Sub-Zero UW-24 Bedienungsanleitung

WINE STORAGE

INSTALLATION GUIDE

SPECIFICATIONS, INSTALLATION, AND MORE

WINE STORAGE

Contents

3Wine Storage

4Model UW-24 | UW-24FS Site Preparation

6Model UW-24 | UW-24FS Installation

10 Model BW-30 Site Preparation

16 Model BW-30 Installation

Features and specications are subject to change at any

time without notice. Visit subzero.com/specs for the most

up-to-date information.

Important Note

To ensure this product is installed and operated as safely

and efciently as possible, take note of the following types

of highlighted information throughout this guide:

IMPORTANT NOTE highlights information that is especially

important.

CAUTION indicates a situation where minor injury or product

damage may occur if instructions are not followed.

WARNING states a hazard that may cause serious injury or

death if precautions are not followed.

IMPORTANT NOTE: Throughout this guide, dimensions in

parentheses are millimeters unless otherwise specied.

IMPORTANT NOTE: Save these instructions for the local

electrical inspector.

Sub-Zero Customer Care 800.222.7820

subzero.com

Product Information

Important product information, including the model and

serial number, are listed on the product rating plate. The

rating plate is located on the underside of the control panel,

on the left. Refer to the illustrations below.

If service is necessary, contact Sub-Zero Factory Certied

Service with the model and serial number. For the name

of the nearest Sub-Zero Factory Certied Service or for

questions regarding the installation, visit the contact

and support section of our website, subzero.com, or call

Sub-Zero Customer Care at 800-222-7820.

WINE STORAGE

Tools and Materials

•Screwdrivers—standard, Phillips, and Torx.

•Power drill.

•Drill bits (masonry bits required for concrete installation).

•Standard socket and wrench set.

•2' and 4' levels.

•Material to protect home, ooring, and cabinetry during

installation.

Model UW-24 and UW-24FS

Model BW-30

RATING PLATE

Sub-Zero Customer Care 800.222.7820

OPENING WIDTH

341/2"

(876)

OPENING

HEIGHT

TOP VIEW

SIDE

VIEW FRONT VIEW

NOTE:

31/2"(89) finished returns will be visible and should be finished to match cabinetry.

3/4"(19)

TYPICAL

FRAMED

CABINETRY

FILLER

31/2"(89)

FINISHED

RETURN

FRAMELESS

CABINETRY

3/4"(19)

TYPICAL

31/2"(89)

FINISHED

RETURN

24" (610)

OPENING

DEPTH

Opening Dimensions

MODEL UW-24

MODEL UW-24 | UW-24FS SITE PREPARATION

OPENING WIDTH W

UW-24 24" (610)

DUAL OPENING WIDTH W

Two 24" (610) Models 481/8"(1222)

Dual installation kit required.

DUAL INSTALLATION

If two units are installed side by side, a dual installation kit

may be required. Installations without a custom ller strip

require a dual installation kit. If a dual installation kit is not

specied, a 2" (51) ller strip is recommended between the

units. Dual installations without a ller strip can only be

accomplished using two units with opposite hinges. Refer to

the illustrations below.

Dual installation kits are available through an authorized

Sub-Zero dealer. For local dealer information, visit the nd

a showroom section of our website, subzero.com. For

questions regarding the installation, call Sub-Zero Customer

Care at 800-222-7820.

WITHOUT FILLER STRIP FILLER STRIP

Opposite hinges

Same side hinges

subzero.com

Electrical Requirements

Installation must comply with all applicable electrical codes.

The electrical supply should be located within the shaded

area shown in the illustration below. A separate circuit ser-

vicing only this appliance is required. A ground fault circuit

interrupter (GFCI) is not recommended and may cause inter-

ruption of operation.

IMPORTANT NOTE: The electrical outlet must be placed so

the grounding prong is to the right of the thinner blades.

The outlet must be ush with the back wall.

ELECTRICAL REQUIREMENTS

Electrical Supply 115 VAC, 60 Hz

Service 15 amp dedicated circuit

Receptacle 3-prong grounding-type

WARNING

Do not use an extension cord, two-prong adapter, or

remove the power cord ground prong.

Preparation

To operate properly, the door must open a minimum of 90°.

Use a minimum 3" (76) ller in corner installations to assure

a 90° door opening.

Uncrate the unit and inspect for damage. Remove and

recycle packing materials. Do not discard the kickplate, anti-

tip bracket, hardware, and the leveling legs which hold the

wood base to the bottom of the unit.

Anti-Tip Bracket

WARNING

To prevent the unit from tipping forward, the anti-tip

bracket must be installed.

MODEL UW-24

The anti-tip bracket should be attached to the wall behind

the unit with the bracket ange located 1/4"(6) above the top

of the unit. Refer to the illustration below. Failure to properly

position the anti-tip bracket will prevent proper engagement.

