SPEEDWOLF
—FS18 Fusion Splicer User’s Manual
Shenzhen Speedwolf Technology Co.,LTD
A-14,Haide Building, Nanxin Road Nanshan District,Shenzhen,P.R.China
If you have any question,please contact us directly for help,Email: speedwolf@speedwolf.net
1. Brief Introduction
Shenzhen SPEEDWOLF Technology CO.,LTD. specializing in the production of optical fiber
fusion splicer, optical fiber cleaver, OTDR, light source, optical power meter, and optical fiber
fixture, and other optical communication instrument high-tech enterprises. Company production of
OP-FS16,FS18fiber splicing machine is not only widely used in China Telecom, China Mobile,
Unicom, radio and television major domestic telecommunications operators, but also exported to
South America, Europe, Russia, Southeast Asia and Africa and other parts of the world.
1.1 Specifications
0.02dB(SM)，0.01dB(MM)，0.04dB(DS)，
Core to Core Alignment by PAS technology
Cable indoor and 0.25mm,0.9mm fiber, SC
connector(option)
Fiber Image/ Magnification
5 inch digital high-quality LCD screen
60mm, 40mm and serials heat Shrinkable Sleeve
200 cycles splicing and heating, 3 hours charging time
( splicing and charging at same time)
Cycling charge 300-500 times, easy to replace battery
3000, easy to replace electrodes
USB Convenient data download and software update
Built in high brightness, wide range of lights, easy to
operate at night
Built in lithium battery 5200mAh 11.1V; external
adapter, input: AC100-240V, output: DC13.5V/4.5A
0-5000m above sea level, Temperature: -10-60℃,
Humidity:0～95%RH (No dew)
Weight (including battery)
1.98 KG (including battery)
135mm(L)×158mm(W)×155mm(H)
