Sony HMZ-T1 Bedienungsanleitung
4-297-824-61(1)
HMZ-T1
Head
Mounted
Display
Reference Guide GB
CT
Before Initial Use
Refer to the “Startup Guide” for instructions on
connecting the system, wearing the unit, and completing
initial settings.
GB
2
To reduce the risk of fire or electric shock, do not
expose this apparatus to rain or moisture.
To prevent fire or shock hazard, do not place objects
filled with liquids, such as vases, on the apparatus.
Install this system so that the mains lead can be
unplugged from the wall outlet (mains) immediately
in the event of trouble.
Do not install this equipment in a confined space such
as a bookshelf or similar unit.
Precaution
The set is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet
(mains), even if the set itself has been turned off.
Notice for customers in the United
Kingdom
A molded plug complying with BS1363 is fitted to
this equipment for your safety and convenience.
Should the fuse in the plug supplied need to be
replaced, a fuse of the same rating as the supplied one
and approved by ASTA or BSI to BS1362, (i.e.,
marked with or mark) must be used.
If the plug supplied with this equipment has a
detachable fuse cover, be sure to attach the fuse cover
after you change the fuse. Never use the plug without
the fuse cover. If you should lose the fuse cover,
please contact your nearest Sony service station.
Notice for customers: the following
information is only applicable to
equipment sold in countries applying
EU directives.
The manufacturer of this product is Sony
Corporation, 1-7-1 Konan Minato-ku Tokyo, 108-
0075 Japan. The Authorized Representative for EMC
and product safety is Sony Deutschland GmbH,
Hedelfinger Strasse 61, 70327 Stuttgart, Germany.
For any service or guarantee matters please refer to
the addresses given in separate service or guarantee
documents.
This equipment has been tested and found to comply
with the limits set out in the EMC Directive using a
connection cable shorter than 3 meters.
Disposal of Old Electrical
& Electronic Equipment
(Applicable in the
European Union and other
European countries with
separate collection
systems)
This symbol on the product or on its packaging
indicates that this product shall not be treated as
household waste. Instead it shall be handed over to
the applicable collection point for the recycling of
electrical and electronic equipment. By ensuring this
product is disposed of correctly, you will help prevent
potential negative consequences for the environment
and human health, which could otherwise be caused
by inappropriate waste handling of this product. The
recycling of materials will help to conserve natural
resources. For more detailed information about
recycling of this product, please contact your local
Civic Office, your household waste disposal service
or the shop where you purchased the product.
Warning
GB
3
Age Limitations
Watching video images or playing games by
this device may affect the health of growing
children. This device should not be used by
children 15 and under.
Use password protection feature (page 21) of
this device to restrict children from using this
device.
Watching Video with the Head Mounted
Display
• Some people may experience discomfort (such
as eye strain, fatigue, nausea, or motion
sickness) while watching video images or
playing games. Sony recommends that all
viewers take regular breaks while watching
video images or playing games. The length and
frequency of necessary breaks will vary from
person to person. You must decide what works
best. If you experience any discomfort, you
should stop watching the video images or
playing games until the discomfort ends;
consult a doctor if you believe necessary.
• Avoid wearing the unit in environments where
your head may shake, or while you are walking
or performing exercise, because there is a
higher possibility that you experience
discomfort.
• You should also review (i) the instruction
manual of any other device or media used with
this device and (ii) our website below for the
latest information.
For customers in Europe, Russia and UK:
http://support.sony-europe.com/
For customers in the U.S.A.:
http://esupport.sony.com/
For customers in Canada:
http://esupport.sony.com/CA/
For customers in China:
http://service.sony.com.cn/index.htm
For customers in other countries/regions:
http://www.sony-asia.com/support/
Correct Use
• Ensure that you are wearing the head mounted
unit correctly.
– For instructions on wearing the unit, refer to
the “Startup Guide.”
– To avoid watching with the screens skewed,
check screen alignment by referring to the
confirmation screen displayed initially.
– Note that dropping the unit or handling it
roughly may skew the screens.
