Sony Ericsson W880i Bedienungsanleitung

Sony Ericsson W880i

Quick Start Guide

In just a few minutes we’ll show you how easy it

is to use the main features of your phone. This is

a Vodafone live! with 3G phone, so you can take

advantage of the faster 3G network as well as

the latest new services.

You’ll see how quickly you can make video calls,

take pictures and video clips with the built-in

digital camera, and then send them to your

family and friends as multimedia messages

(MMS).

You’ll also be able to explore Vodafone live!, and

change your phone by simply downloading new

ringtones, games and wallpapers.

Finally, we’ll show you how to transfer music

les to your phone and use it as a Walkman™

music and video player!

880 UK.indd 1 11/12/06 18:33:08

Getting started

1. Insert the SIM card

Insert your SIM card as shown. Make sure the gold contacts are

facing down and the cut-off edge is correctly aligned.

2. Insert the battery

Insert the battery as shown and ﬁt the cover. The battery may need

charging. A full charge can take up to 2.5 hours.

3. Turn it on

Press and hold the key. Do the same to turn it off.

When prompted, select Normal mode – select Flight mode only

when you don’t want the mobile signal activated.

4. Insert a Memory Stick Micro™ (M2™)

To enlarge the phone’s memory, open the ﬂap on the side of the

phone and insert a Memory Stick Pro Micro™, until it clicks in place.

Push it in to remove it.

880 UK.indd 2 11/12/06 18:33:08

Using the phone

Navigation key: press in [l] to OK an action or select a

highlighted option. In standby mode this opens the main

menu. The navigation key also controls the Walkman®

Music Player (see page 19).

Press the edge of the navigation key to move around icons

and menu lists. In standby mode, press p> Vodafone

live! (ofﬂine), u> My Files, q> Contacts, t>

Create new message.

Soft keys: press to select the option displayed in the

bottom left or right of the screen. In standby mode the left

soft key opens the main Menu, the right soft key opens the

Toolbar.

The Toolbar lets you view and open bookmarks, shortcuts,

applications, and recent calls and messages. Press to

return to the standby screen. Press tuto move between

the Toolbar tabs. The ﬁrst tab lets you open Vodafone live!,

web pages and bookmarks. The second tab shows new

messages, alerts and missed calls. The third shows your

running applications. The fourth shows your shortcut menu.

Call key: press to make or answer a call. Pressing in

standby mode opens your Call Logs.

End key: press to end a call. Press this key at any time to

return to the standby screen.

880 UK.indd 3 11/12/06 18:33:09

Back key: press to take you back to a previous menu or

screen. Press and hold to return to the standby screen.

Clear key: press to delete a character of text. Press and

hold to delete all text. Press this key to delete contact

entries and other items.

Walkman key: press to open the Walkman® Music Player

(see page 19). Press again to return to the main menu.

Camera key (on the right side of the phone): press to start

the camera, and to take a photo or video clip.

Volume key (on the right side of the phone): move up and

down to adjust to volume, and to zoom in and out of photos.

Press once in standby mode to show the phone status.

880 UK.indd 4 11/12/06 18:33:09

Voice calls, 3G &

Video calls

Say how you’re feeling with a voice

call - or show how you’re feeling

with a video call!

With the 3G network growing all the

time, it’s never been easier.

880 UK.indd 5 11/12/06 18:33:13

The 3G network is designed to carry data faster. This will let you

download content faster from Vodafone live!, like ringtones and

videos, as well as being able to use some great new services.

With Vodafone live! with 3G you can have face to face video calls,

listen to full track music downloads and stream video – which means

that you can watch football match highlights and the latest music

videos without having to store them on your phone. You’ll also be

able to access fantastic new services such as Mobile TV! (see Other

Services).

3G connection

When you’re in an area with 3G coverage, the 3G symbol

appears next to the signal bars. This means you can take advantage of

the faster, richer experience of the Vodafone 3G service.

Of course, you’ll still be able to use the existing network at other

times.

The 3G network is growing rapidly – contact Vodafone for more

information on where the service is available.

880 UK.indd 6 11/12/06 18:33:13

Voice calls

Make a call

In standby mode, enter the number using the keypad and then press

the key. Press to end the call.

To use your Call list, press in standby mode. Scroll to the

number you want and press the lkey to start dialling. You can also

press qto access your Contacts from standby mode.

During a call, pressing lbrings up an option menu including turning

on the loudspeaker and muting the microphone (you can also press

the button to do this).

Answer a call

Press .

880 UK.indd 7 11/12/06 18:33:13

3G connection

When the 3G symbol appears you can make and receive video calls.

The other person you’re calling must have a compatible 3G phone and

be in a 3G area too.

Start the Video call screen

In standby mode, press Menu > Video call to bring up the Video call

screen. The small screen shows what the person you’re calling will

see (you’ll see them in the larger screen). Press Camera to switch to

the rear camera view. Use a headset for the best sound quality.

Call a number

Press . Enter a number or choose a contact, then press Call. If

the 3G network is not available, you’ll be asked if you want to make

a voice call.

You can also start a video call from other applications, such as

Contacts or Calls list. Just highlight the number and press More >

Make video call.

Adjusting the image

Press pqto zoom in and out. Press More for an option menu of

other adjustments.

Answer a video call

Press . Press Camera to turn your camera off or on (if you don’t

want the caller to view you).

Video calls

880 UK.indd 8 11/12/06 18:33:13

Camera &

Multimedia

Messaging (MMS)

See it, shoot it, send it!

With your built-in digital camera

you can capture photos and video

clips as they happen, and then

share them straight away with your

friends and family...

880 UK.indd 9 11/12/06 18:33:18





Using the camera

Turn on the camera

Turn the phone sideways, then press the camera key to turn

on the camera (in standby mode). Press the key to turn the

camera off.

Adjust the image

Use the volume key to zoom in or out, and press the navigation key

tor uto adjust the brightness. For other settings, see the next

page.

Take a photo

Press the camera key to take the photo.

Your photo is automatically saved in Menu > My Files > Camera

album. (Press View in the camera screen to see your photos.) To

delete the photo, press , or press to take another one.

Send the photo

Press Send. See the MMS section for further details.

Advanced modes

When you’ve taken your picture, press More > Edit in PhotoDJ™

for a range of editing options. You can also upload it to an online blog

page by choosing More > Blog this.

Settings

View

880 UK.indd 10 11/12/06 18:33:18
