Stannah FE Bedienungsanleitung

Harmony FE Homelift

User Manual

ENG Original instructions

Stratum FE Homelift

User Manual

ENG Original instructions

CONTENTS

Description 4

General Do’s and Don’ts 5

Controls and Operation 7

Smoke Alarms 9

Emergency Procedures 10

Fault Finding 14

Changing Call Station Batteries 17

Lift Disassembly / Safe Disposal of Hazardous

Materials

Service History Record 19

Declaration of Conformity 20

Lift Specication Sheet 21

DESCRIPTION

The Stratum FE Homelift is designed for use by persons with

impaired mobility travelling between fixed floor levels in private

dwellings.

The lift is capable of transporting two people, one of whom could

be a wheelchair user (excludes Stratum FE C). This lift is not

intended for the transporting goods.

The lift is designed to operate without a lift shaft and is provided

with an automatic infill panel which makes the ceiling aperture

safe when the lift is at the lower level.

A telephone is supplied in the car for emergency communication.

A half hour fire rating is provided as standard while the lift is at

the upper or lower level.

The lift car panels are made from powder coated steel which

can easily be cleaned using normal household cleaners. Internal

upholstery can also be cleaned in the same way.

A smoke detection system has been installed on your lift. It has

been designed to provide adherence to British Standard BS5900

2012 Section 9.13 “Behaviour of homelift in the event of fire”.

GENERAL DO’S AND DON’TS

• Never switch off the power supply to the lift, even when you

go away. The lift control circuits are fed by a battery, which

must be kept on constant charge.

• The lift should always be returned to the lower level when

not in use. If it is left upstairs for prolonged periods, it will

occasionally re-level itself depending on conditions. The lift

must be left at the lower level if the mains is turned off.

• Never allow children to play in, under or around the lift.

• Ensure that the area under the lift is kept clear. The underpan

surface is fitted with sensors, which automatically stop the lift

if it strikes an object (page 6).

• Always keep your emergency door release key and key fob in

a safe place near the lift.

• Do not place any object on the aperture infill or stand on it

when the lift is in operation. Ensure that as far as practical,

the area around the travelling infill panel is clear of persons

(particularly children) when the lift is being operated. The

infill panel is fitted with sensors that automatically stop the

lift if the infill panel is obstructed (page 6).

• Do not use this lift for anything other than transporting

people.

• Always treat your lift with respect that should be shown to

electrical and mechanical equipment.

• Users with wheelchairs should apply the brakes on their chair

before moving the lift.

• Safety related components should only be adjusted and reset

by a competent person.

• Proceed with caution when exiting the carriage backwards.

Trapdoor

Underpan safe edge (sensor

on lower and upper surface)

Figure 1. lift shown part-way through aperture

Lift safety sensors

The diagram below (Figure 1) shows the safety edges and

surfaces on your lift.

Lower door safe edge

Top cap

CONTROLS AND OPERATION

To operate the lift you can use the two wall mounted call stations

(Figure 2), one at each level and similar control station fitted in

the lift car. To isolate the lift you can use the optional remote

control fob (Figure 3) to prevent travel. The lights in the car

will switch on automatically when you press any call or control

button and will automatically turn off after a few minutes.

If you stop the lift it cannot be restarted for 3 seconds.

Wheelchair users should apply their brakes before starting the

lift.

DOWN

DOOR

STOP

Figure 2. Wall mounted call station

Figure 3. Optional

remote isolate fob

General operation

• Call the lift by pressing the up arrow if you are at the upper

level or down arrow if you are at the lower level

• Press the door button to open the door.

• Enter the lift. Users with wheelchairs should apply the brakes.

• Press the door button to close the door. Press the button for

the direction that you wish to travel and the lift will travel

uninterrupted to the next floor.

• At any point during travel the stop button can be used to stop

the lift.

• When at either level, the door button can be used to open and

close the door. If the door is moving, pressing this button will

stop the door and make it move in the opposite direction.

• When the lift is not being used, send it to the lower level

whenever possible.

Light Control

The brightness of the lights that illuminate the car and the time

for which they stay on can be altered using the call station.

To change the brightness, press and hold the stop button. Press

the up button and the lights will get brighter. Press down and the

lights will get dimmer.

To change the light timer, press and hold the stop and door

buttons. You should hear two short beeps. Press the up button

to increase the time and the down button to decrease the time.

When up or down is pressed, a series of beeps will sound, where

each beep represents 2 minutes of light-on time. The minimum is

4 minutes or 2 beeps.

SMOKE ALARMS

When installed on a Stratum FE Homelift, the smoke alarm

system will cause the lift to deactivate safely once the alarm is

triggered. When deactivated, the door will continue to operate as

normal.

When the Lift is stationary at either level

If smoke is detected, the alarm will sound. After a period of time,

all other smoke alarms connected to the system will then start to

sound and the lift deactivates.

When the Lift is travelling between levels

If smoke is detected, the alarm will sound. After a period of time,

all other smoke alarms connected to the system will then start to

sound.

The lift will continue to its requested level, it will remain possible

(until that level is reached) to change the direction of the lift.

Once at the desired level, the lift will deactivate.

Reactivation of Lift

The lift will automatically reactivate two minutes after the smoke

alarms no longer detect smoke.

Silencing the Smoke Alarms

The alarms can be silenced by pressing the mute button on

the sensor that initiated the alarm. The initiating sensor can be

identified by a red light flashing every second.

When the alarms are deactivated, the lift will automatically

reactivate when the period of two minutes has expired. If the

source of the smoke alarm is not removed, the smoke alarms will

beginn to sound again and the lift will be disabled.

EMERGENCY PROCEDURES

In the event of a mains failure during travel, the battery backed

control system of the Stratum FE Homelift will allow normal

operation in the down direction without loss of any safety

features. This allows the user to exit the car at the lower level in

the normal way.

Emergency Battery Lowering

In the unlikely event that the lift stops responding normally to the

control station, the lift can be lowered from inside the carriage.

This allows the lift to move downwards while the underpan and

lower door safety surfaces remain operational.

• This emergency battery lowering procedure should never

be used if the lift is at the upper level.

• On the middle back panel, remove the small central cover to

reveal the button control panel.

• Press and hold the E.LOWER button. The lift will move in the

downward direction.

• When at the bottom level, press the door button to open the

door.

• If the door does not unlock, follow the Emergency Unlocking

procedure in this manual.

Figure 4.
