StarTech.com SECTBLTPOS Bedienungsanleitung

Manual Revision: 12/04/2018

For the latest information, technical specications, and support for

this product, please visit www.startech.com/SECTBLTPOS.

FR: Guide de l’utilisateur - fr.startech.com

DE: Bedienungsanleitung - de.startech.com

ES: Guía del usuario - es.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

IT: Guida per l’uso - it.startech.com

SECTBLTPOS

Secure iPad Enclosure with Surface Mount

*actual product may vary from photos

Instruction manual

Table of Contents

Introduction............................................................................................1

Packaging contents.................................................................................................................................. 1

Product diagram ....................................................................................3

Front view .................................................................................................................................................... 3

Rear view...................................................................................................................................................... 3

Assemble the iPad enclosure ...............................................................4

Attach the pads to the plates................................................................................................................ 4

Insert an iPad.............................................................................................................................................. 7

Attach the iPad enclosure to a wall .................................................................................................... 8

Attach the iPad enclosure to a table or desk................................................................................... 9

Set up the iPad enclosure on a table or desk.................................................................................. 10

Attach the iPad enclosure to a universal VESA mount ................................................................ 11

Technical support...................................................................................12

Warranty information............................................................................12

Instruction manual

Introduction

The SECTBLTPOS provides a secure way to mount your iPad to a table, wall, or standard

VESA monitor mount. You can use the SECTBLTPOS to create a secure point-of-sale

system, an interactive marketing kiosk, or an educational display.

The SECTBLTPOS is designed to be used with the iPad, iPad 2, iPad (3rd generation), iPad

(4th generation), or the iPad Air.

Packaging contents

Mounting bracket

Qty: One

Front plate

Qty: One

Rear plate

Qty: One

Keys

Qty: Two

19x16x3 mm EVA pads

Qty: Four

12x100x15 mm EVA pads

Qty: Two

25x100x15 mm foam pads

Qty: Two

M4x8 mm hex screws

Qty: Four

2.5 mm Allen key

Qty: One

12 3

456

Instruction manual

45x15x2 mm EVA pads

Qty: Eight

12.7x2 mm rubber pads

Qty: Four

5x20 mm self-tapping screws

Qty: Three

15.4x5.0x2.0t at washers

Qty: Three

35x1.0t at washers

Qty: Two

Instruction manual

Qty: One

10 12

13 15

Instruction manual

Product diagram

Front view

Bracket

Front plate

Rear plate

Security lock

Rear view

Bracket

Rear plate

Front plate

Instruction manual

Assemble the iPad enclosure

Attach the pads to the plates

1. Use one of the security keys (4) to unlock the plates.

2. Remove the front plate (2) from the rear plate (3) (gure 1).

gure 1

Security lock

3. Turn over the front plate.

4. Remove the backing from four of the 45x15x2 mm EVA pads (10).

5. On the front plate, ax a pad in the center of each of the four sides of the

rectangular-shaped opening (gure 2).

gure 2

6. Remove the backing from the four 19x16x3 mm EVA pads (5).

7. On the rear plate, ax a pad on the inside of each of the tabs so that the pads are on

the side of the tabs closest to the center of the plate (gure 3).

Security lock

Instruction manual

8. Remove the backing from the two 25x100x15 mm foam pads (7).

9. On the rear plate, ax the pads in front of the tabs on the sides closest to the center

of the plate (gure 4).

gure 4

gure 3

10. Depending on the version of iPad that you’re using, do one of the following:

• If you’re using an iPad (1st generation), remove the backing from two of the

45x15x2 mm EVA pads (10). On the rear plate, ax a pad to each of the raised

edges on the long sides of the plate (gure 5).

• If you’re using an iPad 2, iPad (3rd generation), or iPad (4th generation), remove

the backing from four of the 45x15x2 mm EVA pads (10). On the rear plate,

ax a pad to each of the raised edges on the long sides of the plate. Ax a

second pad on top of each of the pads that you just attached, so that there are

two pads on each of the raised edges on the long sides of the plate (gure 6).

• If you’re using an iPad Air, remove the backing from the two 12x100x15 mm

EVA pads (6). Ax the pads on the rear plate, ush against the raised edges on

the long sides of the plate (gure 7).

Instruction manual

gure 7

gure 5

gure 6

Instruction manual

Insert an iPad

To prevent scratching, you should handle the iPad with care when you insert it into the

tablet holder.

Note: Make sure that all of the necessary cables are plugged into the iPad before you

insert it into the SECTBLTPOS.

1. Thread the iPad cables through the hole in the bottom of the rear plate (3).

2. Place the iPad in the rear plate so that it’s sitting on the two 25x100x15 mm foam

pads (7) (gure 8).

gure 8

iPad

3. Place the front plate (2) over the iPad (gure 9).

gure 9

4. To lock the front and rear plates together, press the button in the middle of the lock

on the side of the plate (gure 10).

gure 10

Instruction manual

Attach the iPad enclosure to a wall

1. Line up the holes on the mounting bracket with the four holes on the back of the

rear plate (3).

2. Use the four M4x8 mm hex screws (8) and the 2.5 mm Allen key (9) to attach the

mounting bracket to the rear plate.

3. Make three holes in the wall in the location where you want to attach the

SECTBLTPOS.

Tip! To make sure that the holes are in the right location and are spaced correctly,

hold the mounting bracket up to the wall and use a pencil to trace the holes in the

mounting bracket onto the wall.

4. Line up the holes in the bottom of the mounting bracket with the holes in the wall.

5. Insert the three 5x20 mm self-tapping screws (12) through the three 15.4x5.0x2.0t

at washers (13), the holes in the bottom of the mounting bracket, and into the

holes in the wall (gure 11).

6. Tighten as necessary.

gure 11

12 13
