FELIX STORCH, INC.

SUMMIT APPLIANCE DIVISION®

INSTRUCTIONS MANUAL FOR:

CP-36R

CP-35

CP-35B

CP-35LL

CP-35BLL

Thank you for putting your trust in our company and for purchasing this appliance. We

hope it will successfully serve its purpose for many years.

A Freezer is used for freezing fresh foods at a temperature of -25°C.

A Refrigerator is used for storing fresh foods at a temperature of 32°F and higher.

A CP-36 is a unique two door refrigerator with a zero degree freezer. Auto-defrost fresh

food section with a manual defrost freezer. This unit has a flush back and is available in

white.

The CP-35 is the same as the CP-36 but without the flush back. And the CP-35 is

available in White (CP-35) and Black (CP-35B) and to add a double lock add the suffix

LL to the model number.

REFRIGERATOR

Before Putting Into Use

Before connecting the appliance to the power supply, leave it standing for about 2

hours, which will reduce a possibility of malfunctions in the cooling system due

to transport handling.

Clean the appliance thoroughly; especially in the interior (See Cleaning and

Maintenance).

Instructions for Use

These instructions for use are intended for the user. They describe the appliance and

the correct and safe way to use it. The instructions were prepared for various

types/models of refrigerators therefore you may find in it descriptions of some

accessories and functions that your appliance may not have.

We Care for the Environment

Our appliances are distributed in packaging made of environmental friendly

material which could safely be recycled, disposed of or destroyed without any

effects on the environment whatsoever.

Our instruction manuals are printed either on recycled paper or chlorine free

bleached paper.

Tips for Energy Savings

Try not to open the door too often, especially when the weather is hot and

humid. Once you open the door try to close it as soon as possible.

Every now and then check if the appliance is sufficiently ventilated

(adequate air circulation behind the appliance).

Set thermostat from higher to lower settings as soon as possible

(depending on how loaded the appliance is, the ambient temperature

etc...).

The coils on the rear of the refrigerator should be cleaned and free of dust

or any other impurities.

Ice and frost layer increase energy consumption, so do clean the appliance

as soon as the layer is 1/8” thick.

Always consider instructions stated in sections Positioning and Energy

Saving Tips, otherwise the energy consumption is substantially higher.

Instructions for Use

Use

Storing Fresh Foods

Foods to be stored in the refrigerator should be properly packed as to

prevent mixing various moisture degrees and odors (in polyethylene bags

or sheet, aluminum foil, wax paper, covered containers or bottles).

Never store any inflammable, volatile or explosive substances.

Beverages with high alcohol percentage shall be stored in tightly sealed

bottles in a vertical position.

Food should not touch the rear wall of the refrigerator.

Some organic solutions like volatile oils in lemon and orange peel, acid in

butter etc. can cause damages when in contact with plastic surfaces or

gaskets for a long period of time.

An unpleasant odor inside the refrigerator is a sign that something is

wrong with the food or that your refrigerator needs cleaning. Odors may

be eliminated or reduced by washing the interior of the refrigerator with a

mild solution of water and vinegar. We also recommend using activated

carbon filters to clean the air or to neutralize odors.

If you plan on taking a long trip make sure you remove all perishable food

before you leave to prevent any odors.

Fresh Food Storag

e Time in the Refrigerator

Storage time (days)

Article of Food

1 2 3 4 5 6 7 8 9 10 11 12 13 14

Butter +++++++=== = =

Eggs ++++++++++ = = = =

Fresh uncut meat ++=

Chopped meat + =

Smokedmeat ++++++++++ = = = =

Fish +=

Marinade ++++++++++ = = = =

Root ++++++++== = = = =

Cheese ++++====== = = = =

Sweets ++====

Fruit ++========

Prepareddishes ++==

Legend: + means recommended storage time

= means possible storage time

Instructions for Use

Commercially Fro

zen Foods

Storage time (months)

Article of Food

1 2 3 4 5 6 7 8 9 10 11 12

Vegetable + + + + + + + + + +

Fruit + + + + + + + + + + + +

Bread, Pastries + + +

Milk + + +

Ready-Made Meals + + +

Beef + + + + + + + + + + + +

Veal + + + + + + + + + +

Pork + + + + + +

Poultry + + + + + + + + + +

Game + + + + + + + +

Minced Meat + + = = = = = = = =

Smoked Sausages + + + +

Lean Fish + + +

FatFish +

Offal ++

Legend: + means recommended storage time

Instructions for Use

Important

To reduce the risk of fire, electrical shock,

Warnin

! or in

when usin

our appliance,

follow these basic precautions.

