Stewart Filmscreen B Bedienungsanleitung
TO THE INSTALLER: BE SURE TO LEAVE THIS MANUAL WITH THE OWNER.
MB/C-1101
Model B & Model C
Electriscreens
To the Owner
Installation Instructions
Operating the Screen
Maintenance
OWNER’S MANUAL
Printed in U.S.A.
©2001 Stewart Filmscreen Corporation.
Contents
To The Owner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Preparing The Installation . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Step 1. Hanging The Case . . . . . . . . . . . . . . . . . . . . . . . . . .5
Step 2. Electrical Hook-up . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Operating The Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Adjusting The Screen Extension . . . . . . . . . . . . . . . . . . . . . .9
Screen Care And Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . .11
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Model B & Model C Electriscreens: Owner’s Manual 1
Model B & Model C
Electriscreens
OWNER’S MANUAL
Congratulations on your purchase of the finest optical viewing screen
available anywhere in the world!
Please take a moment to review this manual, it will help ensure you many
years of trouble-free service from your new Stewart Filmscreen product.
About your Model B/Model C Series Electriscreen
Your Model B & Model C Electriscreens offer the most technologically
advanced roller screens in the world.
The maximum overall dimensions of the Model B screen image are 18’ high
by 26’6” wide.
The maximum overall dimensions of the Model C screen image are 25’ high
by 38’10” wide.
2Stewart Filmscreen Corporation
TOTHE OWNER
Preparation
Specifications regarding the individual screen dimensions, weight, mounting
type, and controls are provided by the factory when the unit is ordered.
Before beginning the installation:
KCheck the specifications for the type of mounting and switch
control to be used.
KEnsure that the mounting area and electrical connection are
prepared.
KCheck the size and weight of the screen to be installed so that
you can plan for the number of people required for the mounting
procedure. You need at least four people to mount the smaller
screens; more are needed for larger, heavier screens.
You will need:
KEnough ladders for the personnel supporting the screen during
the mounting process
KA level
KFasteners appropriate for the surface on which the screen is
being mounted (See instructions for the type of mount for
recommendations.)
K2 block and tackles or scissor lifts to raise the unit into place
KStandard screwdriver
K7/16” hex head screwdriver
Model B & Model C Electriscreens: Owner’s Manual 3
PREPARING THE INSTALLATION
KBefore proceeding with the installation of this screen,
take time to thoroughly read and understand these
installation and operation instructions.
KAll electrical wiring installations must conform to local
and national codes and should be performed by
qualified service personnel.
KThere are no user-serviceable parts contained within
the unit.
Caution
During installation, do not place the unit on an unstable
cart, stand, table, or ladder. The unit may fall, causing injury
to a child or adult and damage to the unit.
Unpacking
1. DO NOT remove the paper hanging from the trapdoor at this
time. You should remove it only after the unit is hung, all electrical
connections have been made, and the screen is in operation.
2. Remove the batten lock-down screws located on the back side of
the case.
4Stewart Filmscreen Corporation
Warning!
Failure to remove the batten lock-down screws can result in
permanent damage to the screen.
Factory Advisory
The factory advises against installing a concealed or
recessed electrical projection screen permanently. You
must be able to access and remove the unit should future
service be necessary.
Suggested solutions for removing the unit include:
KA removable ceiling cover plate under the mounting
location.
KAccess to the unit through an attic or overhead space.
Professional mounting techniques should be adhered to. Stewart
Filmscreen Corporation cannot be liable for substandard or faulty
installations.
Make sure that you mount the screen so that the electrical box is on the left
side (audience left).
Installing the unit
The Model B & Model C Electriscreens are ready to install into the ceiling or
soffit. A false ceiling is not intended to support the weight of a Model B &
Model C Electriscreens.
The screen can be bolted directly to the support structure or suspended. If
the unit is to be mounted to plaster, drywall, masonry, or other type of
surface, use an appropriate fastener. (These might include toggle or molly
bolts or similar fasteners.)
1. Install the unit onto the support structure making sure that the
bottom of the case is flush with the finished ceiling, if any.
2. Make sure the unit is level.
Model B & Model C Electriscreens: Owner’s Manual 5
STEP 1. HANGING THE CASE
Figure 1: Model B & Model C Electriscreens
Support Structure
Electrical
Connection
Housing
The motor requires standard 120V 60 Hz input (unless an alternate voltage
has been specified). All connections are made to the electrical box on the
side of the unit (audience left).
There are several kinds of switch controls available. Follow the installation
procedure for the type of switch control you will install.
General suggestions for wiring:
KSoldering is recommended.
KThe use of wire nuts is acceptable.
6Stewart Filmscreen Corporation
STEP 2. ELECTRICAL HOO -UP
Caution
Professional techniques need to be adhered to when
making any electrical connection. A qualified electrician
should perform these procedures.
Be sure to follow all standard safety procedures for
installing electrical devices.
Do not disassemble or alter the configuration of the motor
or the unit's electrical connections. This may cause injury to
you or damage to the product.
The electrical connection should be made only to the type
of power source indicated on the marking label.
Installing the low-voltage 3-button switch (standard)
The Stewart Filmscreen low-voltage control allows the use of low-voltage
wire to connect to the supplied 3-position 24V momentary wall switch.
Preparing the connection
Before making the electrical connections, you need:
KAn available 120V AC constant power source
KA 4-conductor switch hook-up cable (4-conductor bell wire or
category 5 cable is typically used for long runs)
Making the connection
Figure 2 illustrates the connections.
1. Remove the J-box covers, using a standard screwdriver.
2. Connect the 4-conductor cable to the connection harness coming
from the J-box used for switch input, via an electrical knockout.
3. Connect the hookup cable to the 3-button switch.
4. Connect the main 120V AC power source to the the J-box used
for the main AC power connection, via an electrical knockout.
5. Replace the covers on the J-boxes.
6. A parallel connection to an outboard audio-visual switching
network can be made at this time. (optional)
Figure 2: Low voltage 3-button switch wiring
3-button Momentary
Switch
Model B & Model C Electriscreens: Owner’s Manual 7
4 Conductor Hook-up Cable - 20ga Minimum
Category 5 recommended
(NOT Supplied)
J-box for
Switch Input Note: There are three
perforated electrical knockouts
on each J-box; any can be used
to make the connection.
J-box for
Power Input
COMMON-White
UP-Red
DOWN-Black
STOP-Yellow
NEUTRAL-White
GREEN-Ground
HOT-Black
Use the 3-button switch or outboard switching network to control the screen.
When you lower or retract the screen, it will stop at its preset limit. If an
obstacle (such as a person or furniture) gets in the path of the screen as it
is lowered, you should use the switch control to stop the screen's motion; it
will not automatically stop if it hits an obstacle.
In general, when the screen is not in use, you should store it in the fully
retracted position.
8Stewart Filmscreen Corporation
OPERATING THE SCREEN
Caution
Do not operate the motor when any of the following occurs:
KThe unit emits any smoke, heat, abnormal noise or
unusual odor.
KThe unit is damaged in some way, such as damage
from a water leak.
If any of these situations occur, call a qualified service
person.
First time operation
The first time you operate the screen, the protective paper
will fall out as the screen unrolls. Once the screen is fully
displayed, make sure that no packing paper remains on the
screen roll. The screen can be damaged if loose paper
remains.
