Spedo Optical Loop Interface 2232 Instruction Manual
Spedo Optical Loop Interface 2232
Instruction Manual
Issue 2
Spedo UK Limited
76 Woolmer Way
Bordon
Hampshire
GU35 9QF
E GLA D
Telephone:
+44 (0) 1420 487 447
Fax: +44 (0) 1420 477 827
Web: www.spedouk.com
2 | P a g e
2
Spedo Optical Loop Interface 2232 Instruction Manual
Spedo Optical Loop Interface 2232
History Sheet
Manual Issue Date Changes Incorporated
1 January 2013 First Issue
2 May 2015 Format hanged
3 | P a g e
3
Spedo Optical Loop Interface 2232 Instruction Manual
Spedo Optical Loop Interface 2232
Publisher
Published by Spedo UK Limited
76 Woolmer Way
Bordon
Hampshire
GU35 9QF
E GLA D
Copyright
Spedo UK Limited 2013
All Rights Reserved.
o part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or by any means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written permission of Spedo UK Limited.
Unpa k
Unpack the equipment and examine it thoroughly to ascertain whether any damage
has occurred in transit. Report immediately any such damage to the agent or
manufacturer. Retain the packing should further transportation be necessary.
All Goods
All goods manufactured by the Company are guaranteed to the extent hereafter
mentioned against defects arising from faulty material or workmanship subject to
the goods not having suffered maltreatment or interference. The Company's liability
under this guarantee is limited to replacing any part or parts found defective within a
period as laid down in Company instructions after the date of delivery or installation.
Other Goods
If goods not of the Company's manufacture are ordered, the guarantee of that
company is to be accepted.
Des riptive Matter
Descriptive matter, illustrations, dimensions and weights issued by the Company are
typical and shall not be held as binding.
Patterns and Designs
The Company reserves the right to alter patterns and designs without notice.
First Published
January 2013
We have taken every care in the preparation of this manual. If there are any
inaccuracies, ambiguities or omissions, Spedo UK Limited and its consultants and
distributors cannot accept responsibility for any loss or damage these errors may
cause.
4 | P a g e
4
Spedo Optical Loop Interface 2232 Instruction Manual
Spedo Optical Loop Interface 2232
Safety Measures
This instruction manual contains certain WAR I G and CAUTIO notices which must be
followed by the user to ensure safe operation and to retain the equipment in a SAFE condition.
All users of the equipment described in this manual MUST have received adequate training in its
use and application in order to ensure SAFE A D PROPER USE.
Any adjustment, maintenance or repair of the opened apparatus under voltage shall be carried
out only by a skilled person who is AWARE OF THE HAZARD I VOLVED.
5 | P a g e
5
Spedo Optical Loop Interface 2232 Instruction Manual
Spedo Optical Loop Interface 2232
T
ABLE OF
C
ONTENTS
History Sheet ......................................................................................................................... 2
Copyright ............................................................................................................................... 3
Safety Measures .................................................................................................................... 4
Table of Contents .................................................................................................................. 5
D
ESCRIPTION AND
O
PERATION
. SECTION
1
I TRODUCTIO ..................................................................................................................... 6
TECH ICAL DATA ................................................................................................................... 6
DESCRIPTIO OF OPERATIO ................................................................................................ 7
Optical Loop Interface Unit .............................................................................................. 7
Operation with Ancillary Units ......................................................................................... 7
I STALLATIO ....................................................................................................................... 8
OPERATI G I STRUCTIO S ................................................................................................... 9
Paper Detection Range Adjustment ................................................................................. 9
Printer Output Delay Adjustment .................................................................................. 10
OPERATIO AL MAI TE A CE ............................................................................................ 11
6 | P a g e
6
ESCRIPTION & OPERATION SECTION 1 Instruction Manual
DESCRIPTION & OPERATION SECTION 1
INTRODUCTION
Optical Loop Interface Unit is designed to control the height of the paper loop that forms between an
outfeeding printer or unwinder and the associated infeeding Spedo Forms Cutter. A forms cutter of other
manufacture can be used provided it is fitted with a synchronisation input facility. The unit is positioned on
the floor, mounted on 4 feet between the two units.
Fig 1 1 Spedo Optical Loop Switch 2232
TECHNICAL DATA
Paper Loop Syn
Switched relay contact normally open. Closed across pins 1 & 3 when paper is detected
Mains Power
240 V +/- 10 %, 50/60 Hz.
Mains Fuse
800 mA (Type F800mA)
Dimensions
Depth: 26 cm (incl. feet)
Width: 60 cm
Height: 26 cm (incl. feet)
Weight (with leads):
8.6 kg (approx.)
