CONTINUOUS RECORD MODE :
1. This setting will keep the unit turned on and continuously recording with roughly 9-hours of battery life.
With no adjustments made through the Camera Widget, this will be the default recording mode when
turning on the device.
MOTION RECORDING MODE:
This setting is made available through the Camera Widget for Z82/Z86 desktop application, which works
with both Windows and Mac computers: http://zetta.com.hk/index.php/supports/downloads .
1. Download the Camera Widget and open the program.
2. Connect the device to the computer.
3. Within the “Settings,” choose the level of motion detection sensitivity between High, Medium, or Low .
Choosing Always On will not increase the battery life, but it will enable faster triggering of a new
recording. Choosing Max Battery will put the device into a low-power standby state that can last up to 1
month with no motion to trigger the camera.
4. Click Save Option when finished.
SETTING THE DATE AND TIME:
1. Download the Camera Widget and open the program.
2. When the app is opened, the first page shows “ Sync Date and Time to DVR ” listed in the upper right.
3. Click this button.
4. When the item is disconnected from the computer, future recordings will have the correct date and time
stamp, as long as the device has not lost all of its battery supply.
SPECIFICATIONS:
Charge Time: 6-8 Hours
Sensor FOV: 120 Degree Field of View
Memory: Max 256GB SD Card
Memory Consumption: 1.5 GB / 1 Hour ( low quality ), 2GB / 1 Hour ( medium quality ), 3GB / 1 Hour (
high quality )
Recording Picture: HD 1080p (1920x1080)
Motion detection range: 4 to 7 meters (13 to 23 ft)
Voice recording: 32kbps
File Format: .MP4
USB: Mass storage device
OS supported: Windows 2000 / XP / Vista / 7 / 8 / 10, Mac OS X
Storage temperature: 0 to 45degC (32 to 113degF)
Operating temperature: 0 to 45degC (32 to 113degF)
Size: 9 x 5.8 x 2.8 cm (3.54" x 2.3" x 1.1")
Battery: 2900mAh 3.7V Li-ion battery
Adapter : 5V, 1000mA DC adapter (not included in package)
Current consumption: 290mA