For installations that cannot accommodate the anti-tip

bracket, a countertop bracket is provided to secure the unit

to the countertop. Refer to the illustration below.

MODEL UW-24 | UW-24FS SITE PREPARATION

3" (76)

151/2"

(394)

(51)

LEFT SIDE

OF OPENING

FLOOR

Electrical supply location

1/4"(6)

ANTI-TIP

BRACKET

COUNTERTOP

BRACKET

Anti-tip bracket (UW-24)

Countertop bracket

Sub-Zero Customer Care 800.222.7820

Anti-Tip Bracket

MODEL UW-24FS

The back of the anti-tip bracket must be installed 245/8"

(625) from the front and centered behind the unit. Refer to

the illustration below. Refer to page 16 for wood and con-

crete oor applications.

MODEL UW-24 | UW-24FS INSTALLATION

ANTI-TIP BRACKET

Anti-tip bracket (UW-24FS)

Custom Panel

MODEL UW-24

For overlay applications, a custom door panel must be

installed. Panel size is critical for a proper t. To verify the

panel requirements and dimensions, refer to the Sub-Zero

Design Guide at subzero.com/specs.

Finish all sides of the custom panel. They may be visible

when the door is open or through the glass door.

The custom overlay door panel is attached using the screws

provided, through the door frame. The screw locations are

marked on the back of the custom panel using tenon cen-

ters inserted into the holes of the door frame.

With the unit secured and door closed, hold the custom

panel in the desired position on the door. Lightly tap the

front of the panel to locate the mounting positions. Remove

the tenon centers. Refer to the illustration below.

The door frame has mounting holes to accommodate

Sub-Zero accessory handles. If the handle mounting holes

are not used, the handle should be attached to the custom

panel prior to mounting. The screw heads may need to be

countersunk into the panel for proper alignment.

To mount the custom panel, open the door and use the pre-

drilled holes to position the panel. Drive the screws into the

panel through the black tape on the door frame. The screw

holes are hidden behind the door gasket. Use as many

screws as necessary to secure the custom panel. Refer to

the illustration below.

GASKET

GLASS

13/32" (11)

DIAMETER

1/4" (6)

DIAMETER

Tenon center

Door frame cross section

DOOR

FRAMEPANEL

TENON CENTER

subzero.com

MODEL UW-24 | UW-24FS INSTALLATION

Custom Panel

Adjustments can be made to the custom panel with a few

mounting screws in place, but not fully tightened. Once the

proper position is achieved, install and secure all screws.

Cover the holes on the inside of the door frame with the

cover patches or plugs provided.

CAUTION

A solid panel cannot be installed over the glass door. A

solid door is available through an authorized Sub-Zero

dealer. For local dealer information, visit the nd a

showroom section of our website, subzero.com.

Placement

CAUTION

Before moving the unit into position, secure the door

closed and protect any nished ooring.

Use an appliance dolly to move the unit near the opening.

If the unit has been on its back or side, it must stand upright

for a minimum of 24 hours before connecting power.

If the unit will be connected to a home security system,

run lead wires through the compressor compartment prior

to positioning the unit. Refer to page 8. Once the unit is in

position, the wiring connections can be completed from the

front.

Leveling

Level the unit before sliding it into position. Turn each of the

four leveling legs clockwise to raise the unit and counter-

clockwise to lower. Refer to the illustration below.

LEVELING LEGS

Leveling

Sub-Zero Customer Care 800.222.7820

MODEL UW-24 | UW-24FS INSTALLATION

Completion

Plug the power cord into the grounded outlet, then slide

the unit into position. Verify the anti-tip bracket is properly

engaged.

It may be necessary to install the unit 1/4"(6) beyond the

front surface of adjacent cabinetry to prevent interference

when the door is opened to 145°. Refer to the full-scale

template on page 9.

HOME SECURITY CONNECTION

If the unit will be connected to a home security system,

make connections to the leads shown in the illustration

below. Refer to the following color codes:

•Normally open contacts—white with red stripe wire.

•Normally closed contacts—white with blue stripe wire.

•Common—gray with white stripe wire.

Use the spade terminals or wire nuts provided to make

proper wiring connections.

CAUTION

The alarm circuit in the unit is intended as a low-

voltage, low-current device only. It should not be used

to switch line power. Any unused terminals should be

completely insulated and all wires should be secured

away from conductive or moving components.

ANCHORING

To anchor, use the countertop bracket provided to secure

the unit to the underside of the countertop. Refer to the

illustration below. If the countertop bracket cannot be

used, install shims along the top and sides of the unit.

KICKPLATE INSTALLATION

Install the kickplate using the two screws provided. Refer

to the illustration below. The kickplate must be removable

for service. The oor cannot interfere with removal. Do not

cover the louvered section of the kickplate.

