StarTech.com STARVIEW SV231DDUSB Bedienungsanleitung

Manual Revision: 04/25/2014

For the most up-to-date information, please visit: www.startech.com

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

SV231DDUSB

SV431DDUSB

2 or 4 Port DVI VGA Dual Monitor USB

KVM Switch w/ Audio & USB 2.0 Hub

*SV431DDUSB Shown

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction............................................................................................1

Packaging Contents ................................................................................................................................. 1

System Requirements.............................................................................................................................. 1

Installation ..............................................................................................3

Hardware Installation .............................................................................................................................. 3

Driver Installation...................................................................................................................................... 3

Operation ................................................................................................4

Hotkey Reference Chart ........................................................................5

Specications..........................................................................................7

Technical Support ..................................................................................8

Warranty Information............................................................................8

Instruction Manual

Introduction

The StarTech.com SV231DDUSB 2-port Dual Monitor KVM Switch (DVI+VGA) oers

a complete dual display multimedia switching solution, allowing users to control 2

computers using a single USB mouse and keyboard peripheral set.

With support for high-resolution video interfaces, the versatile dual monitor KVM

switch provides 1 VGA (analog) and 1 DVI-I port per computer connection, as well as

audio switching capability between connected computers.

Delivering the capability you need for virtually any application, the dual monitor

KVM switch features an integrated 2-port USB hub that allows connected USB 2.0

peripherals to be shared between connected computers, eliminating the need to

purchase duplicate peripherals.

Suitable for any workspace, the dual monitor KVM switch features a compact, desktop

KVM design and features a rugged metal chassis that helps ensure durability.

NOTE: While both DVI-I (analog mode) and DVI-D (digital only) are supported by the

KVM, both source PCs must output the same signal type for proper switching. It is

recommended wherever possible to use DVI-D cables across all PC to KVM and KVM

to Console connections. If necessary, please contact our technical support team for

assistance identifying your source.

The 2-port DVI+VGA dual monitor KVM switch is backed by a StarTech.com 2-year

warranty and free lifetime technical support.

Packaging Contents

• 1x 2 Port DVI/VGA KVM Switch

• 1x Power Adapter

• 1x Instruction Manual

System Requirements

• Standard 104-key wired USB keyboard

• Standard 3-button wired USB mouse

• DVI enabled display device (i.e. monitor, HDTV, etc.) with appropriate DVI cable

• DVI male/ male cable for each computer

• VGA enabled display device (i.e. monitor, HDTV, etc.) with appropriate VGA cable

• DVI male/ male cable for each computer

• USB/DVI/VGA enabled computer system(s) with available USB/DVI/VGA ports

Instruction Manual

SV431DDUSB Front

SV431DDUSB Back

Port Selection

Button

Computer

Selection

LED

USB Hub

Selection

LED

Console

DVI Port

Console

VGA Port Computer

Connectors

Console USB

Keyboard/

Mouse ports

Console

Speaker/MIC

ports

USB Hub

ports

Power

*SV431DDUSB Shown

Instruction Manual

Installation

Hardware Installation

NOTE: Prior to the installation, please power o all devices that will be connected to

this system.

1. Place the KVM switch in close proximity to the keyboard, mouse, and monitor(s) you

wish to use as the console controls.

2. Connect the USB keyboard, mouse, speakers and microphone (if applicable) to the

KVM switch.

3. Connect the DVI monitor into the Console’s DVI connector.

4. Connect the VGA monitor into the Console’s VGA connector.

OPTIONAL: Connect any other USB peripheral you wish to share between the

connected computers/devices to the extra USB Hub port on the Console side.

5. Use male-to-male video cables to connect the DVI and VGA connectors on the

computer’s video card, to the DVI and VGA ports for one of the KVM’s PC ports (i.e. PC1).

NOTE: Do not mix dierent types of DVI cables (DVI-I, DVI-D) on the same KVM switch.

6. Use a USB type A-B Cable to connect the KVM’s USB port (type B, square connector)

for the PC port used in the previous step, and the USB port on the computer (type A,

at connector). If using audio, connect 3.5mm mini-jack cables from the PC port to

the sound card.

NOTE: DVI + USB + Audio KVM combo cables are also available which can be used

in place of separate individual cables (e.g. StarTech.com ID: DVI4N1USB6).

7. Repeat the previous two steps for each PC port on the KVM switch, or each

computer you wish to use on the KVM switch.

8. Connect the external power adapter from a wall outlet to the power connector on

the rear panel of the KVM switch.

9. Power up the rst computer/device and wait for it to fully boot and test keyboard/

mouse functionality.

Driver Installation

No driver installation is required for the KVM switch, as the keyboard/mouse use USB

drivers that are already installed on any operating system that fully supports USB.

Instruction Manual

Operation

Port Selection Buttons

The Front Panel buttons allow direct control over KVM switch operation and channel

switching. Simply press the PC button for PC port switching. If binding is enabled

between PC / USB hub port control / Audio and Mic switching, they will be jointly

selected at the same time). If you wish to enable the binding of PC / Hub Port control /

Audio and Mic switching, see “Hotkeys” section.

Port Selection LEDs

The green ‘PC’ LED indicates the currently selected computer that has keyboard and

mouse, audio and video access. The red‘HUB’ LED indicates the currently selected

computer that has access to the USB hub ports.

Hotkey Control

A Hotkey command is a short keyboard sequence for selecting a computer, activating

computer scan, etc. A hotkey sequence starts with two left <ScrLk> (Scroll Lock)

keystrokes (successively within 2 seconds) followed by one or two more keystrokes.

