Sony FD Trinitron WEGA KD-36FS170 Bedienungsanleitung

KD-36FS170

FDTrinitron®WEGA

™

ScanDigitalTV

Key Features

FDTrinitron

PictureTube

ATSCDigitalTuner

3-LineDigitalCombFilter

AudioPower(5Wx2)

ProgramPalette™Presets(Vivid/Standard/Movie/Pro)

AutoChannelProgram

SleepTimer

Clock/Timer(TwoEvent)

SpeedSurf™ChannelSelection

FavoriteChannel

Key Technologies

FD Trinitron

WEGA

Flat Screen

FD Trinitron

®WEGA®Flat Screen Technology is the basis of Sony's award

winning line of visually flat televisions. The FD Trinitron sets deliver incredible image accuracy, wide viewing

angles, outstanding contrast, and corner

corner detail. The visually flat FD Trinitron®tube minimizes annoying

glare from light sources, which enhances contrast. Detail, corner

corner, is rendered more accurately because

images aren't distorted by a curved screen. Squares are square, straight lines appear straight, and circles are

circular.

SonyElectronicsInc.

•

16530ViaEsprillo

•

SanDiego,CA92127

•

1-800-222-7669

•

www.sony.com

LastUpdated:03/06/2007

KD-36FS170

FDTrinitron®WEGA

™

ScanDigitalTV

PleasevisittheDealerNetworkforcurrent

informationatwww.sony.com/dn

Features

General

Auto SAP: Yes

Channel Fix: Yes

Closed Caption (CC): Yes

Magnetic Quadra Pole:

Yes

Video Label: Yes

Video

Tuner: 8 VSB, ATSC

Video Processing:

N/A

Auto White Balance: Yes

Dynamic Picture

™

Processor Circuitry: Yes

Trinitone®Color Temperature: Yes

Vertical Compression: Yes

Screen Modes (4:3): Zoom

ClearEdge VM

™

Technology: High, Medium,

Low, Off

Comb Filter: 3D Digital Comb Filter

Dynamic Focus

™

Circuitry:

Yes

Vertical Aperture Compensation: Yes

Color System: ATSC, NTSC

Screen Technology: FD Trinitron®CRT

Technology

Display Technology: FD Trinitron

Audio

MTS Stereo Decoder:

Yes

Audio Mute: Yes

Dolby®

Digital:

Yes

Convenience

Channel Label: Yes

Channel Skip/Add: Yes

Channel Jump: Yes

Favorite Channel: Yes

Speed Surf

™

Channel Selection: Yes

Auto Channel Programming: Yes

Multiple Language Display:

English; Español;

Français

Parental Control (V-Chip): Yes

Info Banner: Yes

Programmable Timer: 2 Event

Sleep Timer:

15, 30, 45, 60, 90, Off

Caption Vision: On, Off, Program

Clock: Yes

Built

-In AC Adaptor: Yes

Specifications

General

Aspect Ratio: 4:3

Screen Size:

36" measured diagonally

Television Type: Tube

Video

Native Resolution: 1080i

Display Resolution: 480i, 1080i

Program Palette

™

Presets: Vivid, Standard,

Movie, Pro

Audio

Speakers (Total):

Audio Power Output: 10W Total (5W x 2)

Inputs and Outputs

Analog Audio Input(s): 3 (1 Front/2 Rear)

Component Video (Y/Pb/Pr ) Input(s): 1 (Rear)

480i

Composite Video Input(s): 2 (1 Front/1 Rear)

RF Connection Input(s): 2 (Rear)- 1 Analog

(UHF/VHF) and 1 Digital (ATSC)

-Video Input(s): 1 (Rear)

Power

Internal Power Supply: Yes

Power Consumption (in Operation): 160W

Power Requirements: AC 120V, 60Hz

Regulation and Standard Compliance

Energy Star

®Compliant: Yes

Service and Warranty Information

Limited Warranty:

90 Days Labor / 1 Year

Parts / 2 Years Picture Tube

Dimensions

Weight:

216lbs 15oz (98.4Kg)

Measurements: 38 3/4" x 30 1/2" x 24 7/8" (985 x

774 x 633mm)

Supplied Accessories

Instruction Manual

Remote Control (RM-YD006)

AA Battery x 2

Optional Accessories

Television Stand: SU-36FS2

UPC Code: 027242693661

1.Screen sizemeasured diagonally.

Sony,Dynamic Focus,Trinitron,Trinitone, ProgramPalette, Speed Surf,

SteadySound, Hi

Scanand WEGAaretrademarks ofSony. Dolby Digitalis a

trademarkof Dolby LaboratoriesLicensing Corporation.All other

trademarksare propertyof their respectiveowners.

Featuresand specificationsare subject tochange withoutnotice. Non

metricweights andmeasures are approximate.
