) to anyone on the U.S.

Treasury Department's list of Specially Designated

Nations or the U.S. Commerce Department's Table

of Denial Orders.

3Restricted Rights: Use, duplication or disclosure

by the United States government is subject to the

restrictions as set forth in the Rights in Technical

Data and Computer Software Clauses in DFARS

252.227-7013(c) (1) (ii) and FAR 52.227-19(c)

(2) as applicable.

Contains Macromedia® Flash™ technology by

Macromedia, Flash, Macromedia Flash, and

Macromedia Flash Lite are trademarks or registered

trademarks of Macromedia, Inc. in the United States

and other countries.

Other product and company names mentioned herein

may be the trademarks of their respective owners.

Any rights not expressly granted herein are reserved.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

Assemble the phone, SIM card, battery, make

a call.

More information and downloads are available

at www.SonyEricsson.com/support.

Instruction symbols

The following instruction symbols appear in this

user guide:

Assembling the phone

Before you can use your phone you need to:

• Insert the SIM card.

• Attach and charge the battery.

SIM card

When you register as a subscriber with a network

operator, you get a SIM (Subscriber Identity Module)

card. The SIM card contains a computer chip that

keeps track of your phone number, the services

included in your subscription, and names and

numbers in your contacts, among other things.

Note

Indicates that a service or function is network-

or subscription-dependent. Contact your

network operator for details.

% See also page ...

} Use the selection keys or the navigation

key to scroll and select, %11 Keys and

navigation.

Press the navigation key centre.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

If you have been using a SIM card in another phone,

make sure that your information is saved to the SIM card

before you remove it from the other phone. For example,

contacts may have been saved in the phone memory.

This is the Internet version of the user's guide. © Print only for private use. 5

Getting started

SIM card and battery

information

Always turn off the phone and detach the charger

before you insert or remove a SIM card.

To insert SIM card and battery

1Remove the battery cover by sliding the two

catches on the side of the phone and lifting

it away as shown in the picture.

2Slide the SIM card into its holder. Make sure

that the gold contacts of the SIM card are facing

down, and the cut off corner is correctly aligned.

3Place the battery on the back of the phone with

the label side up and the connectors facing

each other.

4Place the battery cover as shown in the picture

and slide the two catches back into place.

It may take up to 30 minutes before the battery icon

appears when charging.

This is the Internet version of the user's guide. © Print only for private use.

Getting started

To charge the battery

1Connect the charger to the phone. The symbol

on the charger plug must face upwards.

2It may take up to 30 minutes before the battery

icon appears on the screen.

3It takes approximately 2 hours until the battery

icon indicates that the battery is fully charged.

If you do not see the battery icon after this time,

press a key to activate the screen.

4Remove the charger by tilting the plug upwards.

PIN (Personal Identification Number)

You may need a PIN (Personal Identification

Number) to activate the services in your phone. The

PIN is associated with your SIM card, and not with

the phone. Your PIN is provided by your network

operator. When you enter your PIN, each digit

appears as *, unless your PIN starts with the same

digits as an emergency number, for example 112.

This is so that you can see and call an emergency

number without entering a PIN.

If you make a mistake while entering your PIN,

delete the number by pressing .

If you enter the wrong PIN three times in a row, the

SIM card is blocked and the message PIN blocked

appears. To unblock it, you need to enter your PUK

(Personal Unblocking Key), %78 SIM card lock.

This is the Internet version of the user's guide. © Print only for private use. 7

Getting started

Turning on the phone and

making calls

Make sure that the phone is charged and your SIM

card is inserted before you turn it on. When you have

turned the phone on, you can use the setup wizard

to quickly and easily prepare your phone for use.

To turn on the phone

1Press and hold .

2Enter your SIM card PIN, if requested.

3At first start-up, select the language you want

for your phone menus.

4}Yes if you want the setup wizard to help you

get started, and follow the instructions that

appear. You can start the wizard from the menu

system at any time, }Settings }the General tab

}Setup wizard.

To make and receive calls

Enter the phone number (with international prefix

and area code if applicable) }Call to make the call,

or press to make a video call. }End call to

end the call. When the phone rings }Answer.

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone

Getting to know your

phone

Phone overview, use the menus, enter letters,

activity menu, file manager.

