Sony Ericsson VH700 Service-Handbuch

VH700

Extended User guide

Contents

1.....................................................................................................3

2.....................................................................................................4

Headset overview.........................................................................5

Introduction..................................................................................6

Charging........................................................................................7

Turning on and off........................................................................8

Pairing the headset......................................................................9

Pairing the headset with a phone........................................................9

Pairing the headset with another phone..............................................9

Multipoint....................................................................................10

Calling..........................................................................................11

Transferring sound............................................................................11

Battery.........................................................................................12

Resetting the headset................................................................13

Troubleshooting.........................................................................14

Redial does not work........................................................................14

The headset is automatically turned off.............................................14

Unexpected behaviour......................................................................14

No connection to the phone..............................................................14

FCC Statement...........................................................................15

Industry Canada Statement......................................................16

Declaration of Conformity for VH700 ......................................17

This is an Internet version of this publication. © Print only for private use.

Headset overview

See illustration 1.

1 Microphone

2 Call handling key

3 Microphone

4 Volume keys

5 Charger connector

6 Clip

7 On/off key

8 Indicator light

This is an Internet version of this publication. © Print only for private use.

Introduction

The Bluetooth™ Noise Shield Handsfree VH700 can be connected to any device with

Bluetooth wireless technology that supports the headset or headset profile. This User guide

focuses on use with a Sony Ericsson mobile phone.

This is an Internet version of this publication. © Print only for private use.

Charging

Before using the headset for the first time, you need to charge it with the supplied charger

for 8 hours. See illustration 2. The normal charging time is 2.5 hours. Use Sony Ericsson

chargers only.

This is an Internet version of this publication. © Print only for private use.

Turning on and off

To turn on the headset

•Press and hold down until the indicator light shows a steady green or red light. If

the light is red, the headset needs charging. After 3 seconds, the light turns off and

the headset is on.

To turn off the headset

•Press and hold down until the indicator light shows a green or red light. If the light

is red, the headset needs charging. After 3 seconds, the light turns off and the

headset is off.

This is an Internet version of this publication. © Print only for private use.

Pairing the headset

Pairing the headset with a phone

To use the headset with a phone, you need to pair the headset with the phone. After

successful pairing, the headset connects automatically to the phone as soon as the headset

is turned on and within range.

To pair the headset with a phone

1Make sure the headset is turned off.

2Turn on the Bluetooth function in the phone. For instructions, see the phone User

guide.

3Turn on Bluetooth visibility in the phone. This makes the phone visible to other

Bluetooth devices.

4Place the phone within 20 cm (8 inches) of the headset.

5Press and hold down on the headset for about 5 seconds until the indicator light

flashes green and red alternately.

6Auto pairing in your phone: When asked to add the VH700, follow the instructions

that appear.

7Normal pairing in your phone: Search for and add a new device.

8If a passcode is required, enter 0000.

Pairing the headset with another phone

To use the headset with another phone, you need to pair the headset with the phone. After

successful pairing, the headset connects automatically to the phone as soon as the headset

is turned on and within range.

To pair the headset with another phone

1Make sure the headset is turned off.

2Turn on the Bluetooth function in the other phone. For instructions, see the phone

User guide.

3Place the other phone within 20 cm (8 inches) of the headset.

4Press and hold down on the headset for about 5 seconds until the indicator light

flashes green and red alternately.

5In the other phone: Search for and add a new device.

6If a passcode is required, enter 0000.

This is an Internet version of this publication. © Print only for private use.

Multipoint

With this feature, you can use the headset with two different phones at the same time.

Before you use this feature, you need to enable it.

To enable the multipoint feature

1Make sure the headset is turned off.

2Press and hold down on the headset until the indicator light flashes green and red

alternately.

3Multipoint mode: Press and hold down the plus sign on the volume key. Two orange

flashes on the indicator light shows that multipoint has been enabled.

4Singlepoint mode: Press and hold down the minus sign on the volume key. One

orange flash on the indicator light shows that singlepoint has been enabled.

When the headset is in multipoint mode, you cannot answer a second call on the same phone.
