DVI VGA USB KVM Switch

2/4-Port DVI and VGA, USB

KVM Switch with Audio and

USB 2.0 Hub

SV231DDVDUA

SV431DDVDUA

Instruction Manual

Manual Revision:10/05/2010

For the most up-to-date information, please visit www.startech.com

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only

and do not represent an endorsement of a product or service by StarTech.com, or an

endorsement of the product(s) to which this manual applies by the third-party company

in question. Regardless of any direct acknowledgement elsewhere in the body of

this document, StarTech.com hereby acknowledges that all trademarks, registered

trademarks, service marks, and other protected names and/or symbols contained in this

manual and related documents are the property of their respective holders.

Table of Contents

Introduction..................................................................... 1

Packaging Contents.....................................................................1

System Requirements .................................................................1

Installation....................................................................... 1

Hardware Installation...................................................................2

Driver Installation.........................................................................4

Operation......................................................................... 4

Front Panel ..................................................................................4

Rear Panel (SV431DDVDUA only) ..............................................5

HotKey Control ............................................................................6

Alternative Hotkey Commands ....................................................9

Change Leading Hotkey ..............................................................10

Speciﬁcations.................................................................. 11

Technical Support........................................................... 12

Warranty Information ...................................................... 12

Introduction

Packaging Contents

• 1 x SV231DDVDUA or SV431DDVDUA KVM switch

• 1 x Power Adapter

• 1 x Instruction Manual

System Requirements

• DVI and VGA enabled computer system/video card

• USB enabled computer system

• DVI or VGA enabled display devices (e.g. monitor, projector, TV, etc.)

• A standard 104-key wired USB keyboard

• A standard 3-button wired USB mouse

Installation

NOTE: Prior to the installation, please power off all devices that will be

connected to this system.

Ensure that all devices you will connect are properly grounded.

Place cables away from ﬂuorescent lights, air conditioners, and

machines that are likely to generate electrical noise.

If you experience any problems using a USB KVM switch, the

following BIOS setup changes may be necessary for PC users and not

necessary for Mac users:

• Set HALT ON ERROR to ALL BUT KEYBOARD.

• In PNP AND PCI SETUP, set PNP OS INSTALLED to YES and set

USB IRQ to ENABLED.

Different systems may use different naming, so contact your system

manufacturer for further assistance with these settings.

Hardware Installation

Front View (SV431DDVDUA shown)

Rear View (SV431DDVDUA shown)

* installation pictures are representation only

1. Plug 1 or 2 monitor(s) into the Console side DVI and/or VGA

connectors; plug a USB keyboard and a USB mouse into the

dedicated USB keyboard and mouse ports on the KVM switch.

2. Use a male-to-male DVI and/or VGA video cable to connect the DVI/

VGA connector(s) on the computer’s video card, to one of the KVM’s

PC ports (ie. PC1). A dedicated video, USB and audio 4-in-1 KVM

cable can be used (ie. StarTech.com ID: USBDVI4N1A6 (DVI) or

USBVGA4N1A6 (VGA)).

3. Use a USB type A-B Cable to connect the KVM’s USB port (type B,

square connector) for the PC port used in Step 2, and the USB port

on the computer (type A, ﬂat connector).

4. Repeat for Steps 2 and 3 for each PC port on the KVM switch, or

each computer you wish to use on the KVM.

5. OPTIONAL: Connect any other USB peripherals you wish to share

between the connected computers/devices to the extra USB Hub

ports on the Console side.

6. Connect the external power adapter from a wall outlet to the power

connector on the rear panel of the KVM switch. The Power LED

should light up solid and/or the LED for the selected PC port.

7. Power up the ﬁrst computer/device and wait for it to fully boot and

test keyboard/mouse functionality.

8. Once operation has been successfully conﬁrmed, switch to the next

port and power up that computer/device and conﬁrm.

Driver Installation

No driver installation is required for the KVM switch, as the keyboard

and mouse uses native USB keyboard/mouse drivers that are already

installed on all operating systems that fully support USB.

Operation

Front Panel

Port Selection/Link LED

The LED turns green when the connected computer is powered-on.

The corresponding LED will also illuminate red when that PC port is

currently selected.

Port Selection Button

2-Port: Pressing the front panel “Select” button toggles between the PC

ports on the KVM switch.

4-Port: Each push button on the front panel corresponds with a PC

port. Pressing the button will immediately select that port.

Auto Scan

The KVM automatically scans through the powered-on computers in

sequence on a ﬁxed time interval (see Scan Time below).

To activate Auto Scan, press down front panel push buttons “3” and “4”

simultaneously. The port LED ﬂashes during Auto Scan. Auto Scan is

effective for powered-on computers only. To exit the Auto Scan mode,

just tap any one of the push buttons. (SV431DDVDUA only)

NOTE: When Auto Scan detects any keyboard activity, it suspends the

scanning until the activity stops; it then resumes with the next computer

in sequence. The length of the Auto Scan interval (Scan Rate) is

adjustable, see below.

Scan Time

Four options are available for users to set the Scan Time duration,

which includes 3, 8, 15 and 30 seconds.

