Sony KE-42MR1E Bedienungsanleitung

4-101-833-11 (1)

Plasma TV

KE-42MR1E

KE-50MR1E

2003 Sony Corporation

Operating Instructions

NOTICE FOR CUSTOMERS

A moulded plug complying with BS1363 is fitted to this equipment for your safety and

convenience.

Should the fuse in the plug supplied need to be replaced, a 5 AMP fuse approved by ASTA or

BSI to BS 1362 (i.e. marked with or ) must be used.

When an alternative type of plug is used it should be fitted with a 5 AMP FUSE, otherwise the

circuit should be protected by a 5 AMP FUSE at the distribution board.

If the plug supplied with this equipment has a detachable fuse cover, be sure to attach the fuse

cover after you change the fuse. Never use the plug without the fuse cover. If you should lose

the fuse cover, please contact your nearest Sony service station.

How to replace the fuse

Open the fuse compartment with a blade screwdriver, and replace the fuse.

IMPORTANT

If the plug supplied is not suitable for the socket outlets in your home, it should be cut off and

an appropriate plug fitted in accordance with the following instructions:

The wires in this mains lead are coloured in accordance with the following code:

Blue Neutral

Brown Live

As the colours of the wires in the mains lead of this apparatus may not correspond with the

coloured markings identifying the terminals in your plug, proceed as follows:

The wire which is coloured blue must be connected to the terminal which is marked with the

letter N or colouredblack. The wire which is coloured brown must be connected to theterminal

which is marked with the letter L or coloured red. Do not connect either wire to the earth

terminal in the plug which is marked by the letter E or by the safety earth symbol Ior coloured

green or green and yellow.

WARNING

• To prevent the risk of electric shock, do not insert the plug cut off from the mains lead into a socket

outlet. This plug cannot be used and should be destroyed.

• To prevent the risk of fire or electric shock, do not expose the unit to rain or moisture.

• Dangerously high voltages are present inside the set. Do not open the cabinet. Refer servicing to

qualified personnel only.

Table of Contents

Introduction

Thank you for choosing this Sony Plasma TV.

Before operating the Plasma TV, please read this manual thoroughly and retain it for future

reference.

Symbols used in the manual

Table of Contents

Safety Information ..................................................................................................................................5

Precautions ............................................................................................................................................12

Checking the Accessories Supplied ...................................................................................................14

Overview

Overview of the Display Unit .............................................................................................................15

Overview of the Media Receiver Unit Buttons and Indicators ......................................................16

Overview of the Remote Control Buttons .........................................................................................17

Installation

Inserting Batteries into the Remote Control .....................................................................................19

Connecting the Display Unit to the Media Receiver Unit ..............................................................20

Connecting the Antenna and VCR .....................................................................................................22

First Time Operation

Switching On the Plasma TV and Tuning the Plasma TV Automatically ....................................23

Menu System

Introducing and Using the Menu System .........................................................................................25

Picture Adjustment ...............................................................................................................................25

Sound Adjustment ................................................................................................................................27

Screen Control .......................................................................................................................................29

Features ..................................................................................................................................................31

Set Up .....................................................................................................................................................34

Timer .......................................................................................................................................................38

Unit Status ..............................................................................................................................................42

“Memory Stick”

On a “Memory Stick” ...........................................................................................................................43

Inserting and Removing a “Memory Stick” ......................................................................................46

Using the “Memory Stick” (Memory Stick Home) ..........................................................................47

.........Important information.

.........Information on a feature.

1,2 ...........Sequence of instructions.

....Shaded buttons on the remote

control show you the buttons you

have to press to follow the sequence

of instructions.

..........Informs you of the result of

instructions followed.

