Sony PLAYSTATION 4 PRO Bedienungsanleitung

Quick Start Guide

English

CUH-7116B 7029906

Welcome to the future of play.

Rear view

Connect to your TV.

Follow steps to below to connect your PlayStation®4 system to

your TV. You must use the supplied HDMI cable for the connection.

Let's get started

AC IN connector HDMI OUT port HDMI input port

HDMI™ cable

AC power cord

To an electricity supply

You can transfer saved data from your current PS4™ system to your new PS4™

system. If you intend to do this, we recommend completing the data transfer

during the initial set up process for your new system. If you do it later, any

saved data on the new system will be lost. For guidance on transferring data

and the types of data you can transfer, refer to the User’s Guide.

manuals.playstation.net/gb/04.html

Connect to the Internet.

We recommend use of a LAN cable (sold separately) for a more

stable network connection.

If you prefer to use a wireless connection (Wi-Fi), don't connect a

LAN cable.

Get the most out of your PS4™ system by connecting to the Internet. You’ll be

able to play games online and connect with Friends.*1

Rear view

LAN port

LAN cable

(sold separately)

Type of connection:

Router Internet connected device

such as a modem

To the Internet

Front view

Power button/Power indicator

Turn on your TV and set the input to HDMI.

Turn on your PS4™ system by pressing the

(power) button.

The power indicator blinks blue, and then turns white.

If your TV does not display a picture when the power indicator turns white,

restart your system. Press the (power) button for at least 7 seconds to turn

off your system, and then turn it on again.

Connect your DUALSHOCK®4 wireless controller

to your system using the USB cable, and then

press the (PS) button.

Your controller pairs with your system and turns on.

• You'll need to pair a controller when you use it for the first time and when

you use your controller on another PS4™ system. If you want to use two or

more controllers, you must pair each controller.

• After you've paired your controller, you can disconnect the USB cable and use

your controller wirelessly.

• It's possible to use up to four controllers at the same time. When you press

the (PS) button, the light bar glows in your assigned colour. The first

controller to connect is blue, with subsequent controllers glowing red, green,

and pink.

Front view

USB port USB port

USB cable

PS button

Make it your own.

You're almost done! Follow the on-screen instructions to set up an

Internet connection, set the date and time, and configure other

settings - then select [Start Now] from the setup screen.

After you set up your Internet connection, a system software

update may automatically download. Future updates will improve

performance and add new features.

Will a child be using your PS4™ system? If so, be sure to read the

"Parental controls" section.

To later change any settings that you skipped, select (Settings) from the

function screen.

If children will be using the PS4™ system, parents or guardians can

restrict access to certain content or features using parental

controls.

For details on what can be restricted and how to set restrictions,

refer to the User's Guide.

manuals.playstation.net/gb/01.html

You can restrict the use of games that have age limitations by

setting the parental control level according to the following table.

Europe, Africa and India

Player’s Age Under

33-6 7-11 12-15 16-17 18 and

over

PS4™ Parental

Control Setting 1 2 3 5 7 9

Highest game age

rating

Germany

Player’s Age Under 6 6-11 12-15 16-17 18 and

over

PS4™ Parental

Control Setting 1 3 5 7 9

Highest game age

rating

Parental controls

Portugal

Player’s Age Under

44-5 6-11 12-15 16-17 18 and

over

PS4™ Parental

Control Setting 1 2 3 5 7 9

Highest game age

rating

Take a look around

Function screen

Access PS4™ system features,

including notifications, your

Friends, and settings.

Content info screen

The latest information about the

selected content is displayed.

Up button

Down button

Home screen

Content area

Access your games and other

content.

Start the game

Insert a disc. Select the game from the content area to start

playing.

Return to the home screen from a game

To return to the home screen without ending a game, press the

(PS) button.

To resume playing the game, select it from the content area.

End the game

Press and hold the (PS) button, and then select [Close

Application] from the quick menu that appears.

Eject the disc

Press the (eject) button.

Front view

Let's play

Front view

Eject button