• The head mounted unit can be adjusted in a
range of 55 mm – 72 mm to suit the distance
between your eyes (interpupillary distance). If
you cannot use the system within this range,
refrain from using the system.
• By default, a warning message for automatic
shutdown will be displayed after three hours of
continuous viewing. If you clear the message
and continue watching, the system will
automatically turn off after another 3 hours.
For Comfortable Viewing
Images are perceived as appearing some distance
from the viewer.
If you normally wear glasses or contact lenses,
wear them as usual during use (with the exception
of reading glasses). Note that watching with
bifocals may be less than optimal.
Health Precautions
GB
GB
4
Power Supply
Position the system near the mains used. In case
of strange noises, fumes, or smoke from the
system, immediately unplug the mains lead to
turn all power off. Only pressing the power
button on the head mounted unit will not turn the
system off completely.
Installation Environment
Avoid installation in the following environments.
• Places subject to vibration
• In direct sunlight, or where it is very hot or
humid
• Places that are extremely cold
Also avoid putting liquid-filled containers (such
as flower vases) on top of the processor unit, or
using the system where it may be splashed. The
system may be damaged if splashed with water.
Condensation
Condensation occurs when moisture in the air
condenses on metal panels or other parts, forming
droplets. Condensation may form on outer
surfaces or internally if the system is suddenly
moved from a cold to a warm environment, or
when a heater is turned on in a cold room where
the system is installed. If condensation forms, do
not use the system until the droplets evaporate.
• If the system is not plugged into a mains
Leave the system unplugged, and wait until the
droplets evaporate.
• If the system is not on
Leave the system off, and wait until the droplets
evaporate.
• If the system is on
Leave the system on, and wait until the droplets
evaporate.
Using the system when condensation has formed
may damage it.
Lens Care
• Handle the lenses on the head mounted unit
carefully to avoid smears or scratches. If the
lenses become dirty, wipe them gently with a
soft lens-cleaning cloth.
• Do not use liquid solutions, such as lens-
cleaning fluid, water, or alcohol-based cleaners.
Cleaning the System
Clean outer surfaces of the system using a soft
cloth lightly moistened with a mild detergent. Do
not use solvents, such as thinner, benzine, or
alcohol, which may damage surfaces.
Extended Listening at High Volume
Listening at high volume over extended periods
may harm hearing. To protect your hearing, avoid
listening at excessive volume.
Initial Volume
To avoid sudden loud output, keep the initial
volume low. Increase the volume gradually until
the desired level is reached.
Packaging Materials
Keep the original box and protective cushioning
for future use, in case you move or need to ship
the system for repair or other reasons.
Precautions
GB
5
HDMI Jacks and Connectors
Take these precautions to avoid damaging HDMI
jacks and connectors.
• When inserting cables, note the shape and
orientation of the connector and the HDMI jack
on the back of the processor unit.
• Before moving the processor unit, always
disconnect the HDMI cable.
• When connecting or disconnecting HDMI
cables, hold the connector straight. Do not hold
the connector at an angle or force it into the
HDMI jack.
• Use either the supplied HDMI cable or a
commercially available High-Speed HDMI
cable.
Head Mounted Unit Cord Handling
Take these precautions to avoid damaging the
HMD OUT jack or cord connector.
• When inserting the connecting cord, note the
shape and orientation of the connector and the
HMD OUT jack on the front of the processor
unit.
• Before moving the processor unit, always
disconnect the connecting cord.
• When connecting or disconnecting the
connecting cord, hold the connector straight.
Do not hold the connector at an angle or force it
into the HMD OUT jack.
HDMI input and output
The connector is upside-down
HDMI input and output
The connector is not straight
GB
6
Health Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Product Highlights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Supplied Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Fitting the Head Mounted Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Confirming Screen Alignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
System Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Licence and Trademark Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Contents
GB
7
Wearing the head mounted display, you can
watch 3D movies and play 3D games from
connected Blu-ray Disc™ player and game
consoles.
Product highlights are as follows.
• Enjoy video with impact, simulating the
big-screen cinematic experience through a
wide 45° horizontal field of view.
• Watch high-contrast, high-definition
video produced by Sony HD OLED
(Organic Light-Emitting Diode) panels in
the head mounted unit.
