Summit SINCCOM1 Bedienungsanleitung

Write the serial number here:

Serial # _____________________

Felix Storch, Inc.

Summit Appliance Division

770 Garrison Avenue

Bronx, NY 10474

Instruction Manual

For Commercial Induction Cooktop

Model SINCCOM1

Page 2 SUMMIT APPLIANCE

Thank you for purchasing SUMMIT’s portable commercial

Induction Cooktop, model SINCCOM1. We fully expect this

product to bring you many years of excellent service.

Please read this instruction manual before installing and

using the Cooktop. Keep the manual in a handy spot so

you can check it for reference in the future.

Technical Information

Model #: SINCCOM1

Electrical Specifications: 120VAC / 60Hz

Power Range: 500 –1800W

Temperature Range: 140°F to 464°F

Timer Range: 0 to 170 minutes

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions

should always be followed including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against electrical shock, do not immerse

cord, plug or main body in water or other liquids.

4. Close supervision is necessary when any appliance is

used by or near children.

5. Unplug from outlet when not in use and before cleaning.

Allow to cool before putting on or taking off parts.

6. Do not operate any appliance with a damaged cord or

plug or after the appliance malfunctions or has been

damaged in any manner. Return appliance to the

nearest authorized service facility for examination, repair

or adjustment.

Technical Information

IMPORTANT SAFEGUARDS

Page 3 SUMMIT APPLIANCE

The use of accessory attachments not recommended

by the

appliance manufacturer may cause injuries.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or

touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or

in a heated oven.

11. Extreme caution must be used when moving an

appliance containing hot oil or other hot liquids.

12. If power cord is detachable, always attach plug to

appliance first, then plug cord into the wall outlet. To

disconnect, turn any control to Off, then remove plug

from wall outlet.

13. Do not use appliance for other than intended use.

14. Do Not Cook on Broken Cooktop –If cooktop should

break, cleaning solutions and spillovers may penetrate

the broken cooktop and create a risk of electric shock.

15. Clean Cooktop with Caution –If a wet sponge or cloth

is used to wipe spills on a hot cooking area, be careful

to avoid a steam burn. Some cleaners can produce

noxious fumes if applied to a hot surface.

16. Any servicing should be performed by an authorized

service representative.

17. A short power supply cord (or detachable power supply

cord) should be used to reduce the risk resulting from

becoming entangled in or tripping over a longer cord.

18. Longer detachable power supply cords or extension

cords are available and may be used if care is exercised

in their use.

19. If a longer detachable power supply cord or extension

cord is used:

a) The marked electrical rating of the cord set or

extension cord should be at least as great as the

Page 4 SUMMIT APPLIANCE

electrical rating of the appliance; and

b) The cord should be arranged so that it will not drape

over the countertop or tabletop where it can be pulled

on by children or tripped over.

20.This appliance may have a polarized plug (one blade is

wider than the other). To reduce the risk of electric

shock, this plug is intended to fit into a polarized outlet

only one way. If the plug does not fit fully into the outlet,

reverse the plug. If it still does not fit, contact a qualified

electrician. Do not attempt to modify the plug in any

way.

21.Built-in mounting should follow the directions in the

installation instructions.

22.To reduce the risk of fire, do not place unit over or near

any portion of a heating or cooking appliance.

23.To reduce the risk of fire, do not store anything directly

on top of the appliance surface when the appliance is in

operation.

24.To reduce the risk of electric shock, do not mount over a

sink.

25.Save these instructions.

Page 5 SUMMIT APPLIANCE

Location of Controls

Use a separate socket. The use of an extension cord could

result in overloading the circuit.

 Place the appliance on a flat surface and keep it away

from the wall and from other articles. Leave at least 2"

of clearance on the sides and 6" at the rear. When the

air vents are blocked, the internal temperature of the

appliance rises and this may result in the unit auto-

matically shutting off during cooking.

 Never heat an empty pot or pan. The appliance will

cease to operate and could be damaged as a result.

 Remember to turn off the appliance after use. If not, the

ventilating fan will continue to operate, resulting in a

waste of energy. (Normally, when the unit is turned off,

the fan continues to operate for 3 minutes before

shutting off automatically.)

