Stealth Glite PRO Bedienungsanleitung

www.stealthtronic.com | [email protected] user manual

Glite PRO

1. Insert the Nano-SIMcard and wait for about 10 seconds for the device to bootup

2. Call the unit, and the unit will pick up the call

3. Wait for unit to send replies, sometimes it can take a short amount of time.

4. Close the unit with screwdriver, gently tighten

Activation of VOX

detection SNDSENS 0 -OFF

1-100 – The lowest sensitivity

The number reﬂects the “dB” in the surrounding,

so if you will set it to 30 you will need noise of 30

dB to activate it. Recommend it for activation by

voice is 30-50db

Movement detection MOVESENS

0 -OFF

1 - MOST SENSITIVE

100 - the lowest sensitivity

The number reﬂects a vibration in a sensor that

needs happen, before the unit is activated.

Factory settings RESET Factory settings = SLP0, SLPINT15, PWRINT2,

LEDMSK15, MOVESENS0, SNDSENS0

Status of device STATUS Returns the status of the device, including a

battery

Password settings PASSWORD

0 – Turn off

001 - 999 – set number

possibility

If you decide to activate password you will have to

use it for further communication with the device.

For example, if you set PASSWORD777 and you

will want to change the sensitivity you will need

to do so like this 777SNDSENS50

Turn off LED diodes LEDMSK 0 – OFF

15- ON

You will turn off the led diodes by sending to the

device LEDMSK0

Voice during phone

call (Gain)

Simply, for increasing the signal from the micro-

phone, you use following commands, pressing on

the keypad: #01, #02, to #09 … wait in between the

pressing of DTMF tone.

Commands: - variable

Start up

Glite Vario PRO Glite 20 PRO

www.stealthtronic.com | [email protected] user manual

SMS Format:

Parameters:

FREQUENCY BANDS

850/ 900/ 1800/ 1900MHz

GPRS Multi-slot Class: Class 12

GPRS Mobile Station: Class B

Temperature Range: -40°C ~ +85°C

Dimensions: 70 mm x 45 mm x 15 mm - Glite Vario Pro 2.0

75 mm x 77 mm x 15 mm Glite 20 Pro 2.0

Weight Approx. 1.3g

GSM 07.07, 07.05 and other Enhanced AT

STATUS:

FW:1.3,BAT:60%,SLP0,SLPINT15,PWRINT2,SNDSENS0,MOVESENS30

FW:1.3 - Firmware

BAT60% - Battery 60%

SLP0 - Sleep mode off

SLPINT - Sleep interval 15min

PWRINT - Power interval 2 min

SNDSEND0 - VOX detection off

MOVESENS30 - A movement detection at 30

Status example for FW1.3

Glite PRO

Diodes explanation:

LED1 Internal testing, can be turned off by (LED0,LED1)

LED2 Blinking when processing a command that was sent to

the device.

LED3 GSM NET light : No light: the module is asleep, turned off

or does not have battery.

4ms ON/800ms OFF: The module is not synchronized with network.

Problem with SIMCard or reception

64ms ON/2000ms ON: The module is synchronized with network

LED4 Only active when detection of movement, sound is

activated.

LEDMSK0 will turn off all diodes, they are advised to be turned off.

Glite 20 Pro has to be turned ON for charging. Since the position of the switch

does not directly tell you, if the device is on, you will have to ﬁnd out via SMS if the

battery its at 100%. Simply plug in the device and wait for it to start signaling with

diodes to turn on ﬂashing.

Charging:

www.stealthtronic.com | [email protected] user manual

Glite PRO

Sleep function (it will temporarily disable the

module GSM) It has 2 parameters which must

be set, SLPINT and PWRINT sets time for

connecting back to GSM network.

SLP0 – OFF

1 – ON

This function will turn on SLEEP mode and prolong the battery life of

the module. It will wake up for a speciﬁed time set by SLPINT0-360

minutes, in case there is SNDSENS or MOVESENS the module call

speciﬁed number even when ASLEEP. The amount for which ONLINE

ON GSM is set by PWRINT in minutes.

Setting interval for being asleep. You will not be

able to reach the unit or send commands to it. SLPINT1-360 minutes

When the unit is asleep, it will not be able to wake itself up even by

calling on it. It will only be awake if there is noise or movement and the

parameters are set correctly. After the cycle of minutes the module will

connect to GSM for PWRTINT speciﬁed time

Awake interval for connecting back to GSM PWRINT 1-360 minutes Interval for which the unit will go online to GSM

GSM Sleep function:

Advanced commands:

Please be advised, those commands are only for experience users. By bad usage, you can turn off the GSM signal device and make it either only responsive

to NOISE(SNDSENS) or MOVEMENT(MOVESENS) or you can also shut the device completely off.

MODE SLP1 is used to save battery. We recommend using commands

MOVESENS, SNSDSENS,SLPINT and PWRINT before you activate SLP command.

NOTE:

These advanced functions are to be used for special occasions. For example, when sweeping of spaces would be scheduled, you can deactivate the

module and (SNDSENS + MOVESENS) so the module will be “oﬄine” therefore undetectable.

Another function would be to set a schedule for when you know there is noise which you don’t want to listen to and waste battery life. Let’s say a car
