SunBriteTV Veranda SB-4374UHD-BL Bedienungsanleitung

Veranda Outdoor Television

Quick Start Guide SB-4374UHD-BL, SB-5574UHD-BL, SB-6574UHD-BL

Planning the Location

Place the Veranda only in a fully shaded area.

Sources/What to Watch

• Signals can be sent from any source using

an HDMI, Component, or digital antenna

connection.

• Refer to the operator’s manual for detailed

instructions.

Weather Proong

ETHERNET

RJ45 terminal for

service only

DIGITAL

AUDIO OUT

terminal

ANALOG

AUDIO OUT

terminal

ETHERNET OPTICAL COMPONENT/VIDEO DTV/TV

Y/Y Pb/Cb Pr/Cr L AUDIO RL R CABLE/AMTENNA

(10/100)

COMPONENT/

VIDEO IN terminal* 4

USB 1

Rear IR

USB 2

HDMI 1 terminal

HDMI 2 terminal

HDMI 3 terminal

ARC: Audio Return Channel

HDMI 4 terminal

MHL: Mobile High-Definition Link

CABLE/ANTENNA IN

HDMI HDMI HDMI HDMI

USB USB

• After all connections are made, all wires

must exit the media bay from the bottom.

• Up to 5 wires can exit the media bay while

still maintaining the weatherproof feature.

Note: Leave a drip loop as the wires enter the

compartment.

• Tighten the thumb screws completely to

weatherproof the TV.

Wires

Drip Loop

Media Bay

Thumb Screws

SETUP

• Use the TV remote to access the setup menu and run initial installation.

• Select Language, Location and Time Zone, and default TV settings for the TV location.

• Select the corresponding input source and follow on screen instructions to complete

setup.

• Refer to the operator’s manual for detailed instructions. Press “Menu”on the remote

control to access the internal operation manual or visit the product support page on

www.snapav.com or www.sunbritetv.com.

CONTROL

The Veranda can be controlled via the included remote or universal remote.

IR codes are available at: https://www.sunbritetv.com/support/product-support/product-faq.