Phone overview

8 14 15

12 17 18

1Infrared port

2Ear speaker

3Screen

4Video call key

5, 10 Selection keys

6Back key

7Power on/off button

8Video call camera

9Activity menu

11 Navigation key

12 Clear key

13 Silent key

14 Camera button

15 Camera zoom, volume buttons

16 USB port

17 Microphone

18 Stereo headset and charger connector

For more information on keys and navigation, %11 Keys and

navigation.

This is the Internet version of the user's guide. © Print only for private use. 9

Getting to know your phone

PlayNow™* Internet services* Entertainment

Media player

Online services*

Games

VideoDJ™

PhotoDJ™

MusicDJ™

Remote control

Record sound

Demo tour

Camera Messaging Radio

Write new

Inbox

My friends*

Call voicemail

Drafts

Outbox

Sent messages

Saved messages

Templates

Settings

File manager Contacts Video call

Pictures

Videos

Sounds

Themes

Web pages

Games

Applications

Other

Contacts**

Options:

Speed dial

My business card

Groups**

SIM contacts**

Special numbers

Advanced

New contact

This is the Internet version of the user's guide. © Print only for private use.

Getting to know your phone

Calls Organizer

All Answered Dialled Missed

Alarms

Applications

Calendar

Tasks

Notes

Synchronization

Timer

Stopwatch

Light

Calculator

Code memo

Settings

General

Profiles

Time & date

Language

Voice control

New events

Phone status

Shortcuts

Start-up menu

Locks

Setup wizard

Tips and tricks

Master reset

Sounds & alerts

Ring volume

Ringtone

Silent mode

Increasing ring

Vibrating alert

Message alert

Key sound

Display

Wallpaper

Themes

Start-up screen

Screen saver

Brightness

Sleep mode clock

Edit line names*

Calls

Divert calls

Switch to line 2*

Manage calls

Time & cost

Show or hide no.

Handsfree

Connectivity

Bluetooth

Infrared port

Synchronization

Device mgmt.

Mobile networks

Data comm.

Internet settings

Streaming settings

Settings for Java™

Accessories

* Please note that some menus are operator-, network- and subscription-dependent.

**The menu depends on which contacts application is selected as default.

Andere Handbücher für K600i

Inhaltsverzeichnis

Andere Sony Ericsson Handy Handbücher

Sony Ericsson

Sony Ericsson Walkman W300i Bedienungsanleitung

Sony Ericsson

Sony Ericsson CK13i Referenzhandbuch

Sony Ericsson

Sony Ericsson Sony Ericsson Bedienungsanleitung

Sony Ericsson

Sony Ericsson K600i K600i K600i Leitfaden

Sony Ericsson

Sony Ericsson Z710c Bedienungsanleitung

Sony Ericsson

Sony Ericsson T608 Bedienungsanleitung

Sony Ericsson

Sony Ericsson Yari U100 Bedienungsanleitung

Sony Ericsson

Sony Ericsson CK15i Bedienungsanleitung

Sony Ericsson

Sony Ericsson Cyber-shot C905 Bedienungsanleitung

Sony Ericsson

Sony Ericsson W100i Service-Handbuch

Sony Ericsson

Sony Ericsson W660i Bedienungsanleitung

Sony Ericsson

Sony Ericsson Walkman W350a Bedienungsanleitung

Sony Ericsson

Sony Ericsson Xperia X2 Service-Handbuch

Sony Ericsson

Sony Ericsson CYBER-SHOT C510 Bedienungs- und Sicherheitshinweise

Sony Ericsson

Sony Ericsson T100 Kurzanleitung

Sony Ericsson

Sony Ericsson T300 Kurzanleitung

Sony Ericsson

Sony Ericsson W760 Bedienungsanleitung

Sony Ericsson

Sony Ericsson C903 Cyber-shot Bedienungsanleitung

Sony Ericsson

Sony Ericsson Walkman W850i Bedienungsanleitung

Sony Ericsson

Sony Ericsson T68 Bedienungsanleitung

Sony Ericsson

Sony Ericsson T616UG Bedienungsanleitung

Sony Ericsson

Sony Ericsson Cell Phone Service-Handbuch

Sony Ericsson

Sony Ericsson T612 Kurzanleitung

Sony Ericsson

Sony Ericsson Jalou F100i Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
