Sony PSP Bedienungsanleitung
PSP-3008 4-115-362-71(1)
Quick Reference
Краткий справочник
Using "XMB" (XrossMediaBar)
Introduction
GAME
Playing games
VIDEO
Playing video
MUSIC
Playing music
Displaying images
NETWORK
Connecting to the Internet
SETTINGS
Adjusting PSP™ system
settings
Category
1Select a category using the left or right
button.
2Select an item using the up or down
button.
3Press the button to confirm the
selected item.
Item
Icons displayed in the Home Menu vary depending
on the system software version.
The PSP™ system includes a user interface called "XMB"
(XrossMediaBar). The main screen for "XMB" is called the “Home Menu”.
Home Menu
2
DE
IT
NL
PT
GB
RU
SELECT START
VOL
This document describes basic operations of the PSP™ system. For detailed instructions, refer to the online user’s guide
( page 25).
button:
Cancels selected
operations
button:
Confirms selected items
Directional buttons:
Used to select
categories/items
PS button:
Returns to the Home Menu
Quits gameplay
Select an icon, and then press the button
to display the options menu. While playing content, press the button
to display the control panel.
button: Displays the options menu/control panel
Icons Options menu Control panel
3
01
Checking the package contents
Preparation
Check that you have all of the following items.
If any items are missing, contact the appropriate PSP™ customer service helpline which can be found within
every PSP™ format software manual.
PSP™ (PlayStation®Portable) system
Battery Pack
AC Adaptor
Printed Materials
POWER
HOLD
SELECT
VOL
START
4
DE
IT
NL
PT
GB
RU
Preparation
Checking the package contents
About the PSP™ system documentation
The PSP™ system documentation includes the
following:
• Safety and Support
Before using the product, carefully read this document first.
It contains safety information related to the use of the PSP™
system, troubleshooting, specifications and other
information.
• Quick Reference (this document)
This document contains information on basic hardware
operations of the PSP™ system.
• User’s Guide
(access from : eu.playstation.com/manuals)
This online document is accessed through the Internet and
contains detailed information related to the use of the PSP™
system software ( page 25).
5
02
Preparing the PSP™ system for use
Preparation
Charging the battery
Before using the PSP™ system for the first time after
purchase, you must follow these steps to charge the
battery.
Caution
• The socket-outlet shall be installed near the equipment
and shall be easily accessible.
• Do not plug the AC Adaptor for the PSP™ system into an
electrical outlet until you have made all other
connections.
1 Remove the battery cover.
While holding down the release button, slide the battery
cover in the direction of the arrow.
2
1
Release button
2 Insert the Battery Pack.
Align the bottom surface of the battery pack with the
system to attach the battery.
1
2
Align the tabs of the battery cover with the system and
snap it in place.
4
3
6
DE
IT
NL
PT
GB
RU
Preparation
Preparing the PSP™system for use
3Attach the AC Adaptor to charge the
battery.
SELECT START
VOL
1
2
The POWER indicator lights up in orange, indicating that
charging has begun. The POWER indicator will turn off when
the battery is fully charged.
POWER indicator
To electrical outlet
Initial setup
1Slide the POWER/HOLD switch up.
POWER
HOLD
START
SELECT
POWER/HOLD switch
The POWER indicator lights up in green, and the initial
setup screen is displayed.
2Follow the on-screen instructions to
make the initial settings.
When you have completed initial setup, the Home Menu
(page 2) is displayed.
• See "Using the on-screen keyboard" ( page 26) for
information on entering characters.
• Settings made during initial setup can be changed later in
(Settings). See the user’s guide ( page 25) for details.
7
Off
WLAN switch (top)
LCD screen
L button
Directional buttons
Memory Stick Duo™
access indicator
( page 13)
WLAN access indicator
Lights up when using the
wireless LAN feature
Analog stick
Strap holder
PS button*
Volume − button
Volume + button
START button
SELECT button
Sound button
( page 9)
Display button
( page 9)
Left speaker
Microphone
( page 12)
SELECT START
VOL
On
*The PS button on this PSP™ system performs the same
functions as the HOME button on PSP-1000 and PSP-2000
series systems.
POWER/HOLD
switch (right side)
(page 10)
HOLD indicator
( page 10)
POWER indicator
( page 10)
R button
button, button
button, button
Right speaker
WLAN
03
Part names and functions
Preparation
System
8
DE
IT
NL
PT
GB
RU
Using the sound button
Press and release
Each time you press the button, the tone
changes among HEAVY POPS
JAZZ UNIQUE OFF. *1
Press for more
than one second The sound is muted. *2
*1 : The tone can be changed only when using headphones.
Also, the tone setting is temporarily set to “OFF” during
gameplay.
*2 : To clear muting, press the sound button again.
Using the display button
Press and release
Each time you press the button, the
display changes among three levels of
screen brightness. *1
Press for more
than one second
The backlight turns off and the screen
goes blank. *2
Press for more
than five seconds
The system switches to video output
mode ( page 18).
*1 : The highest level (level 4) can be selected only while the
PSP™ system is plugged in using the AC Adaptor.
*2 : To turn the backlight back on, press any of the PSP™
system buttons.
Preparation
Part names and functions
Connecting Headset
You can connect the remote control (sold separately)
to the headset connector. You can also connect the
headset (sold separately) to the remote control.
VOL
2
1
Headset Remote Control
The PSP-1000 series headphones with remote control are not
compatible for use.
9
04
Basic operations
Use the POWER/HOLD switch to turn the system on
or off, or to put it into sleep or hold mode.
POWER
HOLD
START
SELECT
AB
C
POWER/HOLD switch
POWER indicator
HOLD indicator
POWER/HOLD switch
ATurning the system on /
Putting into sleep mode Slide up
B Turning the system off Slide up and hold for more
than three seconds
C Locking the system buttons* Slide down
*All operations using system buttons are locked.
POWER indicator
Solid green Power on
Solid orange Charging
Flashing green Charge level is low
Light off Power off/in sleep mode
HOLD indicator
Solid yellow In hold mode
Power and sleep mode functions
10
