Sony Grand WEGA KDF-E60A20 Bedienungsanleitung

KDF-

E60A20

3LCD Rear Projection Television

Shown with optional SU

GW12 A/V stand

Key Features

3LCD Technology

WEGA Engine™System

ATSC Integrated Tuner with CableCARD™

Slot

WEGA GATE™-Easy Operation Guide

HDMI™(High Definition Multimedia Interface) Connector

TOS Link

Dolby®

Digital

Key Technologies

3LCD Panel Technology The 3LCD technology at the heart of Sony’s Grand WEGA™televisions provide a

bright picture, with high detail and natural color. These three key benefits are immediately apparent when

viewing a Grand WEGA™TV. You can expect to see an incredibly detailed picture with eye-popping colors.

Sony uses three tiny LCD panels (0.87”

)

with a combined resolution of over 3.14 million pixels. The light from a

high output UHP lamp shines into a filtering system that splits the beam into red, green, and blue light

streams. Each color goes through its own LCD panel, which passes or blocks the light. The three beams are

then recombined and sent to the projection lens.

WEGA Engine™ System The WEGA Engine™system is Sony’s advanced video processing technology

designed to enhance and improve overall picture quality. All analog and digital video signals are processed in

the digital domain increasing signal while decreasing noise. Various video processing circuits are used to scale

the image, perform interlaced to progressive conversion and remove digital artifacts to improve the overall

picture quality. The result? You will see stunning picture quality characterized by natural looking images that

have amazing texture and detail, and excellent depth and contrast.

HDMI

™ Input and More Designed for maximum versatility, Sony’s Grand WEGA televisions are equipped

with a generous number of input interfaces. The HDMI (High-Definition Multimedia Interface) is the first

industry-supported, uncompressed, all-digital audio/video interface. HDMI supports enhanced or High

Definition video, together with multi-channel digital audio to provide matchless image and sound reproduction.

And multiple inputs such as component video, S-Video, composite video inputs along with a Digital Audio

output and variable/fixed audio output compliment the package.

WEGA GATE®User Guide Explore and navigate your Sony

BRAVIA

™television effortlessly with the

WEGA GATE user guide. You can easily change your settings or access your favorite TV channels and

external inputs. Simply touch the WEGA GATE button on the remote control to activate the comprehensive

graphic menu. Your eyes remain on the screen instead of searching in the dark for tiny buttons on the remote

control.

KDF-

E60A20

3LCD Rear Projection Television

Sony Electronics Inc. • 16530 Via Esprillo Drive • San Diego, CA 92127 • 1-800-222-7669 • www.sony.com

Last Updated: 12/04/2005

Shown with front access A/V connections panel

open

Please visit the Dealer Network for current

information at www.sony.com/dn

Features

General

Auto SAP:

Yes

Channel Fix: Yes

Closed Caption (CC): Yes

ID1 Detection: Yes

Video Label: Yes

Video

Screen or Display Technology:

3LCD

Tuner: 8 VBS, ATSC, NTSC, Clear QAM

Video Signal System: ATSC, NTSC

Video Processing:

WEGA Engine

™

Technology

Color Temperature:

Cool, Neutral, Warm

Color Correction:

High/Low/Off

Noise Reduction: Yes

Black Corrector: High/Medium/Low/Off

Clear White: On/Off

Gamma Compensation: High/Medium/Low/Off

CineMotion

Reverse 3:2 Pulldown

Technology: Yes

Direct Digital II Circuitry: Yes

Wide Mode (16:9):

Wide Zoom, Full, Zoom

Wide Mode (4:3):

Wide Zoom, Normal, Full, Zoom

Comb Filter:

3D Digital Comb Filter

DRC

MultiFunction Circuitry: Yes

DRC

Mode:

High Density, Progressive

DRC

Palette Presets:

Custom 1

Game Picture:

+5 to

Image Shift:

Auto, Level 1, 2, 3, 4

Advanced Video Menu: Yes

Picture Modes: Vivid, Standard, Custom

Audio

Tone Control(s): Treble, Midrange, Bass

Sound Mode: Dynamic, Standard, Custom

MTS Stereo Decoder: Yes

A/V Synch: Off/1/2/3

Digital Amplifier: Yes

Audio Mute: Yes

Speaker On/Off: Yes

Simulated Surround: Yes

SRS

TruSurround

XT Audio Effect: Yes

Dolby

Digital: Yes

Convenience

Channel Label: Yes

Channel Skip/Add: Yes

Channel Jump: Yes

Favorite Channel: Yes

Speed Surf™ Channel Selection: Yes

Program Guide Access: Yes

Auto Channel Programming: Yes

Menu Color: Yes

Multiple Language Display:

English; Espa

ol;

Fran

ais

Parental Control (V

Chip): Yes

Freeze Memo Screen Freeze: Yes

Info Banner: Yes

Programmable Timer:

2 Event

Sleep Timer:

15, 30, 45, 60, 90, Off

Timer Events:

Timer 1, Timer 2

Caption Vision: On, Off, Program

Clock: Yes

Power Save Mode: Yes

Built

in AC Adaptor: Yes

Specifications

General

Aspect Ratio:

16:9

Screen Size:

60"

Video

Native Resolution:

720p

Display Resolution:

1366 x 768

Vertical Size:

+5 to

Vertical Center:

+5 to

Audio

Speakers (Total):

Audio Power Output:

24W Total (12W x 2)

Inputs and Outputs

Analog Audio Input(s):

6 (1 Front/5 Rear)

Audio Out (Variable/Fixed): 1 (Rear)

CableCARD™ Slot: 1 (Rear)

Component Video (Y/Pb/Pr ) Input(s): 2 (Rear)

Composite Video Input(s):

3 (1 Front / 2 Rear)

Digital Audio Output(s): 1 (Rear)

HDMI

™ Connection Input(s):

1 (Rear) with

Audio Input

RF Connection Input(s): 2 (Rear)

Video Input(s):

3 (1 Front / 2 Rear)

Power

Power Consumption (in Operation):

265W

Power Consumption (in Standby):

Less than

15W

Power Requirements:

AC120V, 60Hz

Power Management: Yes

Power Consumption (CableCARD™

Function in Standby): NA

Regulation and Standard

Compliance

Energy Star

Compliant: Yes

Service and Warranty Information

Limited Warranty: 1 Year Parts, 1 Year Labor

Dimensions

Weight:

101.5lb (46.1kg)

Measurements:

62" x 39 5/8" x 20 1/2" (1574 x

1055 x 518mm)

Optional Accessories

GW12 (Optional AV Stand)

XL-

2100 or XL2100U (132W Replacement Lamp)

UPC Code:

027242675339

Confidential Sony Information. For Internal Use Only.

1. "Standby" LED for "Power Management" mode.

2. Screen Size measured diagonally.

Sony, WEGA Engine, Steady Sound and DRC are trademarks of Sony. Dolby

and Dolby Digital are trademarks of Dolby Laboratories. SRS and

TruSurround are trademarks of SRS Labs, Inc. HDMI is a trademark of HDMI

Licensing, LLC. CableCARD is a trademark of Cable Television Laboratories,

Inc. All other trademarks are property of their respective owners.

Features and specifications are subject to change without notice. Non-

metric weights and measures are approximate.