• Connect the system to 3D-compatible
equipment for a realistic 3D viewing
experience. Simultaneous display on both
OLED screens eliminates the cross-talk
(double images) that older systems with
alternating images are susceptible to.
• Hear immersive multi-channel virtual
surround-sound with depth, produced by
the headphones in the head mounted unit
and by Virtualphones Technology (VPT).
Make sure the following items are included
with the system after purchase. If any items
are missing, contact your Sony dealer or a
local authorised Sony service centre.
•Mainslead(1)
• HDMI cable (1)
• Light blocker (1 each for the left and right)
• Headband strap clip (1)
• Connecting cord holder (1)
Product Highlights Supplied Accessories
GB
8
• Forehead supporter (3)
• Forehead supporter cover (1)
• Reference Guide (this guide) (1)
• Startup Guide (1)
Type A
(thin)
Type B
(medium)
Type C
(thick)
The type B forehead supporter is attached to
the head mounted unit at the time of
purchase.
GB
9
Head Mounted Unit
Parts and Controls
Top headband strap
Forehead supporter
Illumination
Lens span adjusters
Control buttons (v/V/
b/B, MENU*)
VOL +/– buttons
1(Power On/Standby)
button
Headband strap release
button
Bottom headband
strap
Headband strap release
button
* The MENU button serves two purposes.
Press the MENU button to view setting menus as well as to
confirm setting changes (when it functions as an Enter
button).
Lenses Nose pad
HeadphonesConnecting cord
GB
10
Processor Unit (Front)
Processor Unit (Back)
HMD OUT jack (HMD Output)
Insert the connecting cord of the
head mounted unit.
Power indicator
Lit in green when the system is
on, and lit in red in standby mode.
PASS THROUGH indicator
Lit in amber when HDMI
pass-through is used.
HDMI OUT jack
(HDMI Output)
• Source signals cannot be passed through
the HDMI OUT jack until the HDMI pass-
through is enabled (page 21) and the Head
Mount system is turned off.
Note
HDMI IN jack
(HDMI Input)
AC IN terminal
Andere Handbücher für HMZ-T1
5
Inhaltsverzeichnis
Andere Sony 3D-Brille Handbücher
Sony
Sony BRAVIA KDL-55HX751 Bedienungsanleitung
Sony
Sony HMZ-T2 Benutzerhandbuch
Sony
Sony HMZ-T1 Kurzanleitung
Sony
Sony PLM-A55E Bedienungsanleitung
Sony
Sony STW-C140GI Bedienungsanleitung
Sony
Sony TDGBT500A Bedienungsanleitung
Sony
Sony TDG-BR250 Bedienungsanleitung
Sony
Sony BKM-31GM Bedienungsanleitung
Sony
Sony BKM-31G Bedienungsanleitung
Sony
Sony BKM-30GM Bedienungsanleitung
Sony
Sony TDG-BR100 Bedienungsanleitung
Sony
Sony TDG-BR250 Bedienungsanleitung
Sony
Sony HMZ-T2 Bedienungsanleitung
Sony
Sony TDG-BR250 Bedienungsanleitung
Sony
Sony TDG-BR100 Bedienungsanleitung
Sony
Sony TDG-BR50/B Bedienungsanleitung
Sony
Sony TDG-500P Bedienungsanleitung
Sony
Sony TDG-BR750 Bedienungsanleitung
Sony
Sony TDG-BR750 Bedienungsanleitung
Sony
Sony Glasstron PLM-A35E Bedienungsanleitung
Beliebte 3D-Brille Handbücher anderer Marken
YEAZ
YEAZ SUNUP Bedienungsanleitung
Dimensional Optics
Dimensional Optics Active 3D Bedienungsanleitung
xelux
xelux Smartglass I3 LED Bedienungsanleitung
Cyclopital3D
Cyclopital3D HD3D View-Vaster Bedienungsanleitung
Panasonic
Panasonic TY-EP3D10EB Bedienungsanleitung
Rollei
Rollei Sunglasses Cam 100 Bedienungsanleitung
