StarTech.com VS721MULTI Bedienungsanleitung

Manual Revision: 11/05/2018

User Manual

For the latest information and specications visit

www.startech.com/VS721MULTI

Multiple Video Input with Audio to HDMI®

Switcher

Actual product may vary from photos

SKU#: VS721MULTI

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.

CAN ICES-3 (B)/NMB-3(B)

For the State of California

WARNING: Cancer and Reproductive Harm

www.P65Warnings.ca.gov

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Product installation and/or mounting should be completed by a certied

professional as per the local safety and building code guidelines.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• L’installation et/ou le montage du produit doit être réalisé par un

professionnel certié et dans le respect des normes locales et du code de

construction local.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• 製品の設置やマウントは、使用地域の安全ガイドラインおよび建築基準に

従い、有資格の専門業者が行うようにしてください。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• L’installazione e/o il montaggio dei prodotti devono essere eseguiti da un

tecnico professionale certicato che conosca le linee guida locali sulle norme

edilizie e sulla sicurezza.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Installation och/eller montering får endast göras av behöriga yrkespersoner

och enligt gällande lokala förordningar för säkerhet och byggnormer.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

Warning Statements

• Make sure to assemble this product according to the instructions. Failure to

do so might result in personal injury or property damage.

• Never use this product if parts are missing or damaged.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................3

Warning Statements ..............................................................................4

Product Diagram (VS721MULTI) ..........................................................6

Product Information ..............................................................................7

Packaging Contents ................................................................................................................................. 7

System Requirements.............................................................................................................................. 7

Hardware Installation............................................................................8

Hardware Operation..............................................................................8

Specications..........................................................................................11

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram (VS721MULTI)

Port LEDs

(6)

IR Receiver Input Selection

Buttons (6)

Power

Supply

RS232

Port

HDMI

Ports

(3)

HDMI

Output

Port

VGA

Port

Component

Ports

Composite

Port

S Video

Port

Audio

Input

Ports

(7)

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Information

Packaging Contents

• Multiple Format to HDMI® Audio Video Switch x 1

• IR Remote Control x 1

• Mounting Kit x 1

• RS232 Serial Cable - 6 ft x 1

• RS-232 Control Software CD x 1

• Universal Power Adapter (NA/UK/EU) x 1

• User Manual x 1

System Requirements

For the latest requirements, please visit www.startech.com/

VS721MULTI.

• Video source devices (i.e. computer, Blu-ray Player)

• HDMI® enabled display device (i.e. television, projector)

• Desired Audio Video Input Cables

• HDMI® x 3

• VGA x 1,

• Component YPbPr x 1

• Composite CVBS x 1

• S-Video x 1

• 3.5MM Audio VGA x 1

• RCA Audio x 3

• HDMI® Output Cable

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Hardware Installation

1. Connect the Desired Audio Video Input Cables (sold

separately) from each video source device (i.e. computer,

Blu-ray Player) to the Video Input Ports (3 x HDMI®, 1 x VGA,

1x Component YPbPr, 1 x Composite CVBS, 1 x S-Video) on

the Switcher.

2. Connect an HDMI® cable (sold separately) from the HDMI®

enabled display device (i.e. television, projector) to the

HDMI® Output Port on the Switcher.

3. Turn on the display device, followed by the video source

devices.

4. (Optional) For RS232 Remote Serial control, connect the

included RS232 Serial Cable from a computer to the RS232

Serial port on the Switcher.

Hardware Operation

1. Manual Port Selection

• Press the Input Selection Button that corresponds with the

video source device you would like displayed.

• The selected Active Port LED Indicator will light, and the

desired video source device will be displayed on the

HDMI® enabled display device.

2. Remote Control Port Selection

• Press the desired 1 - 7 key on the remote control that

corresponds with the number above the Active Port LED

Indicator.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

• The selected Active Port LED Indicator will light, and the

desired video source device will be displayed on the

HDMI® enabled display device.

• Use the button to power on/o the VS721MULTI.

Note: The arrow buttons on the remote can also be used to

switch the Active Port LED Indicator to the adjacent left or

right video source device.

3. Remote Serial Control Using The Matrix Application Software

Note: Ensure Step 4. of Hardware Installation has been

completed.

• Download the latest software from the StarTech.com

website (recommended), or insert the included Software

CD into your CD-ROM drive.

• Launch AV Matrix(.msi). This le will be located in the root

directory on the downloaded folder, or the Software CD.

• The Matrix Application software will quickly install. Upon

completion Click to open the software.

• Click the “options” button and congure the

communication protocol to the following specications:

Baud rate 9600bps, no odd or even calibration bit address,

8bit transmission address, 1bit stop address, PC Port 001.

Note: The COM port on your computer will require the same

conguration. Consult your computer user documentation

for further details.