A built-in tone generator creates a high-pitch beep for correct hotkey command;

otherwise, errors and bad key sequences will not be forwarded to the currently

selected computer.

The two proceeding keystrokes can be changed if desired. Press <ScrLk> + <ScrLk> +

<H>, which will be followed by two beeps indicating readiness for selection of a new

preceding sequence, or press and hold down the last front-panel button (Button 2 on

SV231DDUSB, Button 4 on SV431DDUSB) until you hear two beeps, then release the

button.

Select and press the key you would like to use as your preceding sequence (Scroll Lock,

Caps Lock, ESC, F12 or Num Lock) and you’ll hear a beep for conrmation. The new

preceding sequence can now be used to execute hotkey commands.

Instruction Manual

Hotkey Reference Chart

Command Hotkey Sequence Description

Select Active

Computer

(<x> = Port Number: 1, 2,

etc.)

Selects which port has

access to the keyboard/

mouse/monitor.

Select Audio/Mic

output

(<Fy> = Function key:

F5=Port 1, F6=Port 2, etc.)

Selects which port’s

speaker and microphone

output is active at the

console.

Bind computer and

Audio/ Mic control

(default)

When either the “select

active computer” or

“select audio/mic output”

commands are executed,

both functions are

Unbind computer

and Audio/Mic

output control

Computer control and

Audio/Mic output control

can be assigned to dierent

ports at the same time.

Select next/previous

port

or< >

Selects the next (up arrow

key) or previous (down

arrow key) numbered port

for control.

Select previous port <ScrLk> + <ScrLk> +

Selects the most recent

previously active port

Beep sound on/o <ScrLk>+<ScrLk>+<B> Enables/disables audible

responses from the KVM.

Dene new hotkey

sequence

(<y>= Scroll Lock, Caps Lock,

ESC, F12 or Num Lock)

Change the standard

<ScrLk> hotkey to a new

value (see “Hotkey Control”

for more info).

Instruction Manual

Auto-scan <ScrLk>+<ScrLk>+<S>

Automatically cycle

through active ports in

sequence every 10 seconds.

Auto-scan with

programmable

delay

(<z>= 0~9: where 1=10sec,

2=20sec…9=90sec,

0=100sec)

Auto-scan with a custom

set delay time.

Stop Auto-scan Press any key on keyboard Terminate Auto-scan

activity.

Instruction Manual

Specications

SV231DDUSB SV431DDUSB

Number of Ports 2 4

Console Connectors

1 x 29-pin DVI-I female

1 x DE-15 VGA female

4 x USB type A female

2 x 3.5mm Audio Mini-Jack female

Computer Connectors

(per port)

1 x 29-pin DVI-I female

2 x DE-15 VGA female

1 x USB type B female

2 x 3.5mm Audio Mini-Jack female

LEDs 2 x Computer Control

2 x USB Hub Selection

4 x Computer Control

4 x USB Hub Selection

Switching Modes Keyboard Hotkeys, Front Panel Push Buttons

Maximum Video

Resolution

VGA: 2048x1536

DVI: 1920x1200

DDC Support Yes

Audio Support Yes (speaker/MIC)

On Screen Display No

Cascadable No

Power Adapter 9V DC, 1700mA, center positive

Enclosure Material Metal

Dimension 163.0mm x 100.0mm x

66.0mm

253.0mm x 100.0mm x

66.0mm

Weight 730g 1100g

Andere Handbücher für STARVIEW SV231DDUSB

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere StarTech.com Schalten Handbücher

StarTech.com

StarTech.com SV231HDMIUA Bedienungsanleitung

StarTech.com

StarTech.com SV211USB Bedienungsanleitung

StarTech.com

StarTech.com SV221HUC4K Bedienungsanleitung

StarTech.com

StarTech.com ST4200MINI Bedienungsanleitung

StarTech.com

StarTech.com ST124WGB Bedienungsanleitung

StarTech.com

StarTech.com ICUSB2322X Bedienungsanleitung

StarTech.com

StarTech.com SV231DVGAU2A Bedienungsanleitung

StarTech.com

StarTech.com ST4300PBU3 Bedienungsanleitung

StarTech.com

StarTech.com SV431USBAEGB Bedienungsanleitung

StarTech.com

StarTech.com ST7300U3M Bedienungsanleitung

StarTech.com

StarTech.com STARVIEW SV431DVIUAHR Bedienungsanleitung

StarTech.com

StarTech.com C2-D46-UAC-CBL-KVM Bedienungsanleitung

StarTech.com

StarTech.com SV211DPUA4K Bedienungsanleitung

StarTech.com

StarTech.com SV431DVIUA Bedienungsanleitung

StarTech.com

StarTech.com 8STIES51000POE Bedienungsanleitung

StarTech.com

StarTech.com SV431HDU3A2 Bedienungsanleitung

StarTech.com

StarTech.com SV211 Bedienungsanleitung

StarTech.com

StarTech.com HB30A3A1CST Bedienungsanleitung

StarTech.com

StarTech.com 8ST35BAYUSB3S4 Bedienungsanleitung

StarTech.com

StarTech.com SV231DPU Bedienungsanleitung

StarTech.com

StarTech.com CPNT410IR Bedienungsanleitung

StarTech.com

StarTech.com HB30C4AIB Bedienungsanleitung

StarTech.com

StarTech.com SV431DDVDUA Bedienungsanleitung

StarTech.com

StarTech.com SV231USBA Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
