SERVICE MANUAL

Published by Sony Techno Create Corporation

Sony Corporation

BLU-RAY DISCTM/DVD HOME THEATRE SYSTEM

9-893-702-01

2013B33-1

US Model

BDV-N7100W/N8100W

Canadian Model

BDV-N9100W

AEP Model

BDV-N7100W/N7100WL/N8100W/N9100W/N9100WL

UK Model

BDV-N7100W/N7100WL/N9100W

Australian Model

BDV-N9100W/N9100WL

PX Model

BDV-N7100W

Saudi Arabia Model

Middle East Model

BDV-N8100W/N9100W/N9900SH

Singapore Model

BDV-N7100W/N9100W/N9100WL

Indian Model

BDV-N7100W/N9100W

Ver. 1.0 2013.02

BDV-N7100W/N7100WL/N8100W/

N9100W/N9100WL/N9900SH

• BDV-N7100W/N7100WL/N8100W/N9100W/N9100WL/N9900SH

are composed of following models.

As service manuals are issued for each component model, please

refer to them.

COMPONENT MODEL NAME

BDV-N7100W BDV-N7100WL BDV-N8100W

Blu-ray discTM/

DVD receiver HBD-N7100W HBD-N7100WL HBD-N8100W

Front

speaker SS-TSB125 SS-TSB124 SS-TSB126

Center

speaker SS-CTB124 SS-CTB123 SS-CTB124

Surround

speaker SS-TSB129 SS-TSB128 SS-TSB129

Subwoofer SS-WSB125 SS-WSB124 SS-WSB125

Surround

ampliﬁer TA-SA300WR TA-SA400WR TA-SA300WR

Wireless

transceiver EZW-RT50 EZW-RT50 EZW-RT50

BDV-N9100W BDV-N9100WL BDV-N9900SH

Blu-ray discTM/

DVD receiver HBD-N9100W HBD-N9100WL HBD-N9900SH

Front

speaker SS-TSB126 SS-TSB127 SS-TSB127

Center

speaker SS-CTB124 SS-CTB123 SS-CTB123

Surround

speaker SS-TSB131 SS-TSB130 SS-TSB130

Subwoofer SS-WSB125 SS-WSB124 SS-WSB124

Surround

ampliﬁer TA-SA300WR TA-SA400WR TA-SA400WR

Wireless

transceiver EZW-RT50 EZW-RT50 EZW-RT50

Note: As for EZW-RT50, the part number has been described to this service manual.

– Refer to the next page for speciﬁcations –

BDV-N7100W/N7100WL/N8100W/N9100W/N9100WL/N9900SH

General

SPECIFICATIONS

Power requirements

US, Canadian models: 120 V AC, 60 Hz

PX model: 110 V - 240 V AC, 50/60 Hz

Other models: 220 V - 240 V AC, 50/60 Hz

Power consumption

On: 80 W (US, Canadian models)

On: 100 W (Other models)

Standby: 0.3 W (at the power

saving mode)

Dimensions (w/h/d) (approx.)

480 mm × 79 mm × 212 mm (19 in ×

3 1/8in × 8 3/8in) incl. projecting parts

480 mm × 79 mm × 226 mm (19 in ×

3 1/8in × 9 in) (with the wireless

transceiver inserted)

Mass (approx.)

3.1 kg (6 lb 14 oz)

Wireless transceiver (EZW-RT50)

Communication system

Wireless sound Specification version 1.0

Frequency band

5.736 GHz – 5.814 GHz

Modulation method

DSSS

Power requirements

DC 3.3 V, 300 mA

Dimensions (w/h/d) (approx.)

30 mm × 9 mm × 60 mm

(1 3/16 in × 3/8in × 2 3/8in)

Mass (approx.)

10 g (1/2oz)

Design and specifications are subject to

change without notice.

sStandby power consumption: 0.3W

sOver 85% power efficiency of amplifier

block is achieved with the full digital

amplifier, S-Master.

Unpacking

• Front speakers (2)

• Surround speakers (2)

• Center speaker (1)

• Subwoofer (1)

• Speaker cords (5, red/white/gray/blue/green)

• Speaker-bottom covers (2) (BDV-N8100W), (4) (BDV-N9100W/N9100WL/N9900SH)

• Bases (2) (BDV-N8100W), (4) (BDV-N9100W/N9100WL/N9900SH)

• Lower parts of the front and surround speakers (4) (BDV-N9100W/N9100WL/N9900SH)

• Lower parts of the front speakers (2) (BDV-N8100W)

• Screws (4) (BDV-N7100W/N7100WL), (10) (BDV-N8100W), (16) (BDV-N9100W/N9100WL/N9900SH)

• Stands (for surround speakers) (2) (BDV-N8100W)

• Stands (for front and surround speakers) (4) (BDV-N7100W/N7100WL)

• Screw hole covers (2) (BDV-N8100W), (4) (BDV-N7100W/N7100WL)

• Remote control (1)

• R03 (size AAA) batteries (2)

• AC plug adaptors (2) (PX model only)