7 | P a g e
7
ESCRIPTION & OPERATION SECTION 1 Instruction Manual
DESCRIPTIO OF OPERATIO
Opti al Loop Interfa e Unit
This unit consists of a box assembly with 2 optical sensors (fitted in the centre of the top cover), which
operate in conjunction with a opto sensing board inside the unit. The optical sensors detect the presence
of the paper loop between the outfeeding printer or unwinder and the infeeding forms cutter and
maintains it at a height set by the operator. It has a maximum height detection range of 300 mm, which
can be adjusted internally.
Fig 1.2 Identification of Main Parts
Operation with An illary Units
Optical Loop Interface Unit is supplied with mains power from the forms cutter by interconnecting it with
the mains lead supplied. The sync lead is also connected to the forms cutter. Several cables are provided
for interfacing with input devices and care must be taken to ensure the correct cable is used.
Both sensor have been factory set for optimum running conditions (300mm for the cutter control sensor
and 100mm for the printer control sensor) but these can be adjusted if necessary.(see page 9)
Printer Control Sensor
Cutter Cont
rol Sensor
Printer Interface Output
Mains Power Input
Fuse 800mA
Cutter Interface Output
Status Indicators
8 | P a g e
8
ESCRIPTION & OPERATION SECTION 1 Instruction Manual
I STALLATIO
Position optical loop box in front of the cutter so that both sensors are aligned with the
paper web.
Ensure all cables are fitted to the corresponding plugs and tighten into position.
Fig 1 3 Operating States
Switch on the forms cutter. Check that the optical loop interface unit is now powered up and
the ADEV RU and the ADEV READY indicators are illuminated.
Place a piece of paper in front of the cutter control sensor and check that, at a maximum of
300 mm, the CUTTER RU indicator toggles on and off as the paper is moved inside and
outside the sensing range.
Place a piece of paper in front of the printer control sensor and check that, at a maximum of
100mm the ADEV RU indicator toggles on and off. ote: this output is on a time delay of
approximately 2 seconds. This time delay can be adjusted as required. (see page 9).
If the above check is satisfactory, the unit is ready to operate.
9 | P a g e
9
ESCRIPTION & OPERATION SECTION 1 Instruction Manual
OPERATI G I STRUCTIO S
WARNING: ever operate the combined system when wearing items of loose clothing or
other decorative jewellery, such as necklaces or bracelets as they could become entrapped
in the ancillary machinery and cause injury.
Having checked the serviceability of the unit, as in Installation above, it may be required to
adjust the range of detection of the opto sensors for your particular system.
Paper Detection Range Adjustment
WARNING: High voltage mains is present on this equipment. Ensure that the equipment is
isolated from the mains supply when carrying out any adjustments.
The adjustment control and associated indicator are housed on the opto sensor assembly
and can only be accessed from inside the unit.
With the mains power disconnected, remove x6off M4x12 screws and carefully lift off the
top cover. ote: this cover is attached to cables which connect directly to control board.
Fig 1.4 Paper Detection Range Adjustments
The adjustment control and indicator are located at the end of the opto sensor. The
indicator illuminates when paper is detected.
Reconnect the mains power. Place a piece of paper in front of the opto sensor. Adjust the
setting of the control, at the same time as moving the paper towards and away from the
front of the opto sensor, noting the distance at which the indicator lights. Vary the setting
until the required distance is reached.
Disconnect the mains power and refit the top cover.
Position the unit back into the system and reconnect it, ready to continue operation.
10 | P a g e
10
ESCRIPTION & OPERATION SECTION 1 Instruction Manual
Printer Output Delay Adjustment
WARNING: High voltage mains is present on this equipment. Ensure that the equipment is
isolated from the mains supply when carrying out any adjustments.
The adjustment potentiometer is located on the control PCB and can only be accessed from
inside the unit. (Fig1.5)
With the mains power disconnected, remove x6off M4x12 screws and carefully lift off the
top cover. ote: this cover is attached to cables which connect directly to control board.
Fig 1.5 Printer Output Delay Adjustments
Reconnect the mains power
Adjust the potentiometer VR1 (R8 on earlier models). Test the reaction time of the printer
control sensor by covering and uncovering and checking the delay on the ADEV RU
indicator.
Disconnect the mains power and refit the top cover.
Position the unit back into the system and reconnect it, ready to continue operation.