Read all instructions before using the appliance

If you bought this appliance to replace an old one equipped with a lock

that cannot be opened from inside (lock, bolt), make sure that the lock is

broken. This will make it impossible for children to lock themselves

inside the appliance and suffocate.

The appliance must be correctly connected to the power supply.

If the food has a strange smell or color throw it away because it is very

likely that it is spoiled and therefore dangerous to eat.

Disconnect the appliance from the power supply before repairing and

cleaning it (only a qualified technician should repair it).

Use only enclosed tools or tools recommended by the manufacturer.

For the sake of environmental protection be careful not to damage the rear

wall of the appliance (the condenser unit or the tubes when moving the

refrigerator) or any part of the freezing system inside the appliance. Use

only enclosed tools or tools recommended by the manufacturer.

DANGER: Risk of child entrapment.

Before throwing away your old freezer please remove the doors and leave

the shelves in place so that children may not easily climb inside.

The rating plate is inside the appliance or outside on the rear wall.

Disposing of the Worn Out Appliance

When your appliance finally wears out, dispose of it. If the appliance has

a lock, break it to prevent eventual accidents (danger of children getting

locked inside the appliance).

Instructions for Use

Maintenance and Cleaning

Automatic Defrosting of the Refrigerator

There is no need to defrost the refrigerator, because the ice depositing on the inner

back wall is defrosted automatically.

Ice is depositing on the inner back wall during the compressor operation; later on,

when the compressor is not operating, ice is defrosting and water drops, collects

and drains through the outlet in the inner back wall into the drain pan situated

above the compressor where it evaporates.

Cleaning the Appliance

Disconnect the power supply before cleaning the appliance. Do not use coarse or

Aggressive cleaning agents as you can damage the surface.

Clean the exterior with water and detergent. Varnished surfaces are

cleaned with soft cloth and an alcohol based cleaning agent (for example

glass cleaners). You may also use alcohol (ethanol or isopropyl alcohol).

The application of abrasive and especially aggressive cleaners, such as

stainless steel cleaners, is not appropriate for the cleaning of plastic and

coated parts.

Remove the detachable accessories in the interior of the appliance and

clean it with water and liquid detergent. Plastic parts cannot be washed in

a washing machine.

Wash the interior of the appliance with lukewarm water, in which you add

one or two spoonfuls of vinegar.

Every now and then wipe the condenser on the rear wall. Use a soft non-

metal brush or vacuum cleaner.

Do not forget to clean the defrost water receptacle above the refrigerators

compressor (do not remove the receptacle). After cleaning, connect the

appliance to the power supply and reload the packages.

Switch Off the Appliance When Not in Use

If you do not intend to use the appliance for an extensive period of time set the

thermostat knob to the STOP (0) position and disconnect the power supply. Then

take out the foods and clean the appliance. Leave the door slightly open.

Instructions for Use

Trouble-Shooting Guide

During the service of your appliance, you can come across some troubles that in

most cases result from improper handling of the appliance that can easily be

eliminated.

The Appliance Fails to Operate After Connecting to the Power Supply

Check the supply in the outlet socket and make sure the appliance is

switched on (thermostat in the operating position).

Continuous Operation of the Refrigerating System

The door was frequently opened or it was left open too long.

The door is not properly closed (the door may sag; the gasket may be

polluted or damaged).

Perhaps you have overloaded the appliance with fresh foods.

