Sony ICD-47 Primary Bedienungsanleitung

3-231-374-11 (1)

IC Recorder

Operating Instructions

ICD-47

For the customers in the United States

Owner’s Record

The model number is located at the rear and the serial number is located

inside the battery compartment. Record these numbers in the spaces

provided below. Refer to these numbers whenever you call upon your

Sony dealer regarding this product.

Model No. Serial No.

INFORMATION

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance

with the instructions, may cause harmful interference to radio

communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

– Reorient or relocate the receiving antenna.

– Increase the separation between the equipment and receiver.

– Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

– Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

You are cautioned that any changes or modifications not expressly

approved in this manual could void your authority to operate this

equipment.

Table of Contents

What is an IC recorder? ................................................................................ 4

Features .......................................................................................................... 5

Getting Started

Step 1: Installing the Battery........................................................................ 6

Step 2: Setting the Clock............................................................................... 8

Basic Operations

Recording Messages ................................................................................... 10

Playing Back Messages............................................................................... 13

Erasing Messages ........................................................................................ 16

Advanced Operations

Moving Messages to a Different File — Move Function ....................... 18

Adjusting the Playback Speed .................................................................. 19

Adding a Recording to a Previously Recorded Message ...................... 20

Playing Back a Message at a Desired Time with an Alarm ................... 21

Preventing Accidental Operation — HOLD function ........................... 25

Menu Settings

Turning off the Beep Sound ....................................................................... 26

Selecting the Microphone Sensitivity....................................................... 27

Playing Back All Messages in a File Continuously ................................ 28

Additional Information

Precautions ................................................................................................... 29

Troubleshooting .......................................................................................... 30

Specifications ............................................................................................... 31

Index to Parts and Controls ....................................................................... 32

Menu map .................................................................................................... 34

Index .............................................................................................. Back cover

What is an IC recorder?

This IC recorder enables you to record and play back oral messages in the

built-in IC memory.

zRecording

When a new message is recorded, it is automatically added after the last

recorded messages.

Unlike with tape recorders, you do not need to worry about recording over

previously recorded messages by mistake.

Since you do not need to search for the end of the last recording, you can

start recording quickly whenever you wish.

zPlayback

With this IC recorder, you can quickly locate the message you want to play

back.

Reviewing the current recording is also very easy.

zErasing

You can quickly erase unwanted messages with an easy operation. When a

message is erased, the next message automatically advances, leaving no

blank space.

Meet Mr. Brown at

2 p.m. tomorrow.

11:30, November 1 12:00, November 1 10:00, November 2

Don’t forget

to call Mary Make remittance

at ABC bank

9:00, November 4

Send a card to

Miss Smith

Message 1 Message 2 Message 3

Message 4

Remaining messages

are renumbered.

Message 1 Message 2 Message 5

Message 4Message 1 Message 2 Message 3

Message 3

Message 4

After

Before

Erase Message 3

Features

•90 minutes recording time

This unit is useful for recording messages or appointments.

•Organizing message files

You can choose among 3 different files to record and store your

messages.

You can easily move messages from one file to another (see page 18).

Up to 99 messages can be recorded in each file.

•Alarm function

You can start playing back a desired message with an alarm on a desired

date and time (see page 21). You can use this function to remind you of

the time of the meeting, etc.

•Playback speed control

You can play back messages rapidly (+50%) or slowly (–25%) (see page

19). This is useful when playing back a long recording. The sound pitch

will be automatically adjusted when you change the playback speed.

•Adding a recording to previously recorded message

You can add a recording to the message being played back to count as

one message (see page 20).

Slide and lift the battery

compartment lid.

Insert one LR03 (size AAA)

alkaline battery with correct

polarity, and close the lid.

If the battery compartment

lid is accidentally detached,

attach it as illustrated.

Step 1: Installing the Battery

To take out the battery

Take out the battery by pushing

the #side of it as illustrated.

Getting Started

Clock setting display appears when you insert battery for the first time, or

when you insert battery after the unit has been without battery for a

certain period of time. Please refer to Steps 2 to 4 in “Step 2: Setting the

Clock”on pages 8 and 9 to set the date and time.

Replacing the battery

“E“appears on the display when the battery becomes weak and it flashes

when the battery is exhausted. Replace the battery with a new one.

Battery life*

With continuous use, approx. 5 hours recording/4.5 hours playback

* Using Sony alkaline battery LR03 (SG), playing back through the internal

speaker with VOL control at around 3

The battery life may shorten depending on the operation of the unit.

Notes

•Do not use manganese batteries for this unit.

•When you replace the battery, insert the new one within 3 minutes after you

removed the exhausted one. Otherwise, the display may show the clock

setting display or incorrect date and time when you reinsert the battery. In this

case, set the date and time again.

The recorded messages, however, will remain.

•Do not charge a dry battery.

•When you are not going to use the unit for a long time, remove the battery to

prevent damage from battery leakage and corrosion.

Clock setting display appears when you insert battery for the first time, or

when you insert battery after the unit has been without battery for a

certain period of time. In this case, proceed from Step 2.

Display the clock setting display.

Set the date.

Step 2: Setting the Clock

1Press MENU to enter

the menu mode.*

2Press –.once to display

“SET DATE”.

3Press NxPLAY/STOP.

The year digits will flash.

2Press NxPLAY/STOP.

The month

digits will flash.

3Set the month and day in

sequence, then press

NxPLAY/STOP.

The hour

digits will

flash.

1Press –.or >+ to select the digits of the year.

* The “ALARM”display may

appear instead of the “BEEP”

display (see page 34).

Getting Started

Set the time.

Exit from the menu mode.

Press MENU.

2Press NxPLAY/STOP.

The minute digits will flash.

3Set the minute.

4Press NxPLAY/STOP at the

time signal.

The display will return to

“SET DATE”.

1Press –.or >+ to select the digits of the hour.

Recording Messages

You can record up to 99 messages in each file (A, B and C).

Since a newly recorded message is automatically added behind the last

recorded message, you can start recording quickly without searching for

the end of the last recording.

Select the file.

Start recording.

During recording, the OPR indicator lights up in red.

You do not need to keep pressing REC START/STOP while recording.

Press FILE repeatedly until

the desired file is

displayed.

Current file

1Press REC START/STOP.

Current message

number

Remaining recording time

2Speak to the built-in

microphone.

OPR indicator

Message 1 Message 2 Blank space

Newly recorded message

e.g.