4Table of Contents

Additional Information

Connecting Optional Equipment .......................................................................................................55

Using Optional Equipment .................................................................................................................58

Remote Control Configuration for VCR/DVD ................................................................................59

Specifications .........................................................................................................................................61

Troubleshooting ....................................................................................................................................65

Safety Information

For Safety

AC power cord and display cable

Unplug the AC power cord

and the display cable when

moving the Plasma TV. Do

not move the Plasma TV

with the AC power cord

and the display cable

plugged in. It may damage the AC power cord and

the display cable and result in fire or electric shock.

If the Plasma TV has been dropped or damaged,

have it checked immediately by qualified service

personal.

Medical

institution

Do not place this

PlasmaTVinaplace

where medical

equipment is in use.

It may cause

malfunction of medical instruments.

For the display unit

Installation

Installation of the display

unit on the wall should be

carried out by qualified

servicemen. Improper

installation may render

the display unit unsafe in

the event of an earthquake, etc.

Carrying

Carrying the display unit

requires two or more

people. If you carry the

display unit in a manner

other than that specified,

it may drop and a serious injury may be caused.

Be sure two or more people carry the display

unit. When transporting, do not subject the

display unit to shocks or excessive vibration.

The display unit may fall and be damaged or

cause serious injury.

6Safety Information

Installation and moving

Ventilation

Never cover the ventilation holes in

the cabinet. It may cause

overheating and result in fire.

Unless proper ventilation is

provided, the Plasma TV may

gather dust and get dirty. For

proper ventilation, observe the following:

• Do not install the Plasma TV turned backward or

sideways.

• Do not install the Plasma TV turned over or

upside down.

• Do not install the Plasma TV on a shelf or in a

closet.

• Do not place the Plasma TV on a rug or bed.

• Do not cover the Plasma TV with cloth, such as

curtains, or items such as news papers, etc.

Outdoor use

Do not install this

Plasma TV outdoors.

If the Plasma TV is

exposed to rain, it

may result in fire or

electric shock. If the

Plasma TV is exposed

to direct sunlight, the Plasma TV may heat up

and it may damage the Plasma TV.

Vehicle and ceiling

Do not install this Plasma

TV in a vehicle or hang it

fromthe ceiling.Bumping

of the vehicle may cause

the Plasma TV to fall

down and cause injury.

Ship and vessel

Do not install this

Plasma TV in a ship

or vessel. If the

Plasma TV is

exposedto seawater,

it may cause fire or

damage the Plasma TV.

Water and moisture

Do not use this Plasma TV near water - for example,

near a bathtub or shower room. Also do not expose

to rain. It may result in fire or electric shock.

Cord arrangement

Arrange the power cords or connecting

cords in a safe place to avoid tripping on

them.

For the display unit

Optional accessories

Observe the following when

installing the display unit using a

stand or wall-mount bracket. If not,

the display unit may fall and cause

serious injury.

• Be sure to follow the operating instructions

supplied with your stand when installing the

display unit.

• Be sure to attach thebrackets supplied with your

stand.

Fall

Place the display unit on a

secure, stable stand. Do not

hang anything on the display

unit. The display unit may fall

fromthestandorwall-hanging

rack unit, causing damage or serious injury.

Safety Information

Ventilation

Leave space around the Plasma TV. Otherwise, adequate air-circulation may be blocked causing

overheating and cause fire or damage the Plasma TV.

For the display unit

When installing the display unit on the wall

When installing the display unit using a stand

Never install the display unit as follows:

For the media receiver unit

Media receiver box: Front view

Place the media receiver unit on the

stable level surface so as not to block

the inlets at the bottom of the media receiver

unit.

Media receiver box: Top view

Never place the media receiver unit in a

confined space. It may cause overheating and

result in fire or damage the media receiver

unit.

Ensure reliable operation of the media

receiver unit for proper ventilation of an

exhaust fan.

30cm

10cm10cm

10cm

Leave

this

space

atleast.

30cm

10cm10cm

Leave

this

space

atleast.

Air circulation is

blocked.

Air circulation is

blocked.

Wall

654321

MEMORYSTICK

PROG

4cm

0.5cm

5cm 5cm

Leave

this

space

atleast.