COUNTERTOP

BRACKET

KICKPLATE

Anchoring

Kickplate installation

HOME SECURITY

LEADS

Home security connection

subzero.com

MODEL UW-24 | UW-24FS INSTALLATION

DOOR CLOSED

UNDERCOUNTER

UNIT

ADJACENT

CABINETRY

3/4"(19) DOOR PANEL

1/2"

(13)

1/8"(3)

1/4"(6)

HINGE AT 145°

OPENING

(DOOR OPENS PAST 145°)

1" (25)0"

SCALE

145° door opening (top view)

Door Clearance

FULL-SCALE TEMPLATE

To allow for a 145° door opening, the unit should extend

a minimum of 1/4"(6) beyond the front surface of adjacent

cabinetry. The unit can be installed ush, however, there

is potential for interference with the panel if the door is

opened past 90°.

Sub-Zero Customer Care 800.222.7820

Opening Dimensions

STANDARD INSTALLATION

MODEL BW-30 SITE PREPARATION

If two units are installed side by side, refer to page 12.

NOTE:

31/2"(89) finished returns will be visible and should be finished to match cabinetry.

Shaded line represents profile of unit

833/4"

(2127)

OPENING

HEIGHT

24" (610)

OPENING

DEPTH

FRONT VIEW

SIDE

VIEW

TOP VIEW

OPENING WIDTH

3/4"(19)

TYPICAL

FRAMED

CABINETRY

FILLER

31/2"(89)

FINISHED

RETURN

FRAMELESS

CABINETRY

3/4"(19)

TYPICAL

31/2"(89)

FINISHED

RETURN

OPENING WIDTH W

BW-30 291/2"(749)

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Sub-Zero Weinkühler Handbücher

Sub-Zero

Sub-Zero WS-30 Bedienungsanleitung

Sub-Zero

Sub-Zero 427 Bedienungsanleitung

Sub-Zero

Sub-Zero Designer Series Bedienungsanleitung

Sub-Zero

Sub-Zero 424HAG/O-2 Bedienungsanleitung

Sub-Zero

Sub-Zero 424 Bedienungsanleitung

Sub-Zero

Sub-Zero Classic CL3050W/O/L Bedienungsanleitung

Sub-Zero

Sub-Zero Wolf IW Series Bedienungsanleitung

Sub-Zero

Sub-Zero DEC3050WAR Bedienungsanleitung

Sub-Zero

Sub-Zero 424FS Bedienungsanleitung

Sub-Zero

Sub-Zero ICB424 Bedienungsanleitung

Sub-Zero

Sub-Zero 424FS Bedienungsanleitung

Sub-Zero

Sub-Zero 315W Bedienungsanleitung

Sub-Zero

Sub-Zero 424FS Gebrauchsanweisung

Sub-Zero

Sub-Zero DEU1550B/L Bedienungsanleitung

Sub-Zero

Sub-Zero 430 Bedienungsanleitung

Sub-Zero

Sub-Zero WINE STORAGE Betriebsanleitung

Sub-Zero

Sub-Zero 424 Bedienungsanleitung

Sub-Zero

Sub-Zero 315W Bedienungsanleitung

Sub-Zero

Sub-Zero UW-24FS Bedienungsanleitung

Sub-Zero

Sub-Zero 315W Leitfaden

Sub-Zero

Sub-Zero Wolf 400 Series Bedienungsanleitung

Sub-Zero

Sub-Zero 430 Bedienungsanleitung

Sub-Zero

Sub-Zero 315W Bedienungsanleitung

Sub-Zero

Sub-Zero 427 Bedienungsanleitung

Beliebte Weinkühler Handbücher anderer Marken

U-Line

U-Line Echelon Wine Captain 2075WC Betriebsanleitung

Haier

Haier WS50GA Bedienungsanleitung

Cavist

Cavist 62 Bedienungsanleitung

Kenmore

Kenmore 461.99130 Bedienungsanleitung

Miele

Miele KWT 6422 iG Bedienungsanleitung

Danby

Danby DWC113BLSDB Bedienungsanleitung

Caple

Caple Wi6128 Bedienungsanleitung

Avanti

Avanti WC1001 Bedienungsanleitung

Frigidaire

Frigidaire FFWC38F6LS Bedienungsanleitung

Titan

Titan TT-W2454SZ Installationshandbuch

Klarstein

Klarstein Botella 166 Uno Bedienungsanleitung

Costway

Costway FP10130WL Bedienungsanleitung

Lemair

Lemair LWC59 Bedienungsanleitung

Haier

Haier JC-125GEA Bedienungsanleitung

Caple

Caple WCi46B Bedienungsanleitung

Climadiff

Climadiff CLI24 Kurzanleitung

Viking

Viking VCWB301LSS Bedienungsanleitung

Caple

Caple WC6511 Bedienungsanleitung