 Keep the appliance away from a gas range or electric

oven. If the surrounding temperature is high the unit will

stop heating.

 Be sure to wipe off any water droplets from the bottom

of the cooking pot before heating. If not, the boiling

water may splatter and burn someone.

Cooking surface

TIMER button Power LED

HEATING and

TEMP buttons

Digital display

▼/▲buttons LEDs

Location of Controls

Before Using the Appliance

Power ON/OFF

switch

Page 6 SUMMIT APPLIANCE

How to Use the Induction Cooktop

1. Center a suitable pot or pan on the cooktop and

plug in

the appliance. The Power LED will start to flash.

2. Press the ON/OFF switch to turn on the unit. The

Power LED will be on steady.

The ON/OFF switch controls power to the appliance,

while the HEATING, TEMP and TIMER buttons control

the various functions. The digital Display shows

information about the functions.

3. When the Induction Cooktop is turned on, the HEATING

function will be displayed, and that LED will be lit. If you

want to use this function, press the ▼and ▲buttons to

adjust the HEATING rate to any of 7 levels (from 500W

to 1800W).

4. Press TEMP if you want to set the temperature. The

default temperature setting is 212°F (100°C), but this

can be adjusted by pressing ▼or ▲. The temperature

range of the Induction Cooktop is 140°F to 464°F (60°C

to 240°C).

5. Press TIMER to set the cooking time. The TIMER LED

will be lit and the Display will flash the time. Adjust the

TIMER by pressing ▼or ▲(the

range is from 0 to 170

minutes). When the TIMER button has not been pressed

for a few seconds, the Display will stop flashing and then

will automatically shift to either TEMP or HEATING. The

corresponding LED will be lit. To see the countdown

time on the Display, press TIMER again and the

remaining time will flash briefly.

WARNING: The appliance will be HOT during and after use.

6. The unit will automatically shut off after the set time has

elapsed.

NOTE: For frying in oil, used the TEMP function rather than

HEATING.

How to Use the Induction Cooktop

Page 7 SUMMIT APPLIANCE

Tips

 If possible, use a surge protector with this appliance.

 This appliance is for indoor use only.

 Never submerge the appliance in water.

 Never heat an empty pot or pan.

 Never heat any sealed containers such as a can of soup

to avoid a possible explosion due to heat expansion.

 Even after the appliance is turned off, the cooking

surface remains hot. Avoid touching this ceramic

surface until it has had time to cool down.

 Check under the appliance periodically to be sure the air

vents are not obstructed by any paper, glass, etc.

 Metallic objects like knives, forks, spoons and lids

should not be placed on the cooktop since they can get

hot.

 Never use the appliance in high-temperature

environments such as near a stove.

 Do not put flammable objects in the equipment installed

below the Induction Cooktop.

 If the cooking surface is cracked, switch off the

appliance to avoid the possibility of electric shock.

 Do not use cooking vessels with rough or uneven

bottoms which could damage the ceramic surface of the

appliance.

Tips

Page 8 SUMMIT APPLIANCE

Usable and Non-Usable Cooking Utensils

Usable Pans

Steel or cast iron, enameled iron, magnetic stainless steel,

flat-bottom pots or pans with diameters between 4¾" (12

cm) and 10¼" (26 cm).

 iron pots

 enameled iron pots

 cast-iron pans

 deep-frying pans

 magnetic stainless steel pots

 iron plates

Non-Usable Pans

Heat-resistant glass, ceramic, copper, aluminum, rounded-

bottom pans and pots with bottoms measuring less than

4¾" (12 cm).

 pots with rounded bottoms

 aluminum and copper pots

 pots with bottoms measuring

less than 4¾"

 pots with feet

 ceramic pots

 heat-resistant glass pots

NOTE: If you are unsure about the usability of your

cookware, simply take a magnet (such as one on your

refrigerator) and hold it under the bottom of your pot or

pan. If the magnet sticks, the cookware CAN be used on

the induction cooktop.

Usable and Non-Usable Cooking Utensils

Page 9 SUMMIT APPLIANCE

Cleaning

 Disconnect plug and wait until the unit is cooled down

completely. Clean after each use.

