www.star-way.com User Manual
LASERTECH 5000 3
Projector Introduction
The LASERTECH 5000 is designed convenient for customers with control system
in one housing and lasers in another, different output laser housing changeable to
meet unique requirement. It is the combo to be able to play animation, DG effect,
beam effect and at same time boasts linear adjustable DPSS lasers, easier to
operate Pangolin build in control system, Cyperlite control software, high speed
USB connector, ILDA DB 25, larger memory. All of the above features are enough
to guarantee you pleasure laser show feast.
◆ Mode：DMX mode、Projector is capable to be controlled by computerized
soft through USB and by ILDA signal.
◆ DMX Channel：4、8、12、24 Channels selectable
◆ Show：More than 400 show (editable)
◆ Laser：R > 1600mw 635nm 、G > 2500mw 532nm、B > 1000mw 473nm
◆ Scan System：ILDA24K
◆ Control System：Pangolin built in system
◆ Beam Effect: 6 Beam Turret Positions, 10 Total Targeting Beams, 20
Position Rotating/ Selectable DG, Dual counter Rotating DG effect,
180°Static Linear DG Effect, 180*180 Static Grid DG effect
◆ Memory：128MB
◆ Input Voltage：AC 110V~240V 60/50Hz
◆ Power：240W
◆ Dimension：1393×426×(365~395)mm
◆ Weight：***Kg