The reason may be inadequate ventilation of the compressor and

condenser (assures adequate air circulation and wipe off the condenser).

Ice Formation on the Inner Rear Wall

As long as the defrost water runs to the channel and through the opening to the

drain pan on the compressor, automatic defrosting of the appliance is assured. In

case the ice formation on the inner back wall is increased (1/8”), ice should be

manually defrosted.

Set the thermostat knob to STOP (0) position and leave the door open. Never use

electric devices for defrosting and do not scrape the ice or frost layer with sharp

objects. After completed defrosting, turn the knob to desired position and close

the refrigerator door.

The cause of increased ice formation may be one of the following reasons:

-the door does not seal well (clean the gasket if it is contaminated,

or replace it if it is damaged).

-The door was frequently opened or it was left opened for too long.

-The food stored in the refrigerator was warm.

-The food or dish is touching the inner back wall.

Water is Leaking from the Refrigerator

In case the discharged water outlet is clogged, or the defrost water drips over the

channel, or water leaks from the refrigerator just clean the clogged opening with a

plastic straw. Manually defrost the increased ice layer. See “Ice Formation on the

Inner Back Wall”.

Instructions for Use

Noise

Cooling in refrigerating-freezing appliances is enabled by the refrigerating system

with the compressor, this produces noise. How noisy the appliance is depends on

where it is placed, how it’s used and how old the appliance is.

During the operation of the compressor, a liquid noise is heard and when

the compressor is not operating a refrigerant flow is heard. This is a

normal condition and it has no influence whatsoever on the lifetime of the

appliance.

After starting the appliance, the operation of the compressor and the

refrigerant flow may be louder and this does not mean something is wrong

with the appliance. The noise will reduce gradually, this will not affect

the lifetime of the appliance.

Sometimes unusual and strong noises occur which is rather unusual for the

appliance. This noise is often a consequence of inadequate placing. To

avoid the noise make sure the appliance is placed and leveled firmly on a

solid base. Make sure the appliance is not touching the wall or kitchen

units standing next to it. And always make sure you check the accessories

in the interior of the appliance; they should be placed correctly in their

positions. Check the bottles, tins and other vessels that might touch each

other and rattle.

Before Calling for Service

Check the plug and fuse.

Test the outlet with a lamp

Be sure the control is not set to OFF

Read the manual, especially the items under the Use and Care sections.

You may find the answer to your questions.

If you don’t find the answer to your questions in this manual, find the

unit model number (on the upper back of the refrigerator) and contact

your Summit Appliance Dealer.

Specifications are Subject to Change Without

Notice.

Instructions for Use

Andere Handbücher für CP-35

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Summit Kühlschrank Handbücher

Summit

Summit SP6DS7 Bedienungsanleitung

Summit

Summit FFBF247SSIM Bedienungsanleitung

Summit

Summit FF61 Bedienungsanleitung

Summit

Summit SP6DS2D7 Bedienungsanleitung

Summit

Summit FF43 Leitfaden

Summit

Summit FFBF283SS Bedienungsanleitung

Summit

Summit BAR77S Bedienungsanleitung

Summit

Summit FF29B Bedienungsanleitung

Summit

Summit FF43SS Leitfaden

Summit

Summit AL650 series Bedienungsanleitung

Summit

Summit SP6DS Bedienungsanleitung

Summit

Summit S19L Bedienungsanleitung

Summit

Summit FF1091WIM Bedienungsanleitung

Summit

Summit FFAR21L Bedienungsanleitung

Summit

Summit FF642D Bedienungsanleitung

Summit

Summit FF-1074 Series Bedienungsanleitung

Summit

Summit AL750 series Leitfaden

Summit

Summit FF31L7BI Bedienungsanleitung

Summit

Summit FF7L Leitfaden

Summit

Summit Accucold FF6W Series Bedienungsanleitung

Summit

Summit FF412ES Bedienungsanleitung

Summit

Summit FFBF241W Bedienungsanleitung

Summit

Summit FFBF285SS Bedienungsanleitung

Summit

Summit FDRD15SS Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