 If pots and pans are used without being cleaned,

discoloration and cooked-on stains may occur.

 Do not use benzene, paint thinner, scrubbing brush or

polishing powder to clean the appliance.

 Wipe the appliance with a clean, soft cloth dampened

with a solution of dish-washing liquid.

 Use a vacuum cleaner to remove dirt from the air intake

and exhaust vents.

 Never run water over the unit. (Water can get inside

and cause a malfunction.)

Cleaning

Page 10 SUMMIT APPLIANCE

Troubleshooting

Error

Message Cause Solution

E0 No pan or unsuitable

pan Use a suitable pan.

E1 Temperature of inter-

nal circuit is too high

or temperature testing

circuit has failed.

Clear/unblock ventila-

tion slots. Let device

cool off for a few min-

utes. If error message

remains after unit has

cooled off, contact re-

tailer.

E2 Heating an empty

pan. Temperature of

pan is too high or tem-

perature testing circuit

has failed.

Remove the cookware

from the cooktop. Let

the device cool off for a

few minutes. The de-

vice is ready for

opera-

tion afterwards.

E3 Voltage is atypical. Let the device cool off

for a few minutes. It

should be ready for op-

eration afterwards.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Summit Kochfeld Handbücher

Summit

Summit CREK2B Bedienungsanleitung

Summit

Summit ZLIC180515 Leitfaden

Summit

Summit CR4B23T6W Bedienungsanleitung

Summit

Summit CR2B228T Bedienungsanleitung

Summit

Summit CSD4B24 Bedienungsanleitung

Summit

Summit CR2220 Bedienungsanleitung

Summit

Summit CR2110TK12 Bedienungsanleitung

Summit

Summit CR1115 Bedienungsanleitung

Summit

Summit SNL053 Bedienungsanleitung

Summit

Summit CR4SS24 Bedienungsanleitung

Summit

Summit CREK4B Bedienungsanleitung

Summit

Summit SINC2220 Bedienungsanleitung

Summit

Summit CR2B120WH Bedienungsanleitung

Summit

Summit CR424WH Bedienungsanleitung

Summit

Summit CR424 Bedienungsanleitung

Summit

Summit CR5B271B Bedienungsanleitung

Summit

Summit CR427 Series Bedienungsanleitung

Summit

Summit SINC2B120 Bedienungsanleitung

Summit

Summit CR2B23T3BTK15 Bedienungsanleitung

Summit

Summit SINC424220 Bedienungsanleitung

Summit

Summit CR2B120 Bedienungsanleitung

Summit

Summit GC2BGL Bedienungsanleitung

Summit

Summit SINC1110 Bedienungsanleitung

Summit

Summit CR4BV230B Bedienungsanleitung

Beliebte Kochfeld Handbücher anderer Marken

Bonnet

Bonnet OPTIMUM 700 Betriebsanleitung

Jenn-Air

Jenn-Air JGCP430 Bedienungsanleitung

Frigidaire

Frigidaire FES367FCC Kurzanleitung

Ztove

Ztove EZ2 DUO Bedienungsanleitung

Kleenmaid

Kleenmaid cooking GCTK9011 Installationsanleitung

Casselin

Casselin CSASRE24 Bedienungsanleitung

Jenn-Air

Jenn-Air JGC2536EB00 Bedienungsanleitung

Waldorf

Waldorf RN8603E-B Bedienungsanleitung

Whirlpool

Whirlpool SMP658CNEIXL Bedienungsanleitung

Wolf

Wolf CI243C/B Bedienungsanleitung

Fulgor Milano

Fulgor Milano F5PGK305S1 Bedienungsanleitung

GE JP389 Bedienungsanleitung

Wells

Wells WV-2HFG Bedienungsanleitung

IKEA

IKEA Lagan HGA4K Bedienungsanleitung

Samsung

Samsung NA36N9755 Bedienungsanleitung

Miele

Miele KM 404 Bedienungsanleitung

Lacor

Lacor 69562 Technisches Datenblatt

Keating Of Chicago

Keating Of Chicago MG-2 Bedienungsanleitung
