Sony Ericsson R306c Bedienungsanleitung

R306c

User guide

This is the Internet version of the User's guide. © Print only for private use.

Congratulations on your purchase of the Sony Ericsson

R306c. For additional phone content, go to

www.sonyericsson.com/fun. Register now to get free online storage

and special offers at www.sonyericsson.com/myphone. For product

support, go to www.sonyericsson.com/support.

Instruction symbols

The following instruction symbols appear in this User guide:

> Use the navigation key to scroll and select.

Press the navigation key centre.

Press the navigation key up.

Press the navigation key down.

Press the navigation key to the left.

Press the navigation key to the right.

Note

Tip

Warning

Indicates that a service or function is network- or

subscription-dependent. All menus or functions may not be

available in your phone. Consult your network operator for

more information.

This is the Internet version of the User's guide. © Print only for private use.

Preparing the phone

To insert the SIM card and battery

1Remove the battery cover.

2Slide the SIM card into its holder with the contacts facing down.

3Insert the battery with the label side up and the connectors facing

each other.

4Replace the battery cover.

Do not force the battery cover into place. Slide the battery cover

carefully onto the phone and close it.

This is the Internet version of the User's guide. © Print only for private use.

Charge the battery

Your phone battery is partly charged when you buy it.

Using the USB charger

To connect the charger and charge the battery (The illustrations are

for guidance only and may not accurately depict the actual phone)

1Connect the USB cable (you can get instruction for three conditions from

Note) plug to the AC adapter USB socket, as shown in the above

illustration. The USB cable is supplied with your phone.

2Connect the USB cable connector to your phone. Press a key to view

the charging status on the screen. It takes approximately 2.5 hours to

fully charge the battery.

It may take 30 minutes for the battery icon to appear on the screen.

This is the Internet version of the User's guide. © Print only for private use.

To remove the charger

1Charge your battery until the battery icon indicates a full charge.

2Tilt the USB charger connector upwards to remove it.

Note:

1If there are two USB cables in the kit (USB cable for charging and USB

cable for data transferring. See the illustrations as below), then the

USB cable for charging is only intended for charging your phone.

Do not use it for transferring data.

The USB cable for the USB charger is only intended for connection

to the AC adapter to charge your phone. It must not be used for

connection to a PC. It can only be used for charging your phone.

Never use it for charging accessories.

USB cable for charging USB cable for transferring

This is the Internet version of the User's guide. © Print only for private use.

2If there is only one USB cable in the kit, it is intended for charging your

phone as well as transferring data.

3If there is only one USB cable for the USB charger in the phone kit,

this USB cable is only intended for charging your phone.

4Sony Ericsson strongly recommends that you use only Sony Ericsson

branded original batteries, the part of power supply device in

accordance with YD/T 1591-2006 specifications of Communications

Industry Standards of P. R. China and the USB cable supplied with

your phone to charge the phone. The use of third-party products may

decrease the performance of your phone and/or pose a risk to your

health or safety.

You can charge the battery for more or less than 2.5 hours. Interrupted

charging will not damage the battery.

Performance depends on temperatures, signal strenth, usage

patterns, features selected and voice or data transmissions. The

stand-by time for this battery is up to xxx hours.

Use only Sony Ericsson branded original batteries intended for use

with your mobile phone. If you use other batteries you may not be

able to charge your phone.

This is the Internet version of the User's guide. © Print only for private use.

Turning on the phone

To turn on the phone

1Press and hold down .

2Enter your PIN if requested. To correct mistakes, press .

3Select OK.

4Select a language.

5Enter the time and date and select Save.

To turn off the phone

•Press and hold down .

Standby

After you have turned the phone on and

entered your PIN, the name of your operator appears on the screen.

This is called standby. You can now make and receive calls.

This is the Internet version of the User's guide. © Print only for private use.

SIM and PIN

SIM card

The SIM (Subscriber Identity Module) card, which you get

from your network operator, contains information about your

subscription. Always turn off your phone and detach the

charger before you insert or remove the SIM card.

PIN code

You may need a PIN (Personal Identification Number) to activate the

services in your phone. Your PIN is supplied by your network operator.

Each PIN digit appears as *, unless it starts with emergency number

digits, for example, 112 or 911. You can call an emergency number

without entering a PIN.

You can save contacts on the SIM card before removing it from

your phone. Contacts may also be saved in the phone memory.

See Contacts on page 16.

If you enter the wrong PIN three times in a row, this message

displayes, PIN blocked. To unblock, enter your PUK code provided

by your network operator. To unblock it, you need to enter your

PUK (Personal Unblocking Key).

This is the Internet version of the User's guide. © Print only for private use.

Phone overview

Call key

Selection key

Shortcut key

Centre navigation

key

Screen

C key

Ear speaker

Radio shortcut

key

Silent key

On/off key,

End key

This is the Internet version of the User's guide. © Print only for private use.

Volume keys

Camera

Connector for charger,

handsfree and USB

cable

Radio preset

keys

Channel up &

down keys

Stereo Speakers

Audio enhancer key

This is the Internet version of the User's guide. © Print only for private use.
