Stairville SF-80 Bedienungsanleitung

Owner‘s Manual

FOG MACHINE

SF-80

- 2 -

Thank you for choosing one of our fog machines. You now own a rugged

and powerful state-of-the-art machine. Prior to use, we suggest that you

carefully read all of the instructions. By following the suggestions found

in this user manual, you can look forward to the reliable and satisfactory

performance of your fog machine for years to come.

1. Cautions

For your own safety you must read this section in full

rst!

Never drink fogger liquid. If it is ingested, call a doctor immediately. If•

Fogger liquid comes in contact with skin or eyes, rinse thoroughly with

water.

Donotoverllyour• fog machine.Overllingwillcausetheunittoclog.

If your• fog machine fails to work properly, discontinue use immediately.

Drain all fogger liquid from the tank, pack the unit securely (preferably

in the original packing material), and return it to your fogger dealer for

service.

Danger of electric shock or burns

Keep this device dry. For inside use only. Not designed for outside use.•

For the 230V models, use 3-prong grounded electrical outlet only. Prior to•

use take care to determine that the unit is installed at the rated voltage.

Always unplug your• fog machinebeforellingitstank.

Keep Fogger upright.•

Turn off or unplug when not in use.•

This machine is not water-or splash proof. If moisture, water, or fog•

liquid gets inside the housing, immediately unplug the unit and contact a

service technician or your fogger dealer before using it again.

No user serviceable parts inside. Refer to your Fogger dealer or other•

qualiedservicepersonnel.

The output nozzle becomes very hot during operation (300 °C). Keep•

ammablematerialsatleast60cmawayfromthenozzle.

Always allow your fog machine to cool down before attempting to clean•

or service it.

For adult use only. Fogger must be installed out of the reach of children.•

Never leave the unit running unattended.•

Neveraimtheoutputatopenames.•

- 3 -

Danger of explosion

Neveraddammableliquidsofanykind(oil,gas,perfume)tothe• fog

machineliquidortheuidcontainer.

Pay attention to all warning labels and instructions printed on the•

exterior of your fog machine.

Neverletthefoggercloseuptoanyame,ammableorexplosive•

substancetoavoidreandexplosive.

Useonlyhigh-qualityliquidorsuitabledealerrecommendedfoguid.•

Alwaysmakesurethereissufcientliquidinthe• fog machine liquid

tank. Operating this unit without liquid may cause permanent damage to

the machine.

2. Unpacking & Inspection

Open the shipping carton and verify that all equipment necessary to•

operate the system has arrived intact.

Your• fog machine should be accompanied by the following items:

1. Thisusermanual!

2. Power cord

3. Multi-function remote control with attached cord

If any equipment is missing contact your• fog machine dealer immediately.

Pleasealsocontactyourvendorwhenyoundanydestroyedor•

omitting parts.

Before beginning initial setup of your• fog machine, make sure that there

is no evident damage caused by transportation. In the event that the

unit’s housing or cable is damaged, do not plug it in and do not attempt

to use it until after contacting your fog machine dealer for assistance.

3. Setup

Remove all packing materials from shipping box, check that all foam•

and plastic padding is removed, especially in the nozzle area.

Placethefogmachineonaatsurfaceandremoveliquidtankcap.•

Pour high quality fog water-based liquid into the liquid tank, being•

carefulnottoexceedthemaximumuidlevel.DONOTOVERFILL.Use

onlyourFoggerLiquidorotherdealer-recommendedhigh-qualityfog

uid.Anyothertypesofuidcandamagetheunit.Whenthecontainer

is full, place the cap back on the liquid tank and tighten.

Firmly attach remote control cable to the proper input on the rear of the•

machine.

- 4 -

4. Operation

Plug the power cord into a properly wired and grounded electrical outlet.•

Turnthepowerswitchonrearofunittoposition“1”.Warm-upiscom-

pleted when the green lamp lights up on the remote unit.

To emit fog, press the button on the remote for the desired length of•

time.

The remote unit’s lamp will cycle on and off as the machine re-heats to•

the proper operating temperature.

As your model includes a mounting bracket designed for overhead in-•

stallation,itmaybeinstalledatoorlevelorsuspendedoverhead.Ifthe

unit is to be mounted using the bracket, it is important that the fog does

notshootdirectlyatanyone’sface.Whateverinstallationmethodyou

choose, do not allow the unit to have more than a 15 degree angle of

inclination.

Important:

Alwaysmonitortankuidlevelduringoperation.Thefogmachinecan

sufferdamagewhenrunwithoutuid.Ifthemachinedoesnotfunction

afterhavingbeenrunwithoutuid,pleasecontactyourFoggerdealerfor

service.

Fog Liquid

The• fog machine operates on regular fog liquid. The machine has been

designed to produce exceptional haze using Stairville fog liquids. Use

onlyourhighqualityfogliquidsorotherdealerrecommendedfoguids.

Failure to use high quality fog liquid can damage the machine.

TheFoggercanonlybeoperatedusingfoguidsoruids•

recommended by your dealer that are designed to be used exclusively

in the fog machine.

Do not allow the fog liquid to become contaminated. Contamination•

includes adding fragrances, oils, dust or any other foreign materials to

the fog liquid supply. Always replace the caps on the fog liquid container

andtheFogger’sliquidtankimmediatelyafterlling.

5. Cleaning

After every 40 hours of continuous operation, we recommended to run

a cleaning solution composed of 80% distilled water 20% white vinegar

through the system to prevent the accumulation of particulate matter in the

heating element. Please follow these guidelines:

- 5 -

1. Whiletheunitisunpluggedandcooleddown,unscrewthenozzleat

the very front of the unit and clean out debris with vinegar and a pipe

cleaner, making sure that the hole is free of clogs.

2. Emptyallfoguidfromthemachine.Addcleaningsolutiontothetank.

Plug the unit in and let it warm up.

3. Run the unit in a well-ventilated area, until the tank is empty.

4. Replace the nozzle.

5. Cleaningisnowcompleted,rellwithfogliquid.

6. Troubleshooting

If you experience low output, pump noise or no output at all, unplug the

unitimmediately.Checktheuidlevel,theexternalfuse,remoteconnec-

tion, and power from the wall outlet. If all of the above appears to be O.K.,

plug the unit in again. If fog does not come out after holding the remote

button down for 30 seconds, check the hose attached to the tank to make

surethereisuidgoingthroughthehose.Ifyouareunabletodetermine

the cause of the problem, do not simply continue pushing the remote but-

ton, as this may damage the unit. Return the machine to your dealer.

WARNING!

Neverblockventilationholes!X

Nevertouchtheunitwhenit‘shot!X

No user serviceable parts inside. Refer to your Fogger dealerX

orotherqualiedservicepersonnel.

7. Specification

Rating Voltage: 220-240V~/50Hz

PowerConsumption:  700W

Fuse: 5A/250V

Tankcapacity:  1,0Liter

Dimensions:   33x16x13cm

Weight:   ca.4kg

Aswecontinuouslystrivetoimproveourproducts,allspecicationsand

appearance are subject to change without prior notice.

Keep this manual for future reference.

- 6 -

8. Disposal

Do not dispose of the device at the end of his operating life

in your normal domestic waste. This device is subject to

the European Guidelines 2002/96/EC.

Have the product disposed of by a professional disposal company of by•

your communal disposal facility.

Observe the currently applicable regulations. In case of doubt contact•

your disposal facility.

Dispose of packaging materials in an environmentally•

responsible manner.

- 7 -

Contact:

Musikhaus Thomann

Treppendorf 30

96138Burgebrach

Germany

www.thomann.de