10cm

5cm 5cm

Front

8Safety Information

Power Sources

Overloading

This Plasma TV is

designed to operate on a

220-240V AC supply for

the Media Receiver and

100-240V AC supply for

the Display Unit. Take

care not to connect too

many appliances to the

same AC power socket

as this could result in fire or electric shock.

AC power cord

protection

Pull out the AC

power cord by the

plug.Donotpullon

the AC power cord

itself.

AC power outlet

Do not use a poor fitting AC power

socket. Insert the plug fully into the

AC power outlet. If it is loose, it may

cause arcing and result in fire. Contact

your electrician to have the AC power

socket changed.

Wiring

Unplug the AC power cord when wiring

cables. Besure tounplug the ACpower cord for

your safety, when hooking up.

Moisture

Do not touch the AC power cord

withawethand.If youplug/unplug

the AC power cord with a wet hand,

it may cause electric shock.

Cleaning

Clean the AC power plug

regularly. If the plug is

covered with dust and it picks

up moisture, its insulation

may deteriorate and result in

fire. Unplug the AC power

plug and clean it regularly.

Lightning storms

For your own safety, do not

touch any part of the Plasma

TV, AC power cord or

antenna lead during

lightning storms.

Grounding wires

To avoid electric shock, be sure to connect the

supplied AC power cord to a grounded power

outlet.

Safety Information

Use

Damage requiring service

If the surface of the display unit cracks, do not touch

it until you unplug the AC power cord. Otherwise

electric shock may result.

Ventilation holes

Do not insert anything in the

ventilation holes. If metal or

something flammable enters,

it may result in fire or electric

shock.

Servicing

Do not open the cabinet

and the rear cover of the

Plasma TV. Refer to

qualified service

personnel only.

Moisture and

flammable

• Do not let this Plasma

TV get wet. Never spill

liquid of any kind on

the set. If any liquid or

solid object does fall through, do not operate

thePlasma TV. Itmay result in electricshock

or damage to the Plasma TV. Have it

checked immediately by qualified

personnel.

• To prevent fire, keep inflammable objects or

naked lights (e.g. candles) away from the

Plasma TV.

For the media receiver unit

Object placement

Donot placesomething heavy

on the media receiver unit. It

may damage the media

receiver unit.

Liquid placement

Do not place objects

containing liquid on the

media receiver unit. It may

result in electric shock or

damage the media receiver

unit.

10 Safety Information

Additional Safety Information

Electric shock

Do not touch the Plasma TV with a wet hand. Doing

so may cause electric shock or damage the Plasma

TV.

Broken pieces

Do not throw anything at

the display unit. The

screen glass may explode

by the impact and cause

serious injury.

Protruding location

Do not install the display unit in protruding

locations. If you install the unit in the following

locations, injury may result.

• Do not install the display unit in a location where

the display unit protrudes, such as pillars.

• Do not install the display unit in a location where

your face may bump.

Oils

Donot installthisPlasma TV inrestaurantsthat

use oil. Dust absorbing oil may enter into the

Plasma TV and damage the Plasma TV.

Placement

Neverplace the PlasmaTV in

hot, humid or excessively

dusty places. Do not install

the Plasma TV where it may

be exposed to mechanical

vibrations.

Corrosion

If you use this Plasma TV near the seashore, salt

may corrode metal parts of the Plasma TV and

cause internal damage or fire. It may also

shorten the life of the Plasma TV. If the Plasma

TV will be subjected to none of these

conditions, steps should be taken to reduce the

humidity and temperature of the area where

the Plasma TV is located.

Accessories

Secure the display unit from falling down.

If the display unit is not secured properly, it may fall

and cause injury. Take measures against it using a

stand or other apparatus on the floor or wall in the

specified manner, referring to the operating

instructions supplied with your stand.

