StarTech.com SV221NANOU Bedienungsanleitung

USB KVM Switch

2-Port Nano USB VGA Cable

KVM Switch - USB Powered

SV221NANOU

Instruction Manual

Manual Revision:10/18/2010

For the most up-to-date information, please visit www.startech.com

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and

Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes

only and do not represent an endorsement of a product or service by StarTech.

com, or an endorsement of the product(s) to which this manual applies by the

third-party company in question. Regardless of any direct acknowledgement

elsewhere in the body of this document, StarTech.com hereby acknowledges that

all trademarks, registered trademarks, service marks, and other protected names

and/or symbols contained in this manual and related documents are the property

of their respective holders.

Table of Contents

Introduction.............................................................. 1

Packaging Contents............................................................. 1

System Requirements ......................................................... 1

Installation................................................................ 2

Hardware Installation........................................................... 3

Driver Installation................................................................. 3

How to Use ............................................................... 3

Hotkey Switching ................................................................. 3

Push Button Switching......................................................... 3

Speciﬁcations........................................................... 4

Technical Support.................................................... 5

Warranty Information............................................... 5

Introduction

The SV221NANOU 2-Port Nano USB VGA Cable KVM Switch lets you

control two systems using a single USB keyboard, USB mouse and VGA

monitor. A space-saving design helps to organize your desk without

sacriﬁcing control and convenience.

Featuring a push-button remote control on a 1.5 meter (5 ft.) cable that can

be placed in an easily accessible location on your desk as well as keyboard

hotkeys for switching between Windows®systems, this KVM makes it easy

to manage both of your connected computers. The KVM switch draws

power from the USB connected systems, doing away with the need for a

bulky external power adapter.

Offering support for extremely high resolutions of up to 2048x1536, this

KVM has the capability of driving large VGA displays with crystal clarity.

The SV221NANOU is perfect for streamlining the clutter on your desk and

maximizing productivity by allowing you to switch back and forth between

two computers quickly and easily.

Packaging Contents

• 1 x SV221NANOU KVM switch

• 1 x Instruction Manual

System Requirements

• VGA and USB enabled computer system

• VGA enabled display device (i.e. monitor, projector, HDTV, etc)

• A standard 104-key wired USB keyboard

• A standard 3-button wired USB mouse

Installation

Hardware Installation

1. Make sure that the two computers (PC1 and PC2) are located within

1.5m of each other. Both computers should be powered off.

2. Locate the end of the cable that has the female VGA connector and

the Remote Control. Connect the male VGA and USB connector to the

appropriate connectors on PC1.

3. Connect the male VGA and USB connector on the other end of the Nano

KVM to the appropriate connectors on PC2.

4. At the end with the female VGA connector, connect the VGA display

device (i.e. monitor, projector, etc) using a standard male/male DE-15

VGA cable.

5. At the other end of the KVM cable are two female USB connectors. Plug

the USB keyboard and mouse into these connectors.

6. Power on PC1 and conﬁrm proper operation of the display and

keyboard/mouse.

7. Press the button on the Remote Control to switch to port 2 and power on

PC2. Conﬁrm proper operation of the display and keyboard/mouse.

Driver Installation

No drivers are required to be installed for the KVM switch to function.

How to Use

Hotkey Switching

Press the <Scroll Lock> key on the keyboard twice in quick succession

to switch between ports. This feature only works from computers running

Windows.

Push Button Switching

Push the button on the Remote Control to immediately switch between

ports on the KVM.

Specications

Number of Ports 2

Computer Connectors

(per port)

1 x DE-15 VGA male

1 x USB type A male

Console Connectors 1 x DE-15 VGA female

2 x USB type A female

LEDs 1 x Power

Maximum Video Resolution 2048 x 1536

DDC Support DDC, DDC2, DDC2B

Switching Methods Push Button, Hotkeys*

Power Adapter None (USB powered)

Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)

Storage Temperature -10°C ~ 80°C (14°F ~ 176°F)

Humidity 0% ~ 90% RH

Integrated Cable Length KVM Cable: 1.5m

Remote Control cable: 1.5m

Dimensions 33.0mm x 59.0mm x 12.0mm

Weight 210g

*hotkeys only supported under Microsoft®Windows®operating systems

Technical Support

StarTech.com’s lifetime technical support is an integral part of our

commitment to provide industry-leading solutions. If you ever need

help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and

downloads.

Warranty Information

This product is backed by a one year warranty.

In addition, StarTech.com warrants its products against defects in

materials and workmanship for the periods noted, following the initial

date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion.

The warranty covers parts and labor costs only. StarTech.com does

not warrant its products from defects or damages arising from misuse,

abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.

com USA LLP (or their ofﬁcers, directors, employees or agents) for

any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of proﬁts, loss of business, or any

pecuniary loss, arising out of or related to the use of the product exceed

the actual price paid for the product. Some states do not allow the

exclusion or limitation of incidental or consequential damages. If such

laws apply, the limitations or exclusions contained in this statement

may not apply to you.

StarTech.com has been making “hard-to-ﬁnd easy” since 1985,

providing high quality solutions to a diverse IT and A/V customer

base that spans many channels, including government,

education and industrial facilities to name just a few. We offer

an unmatched selection of computer parts, cables, A/V products,

KVM and Server Management solutions, serving a worldwide

market through our locations in the United States, Canada, the

United Kingdom and Taiwan.

Visit www.startech.com today for complete information about

all our products and to access exclusive interactive tools such as

the Cable Finder, Parts Finder and the KVM Reference Guide.