• FM wire antenna (aerial) (1)

• Calibration mic (1)

• High Speed HDMI cable (1) (Saudi Arabia, Singapore, Middle East, Indian models only)

• Surround ampliﬁer (1)

• Wireless transceivers (2)

• Operating Instructions (Except AEP, UK models only)

• Quick Setup Guide

• Speaker Installation Guide

• Reference Guide (AEP, UK models only)

– Refer to the next page for accessories list –

BDV-N7100W/N7100WL/N8100W/N9100W/N9100WL/N9900SH

ACCESSORIES

4-456-334-11 INSTRUCTION MANUAL (ENGLISH) (US, CND)

4-456-334-21 INSTRUCTION MANUAL (FRENCH) (CND)

4-456-334-31 INSTRUCTION MANUAL (SPANISH) (US)

4-456-334-41 INSTRUCTION MANUAL (ENGLISH) (PX)

4-456-335-11 INSTRUCTION MANUAL (ENGLISH) (UK, AUS)

4-456-335-31 INSTRUCTION MANUAL (FRENCH) (AEP)

4-456-335-41 INSTRUCTION MANUAL (SPANISH) (AEP)

4-456-335-51 INSTRUCTION MANUAL (GERMAN) (AEP)

4-456-335-61 INSTRUCTION MANUAL (DUTCH) (AEP)

4-456-335-71 INSTRUCTION MANUAL (ITALIAN) (AEP)

4-456-335-81 INSTRUCTION MANUAL (POLISH) (AEP)

4-456-336-11 INSTRUCTION MANUAL (PORTUGUESE) (AEP)

4-456-336-21 INSTRUCTION MANUAL (SWEDISH) (AEP)

4-456-336-31 INSTRUCTION MANUAL (DANISH, FINNISH)

(AEP)

4-456-336-41 INSTRUCTION MANUAL (GREEK) (AEP)

4-456-336-51 INSTRUCTION MANUAL (CZECH, HUNGARIAN)

(AEP)

4-456-336-61 INSTRUCTION MANUAL (TURKISH) (AEP)

4-456-336-71 INSTRUCTION MANUAL (SLOVAKIAN) (AEP)

4-456-337-11 INSTRUCTION MANUAL (ENGLISH) (SP)

4-456-337-21 INSTRUCTION MANUAL (FRENCH, PERSIAN)

(N8100W: E3/N9100W: E3)

4-456-337-31 INSTRUCTION MANUAL (ARABIC)

(N8100W: E3, EA/N9100W: E3, EA)

4-456-337-41 INSTRUCTION MANUAL

(TRADITIONAL CHINESE) (SP)

4-456-337-71 INSTRUCTION MANUAL (ENGLISH)

(N7100W: E12/N8100W: E3, EA/

N9100W: E3, E12, EA)

4-456-337-81 INSTRUCTION MANUAL (ENGLISH, ARABIC)

(N9900SH)

4-456-337-91 INSTRUCTION MANUAL (FRENCH, PERSIAN)

(N9900SH: E3)

Ref. No. Part No. Description Remark

– Continued on next page –

• Abbreviation

AUS : Australian model

CND : Canadian model

E3 : Middle East model

E12 : Indian model

EA : Saudi Arabia model

SP : Singapore model

BDV-N7100W/N7100WL/N8100W/N9100W/N9100WL/N9900SH

501 1-491-967-11 REMOTE COMMANDER (RM-ADP092)

(Remote control) (N7100W: US, PX/

N8100W: US/N9100W: CND)

501 1-491-968-11 REMOTE COMMANDER (RM-ADP093)

(Remote control) (N7100W: AEP, UK/

N8100W: AEP/N9100W: AEP, UK, AUS)

501 1-491-969-11 REMOTE COMMANDER (RM-ADP093W)

(Remote control) (N7100WL/N9100WL: AEP, AUS)

501 1-491-972-11 REMOTE COMMANDER (RM-ADP095)

(Remote control) (N7100W: E12, SP/

N8100W: E3, EA/N9100W: E3, E12, EA, SP)

501 1-491-973-11 REMOTE COMMANDER (RM-ADP095W)

(Remote control) (N9100WL: SP/N9900SH)

502 1-754-060-21 ANTENNA (FM) (FM wire antenna (aerial))

(EXCEPT US, CND, PX)

502 1-793-184-41 CONNECTOR (F TYPE ADAPTOR)

(FM wire antenna (aerial)) (US, CND, PX)

503 1-542-903-11 MEASUREMENT MIC (STEREO) (Calibration mic)

504 1-489-359-11 RF MODULATOR (EZW-RT50 UC)

(Wireless transceiver) (1 piece) (AEP, UK)

504 1-489-360-11 RF MODULATOR (EZW-RT50 UC2)

(Wireless transceiver) (1 piece) (US, CND, PX)

504 1-489-361-11 RF MODULATOR (EZW-RT50 AU)

(Wireless transceiver) (1 piece)

(E3, E12, EA, SP, AUS)

505 1-846-401-11 CABLE (WITH CONNECTOR) (SPEAKER)