Recommended place for

the media receiver unit

Place the media receiver

unit on a stable, level

surface. Otherwise, the

mediareceiverunitmayfall

and cause injury. Use an optional Sony stand,

which has adequate strength.

Weight

Do not stand on the media receiver

unit. The media receiver unit may

fallor bebroken, causinginjury.Pay

special attention to little children.

Cleaning

Unplug the AC power cord when cleaning this

Plasma TV.If not, itmay resultin electric shock.

Keep the connector cap for display interface

cable away from children

A child is likely to choke on it, if swallowed.

In the event of choking, seek immediate medical

attention.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Sony Plasma-TV Handbücher

Sony

Sony KDE-50XS955 - 50" Flat Panel Color Tv Benutzerhandbuch

Sony

Sony WEGA KE-V42A10E Bedienungsanleitung

Sony

Sony KE-32TS2 - 32" Flat Panel Color Tv Bedienungsanleitung

Sony

Sony WEGA KDE-37XS955 Bedienungsanleitung

Sony

Sony WEGA KE-MV42A1 Bedienungsanleitung

Sony

Sony WEGAKE-MX42 Bedienungsanleitung

Sony

Sony KDE-42XBR950 - 42" Xbr Plasma Wega™ Integrated... Bedienungsanleitung

Sony

Sony KE-42XBR900 - 42" Xbr Plasma Wega™ Integrated... Bedienungsanleitung

Sony

Sony KZ-32TS1U Installationsanleitung

Sony

Sony WEGA KE-W50A10E Bedienungsanleitung

Sony

Sony KDE-P42XS1 Bedienungsanleitung

Sony

Sony WEGA KE-50XBR900, KE-42XBR900 Bedienungsanleitung

Sony

Sony KDE-50XS955 - 50" Flat Panel Color Tv Bedienungsanleitung

Sony

Sony KE-32TS2 - 32" Flat Panel Color Tv Bedienungsanleitung

Sony

Sony KZ-32TS1E Bedienungsanleitung

Sony

Sony Wega KE-P37XS1 Bedienungsanleitung

Sony

Sony WEGA KE-V42A10E Bedienungsanleitung

Sony

Sony WEGA KDE-W50A10 Bedienungsanleitung

Sony

Sony Wega KE-P37XS1 Bedienungsanleitung

Sony

Sony WEGA KDE-W50A11E Bedienungsanleitung

Sony

Sony KE-MX42A1 Bedienungsanleitung

Sony

Sony WEGA KDE-37XS955 Gebrauchsanweisung

Sony

Sony WEGA KE-42M1 Benutzerhandbuch

Sony

Sony WEGA KE-37XS910 Bedienungsanleitung

Beliebte Plasma-TV Handbücher anderer Marken

Hitachi

Hitachi 50PD9800TA Bedienungsanleitung

Pioneer

Pioneer PDP-LX508G Bedienungsanleitung

LG 60PM9700 Bedienungsanleitung

LG 50PX4D Bedienungsanleitung

Panasonic

Panasonic Viera TH-37PA20 Bedienungsanleitung

Panasonic

Panasonic TH-103PF12E Bedienungsanleitung

Panasonic

Panasonic VIERA TH-42PZ80Q Bedienungsanleitung

LG 60PA5500 Bedienungsanleitung

VESTEL

VESTEL PL2000 Bedienungsanleitung

VisionQuest

VisionQuest PVQ-32VGB Bedienungsanleitung

Maxent

Maxent MX-5020HPM Bedienungsanleitung

XOCECO

XOCECO PH-42T8 Bedienungsanleitung

Maxent

Maxent MX-42VM7 Bedienungsanleitung

Sampo

Sampo PME-42S6 Bedienungsanleitung

Hitachi

Hitachi 32PD7800 Bedienungsanleitung

LG 50PK550 Bedienungsanleitung

Haier

Haier P42A1-AK Bedienungsanleitung

Insignia

Insignia NS-42P650A11 Bedienungsanleitung