To change the Scan Time interval, press both front panel buttons “1”

and “2” simultaneously. The unit beeps 1, 2, 3 or 4 times for Scan Time

of 3, 8, 15 or 30 seconds respectively. (SV431DDVDUA only)

NOTE: Scan Time is automatically set to the default of 3 seconds when

the units loses power.

Rear Panel (SV431DDVDUA only)

To adjust the video signal strength/equalization settings for the length

or quality of DVI cable being used, the “FUNC” button combined with

the front panel push buttons can be used.

1. Press “FUNC” button three times, and the LED for “POWER” will

start to ﬂash once per second.

2. Press front panel push button “1” one or two times to adjust the

signal equalization with one beep (normal) or two beeps (enhance)

respectively.

Press front panel push button “3” one or two times to adjust the

video signal output current with one beep (normal) or two beeps

(enhance) respectively.

Press front panel push button “4” one, two, three, or four times to

adjust the output emphasis with one beep (no pre-emphasis), two

beeps (low pre-emphasis), three beeps (medium pre-emphasis), or

four beeps (high pre-emphasis).

3. Once the settings have been adjusted, press the “FUNC” button one

time to exit this mode.

HotKey Control

A Hotkey command is a short keyboard sequence for selecting a

computer, activating computer scan, etc. A hotkey sequence starts

with two left <CTRL> keystrokes (successively within 0.2 seconds)

followed by one or two more keystrokes. A high-pitch beep will be

generated for each correct hotkey command; otherwise, one low-pitch

beep is generated for errors and the bad key sequence will not be

forwarded to the selected computer.

NOTE: Press and hold Left <SHIFT> and press <NumLock> twice,

then release <SHIFT> followed by pressing left <CTRL> once, which

will enable / disable the hotkey feature.

To select a computer:

Left <CTRL> + Left <CTRL> + <1>

(Example: Selects the computer at port 1.)

Left <CTRL> + Left <CTRL> + <2>

(Example: Selects the computer at port 2.)

NOTE: Do not use the keypad on the right-side of the keyboard.

Auto Scan

The KVM automatically scans through the powered-on computers in

sequence on a ﬁxed time interval (see Scan Time below).

To start Auto Scan:

Left <CTRL> + Left <CTRL> + <F1>

To abort the Auto Scan mode, press the left <CTRL> key twice.

NOTE: When Auto Scan detects any keyboard activity, it suspends the

scanning until the activity stops; it then resumes with the next computer

in sequence. The length of the Auto Scan interval (Scan Rate) is

adjustable, see below.

Manual Scan allows users to manually switch back and forth between

powered-on computers.

Left <CTRL> + Left <CTRL> + <F2>

To select the previous or the next computer, press <UP> or <DOWN>

arrow keys. To abort the Manual Scan, press any other key.

Scan Time

Four options are available for users to set the Scan Time duration, it

Includes 3, 8, 15 and 30 seconds.

Note: Scan Time is set to 3 seconds by default.

To adjust Scan Rate, set the scan time of duration before switching to

the next computer:

Left <CTRL> + Left <CTRL> + <F3>

The KVM Switch generates 1 to 4 beeps indicating a scan time

duration for 3, 8, 15 or 30 seconds respectively.

Andere Handbücher für SV231DDVDUA

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere StarTech.com Schalten Handbücher

StarTech.com

StarTech.com ST121HDBTSC Bedienungsanleitung

StarTech.com

StarTech.com VS420RDVIA Bedienungsanleitung

StarTech.com

StarTech.com HB30C1A1CPD Bedienungsanleitung

StarTech.com

StarTech.com 8STIES51000POE Bedienungsanleitung

StarTech.com

StarTech.com SV231DPUCA Bedienungsanleitung

StarTech.com

StarTech.com HB30A3A1CST Bedienungsanleitung

StarTech.com

StarTech.com 4PORT-8K-HDMI-SWITCH Bedienungsanleitung

StarTech.com

StarTech.com SV231DVIUA Bedienungsanleitung

StarTech.com

StarTech.com ST3300U3S Montageanleitung

StarTech.com

StarTech.com STARVIEW SV831SUN Bedienungsanleitung

StarTech.com

StarTech.com 8STICUSB23216FD Bedienungsanleitung

StarTech.com

StarTech.com DS16105 Systemhandbuch

StarTech.com

StarTech.com MSTDP123HD Bedienungsanleitung

StarTech.com

StarTech.com 8STIES81GPOEW Bedienungsanleitung

StarTech.com

StarTech.com ICUSB2324I Bedienungsanleitung

StarTech.com

StarTech.com MSTDP124DP Bedienungsanleitung

StarTech.com

StarTech.com ST4300PBU3 Bedienungsanleitung

StarTech.com

StarTech.com IESC1G50UP Bedienungsanleitung

StarTech.com

StarTech.com SV231UADVI Bedienungsanleitung

StarTech.com

StarTech.com ST7CU35122 Bedienungsanleitung

StarTech.com

StarTech.com SV431DPUA Bedienungsanleitung

StarTech.com

StarTech.com ST4205READ Bedienungsanleitung

StarTech.com

StarTech.com STARVIEW SV431DVIUAHR Bedienungsanleitung

StarTech.com

StarTech.com DisplayPort MSTDP124DP Bedienungsanleitung

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
