Sundrax Splitter PRO Bedienungsanleitung
User
Manual
Version 2.00
September 29, 2020
SPP-3-1D5D, SPP-5-1D5D, SPP-6-1D5D,
SPP-3-1D10D, SPP-5-1D10D, SPP-6-1D10D,
SPPD-3-3D8D, SPPD-5-3D8D, SPPD-6-3D8D
Splitter PRO
Splitter PRO DUO
Contents
Specifications
Safe operation
General information
Advantages
Installation
Indication
Connection scheme
Technical maintenance
Notes
3
3
3
3
4
4
5
7
7
2
Splitter PRO
Specifications
Supported protocols
DMX data refresh rate
DMX input ports
DMX output ports
DMX connectors
Mounting
Power supply
Mains Fuse
Input power
Operating Temperature:
IP Rating
DMX512, RDM
44 Hz
1 or 3 isolated
5,8 or 10 isolated
XLR (5 pins, 3 pins) or RJ-45 (etherCON)
Rack
~100-250 VAC, 50/60 Hz
0.5 A
5 W
-0°С... +60°С
IP 20
General information
Splitter Pro is a single-channel DMX512 splitter and is an effective solution for controlling dynamic
lighting equipment. A feature of the splitter is the ability to transfer DMX512, RDM (ANSI E1.20)
protocols from one input to 5 or 10 outputs.
Splitter Duo Pro is a double-channel DMX512 splitter with 2 inputs and 8 outputs. Splitter Duo Pro can
work as two separate splitters 1-to-4, or as a single splitter with 1 input and 10 outputs
(similar to Splitter Pro).
Splitter Pro and Splitter Duo Pro can be supplied with XLR 5-pin, XLR 3-pin, or EtherCON connectors.
RDM support can be enabled and disabled by a stick switch on the front panel.
Each input connector has a through-output connector to pass DMX512 signal to other devices in a chain.
The device is designed in a housing for installation in a 19-inch rack and can be used at positive
temperatures indoors.
Safe operation
In installation, operation, preventive maintenance and
repairs of the device, the requirements of the safety rules
must be followed.
To ensure safe and reliable operation of the devices, please
observe the following requirements:
Use the device only for its intended purpose
Do not use devices that shows signs of malfunctioning
Avoid strong physical impacts on the device
Protect devices and cables from contact with corrosive liquids
Whenever a fault is detected in the device, please contact the manufacturer.
Warning!
The device uses hazardous
voltage AC 100-250V
3Splitter PRO
Installation
Before mounting and power up, it is necessary to verify protective earthing and cable connections.
1. Ensure the device has no damage due to transportation
2. Install the unit into the rack and secure it with screws. Connect the power cable plug
to a power outlet
3. Connect cable to input port “IN” if you use Splitter Pro device or to necessary input port
(“IN COM”, “IN A” or “IN B”) if you use Splitter Duo Pro device. If the input signal is present,
the appropriate port indicator lights green. If there is no signal, the indicator is red.
4. Connect the desired number of output lines to the “OUT” connectors.
5. The device is ready for use
Indication
Splitter Pro indicates presence of DMX512 signal on the input(s), activity in DMX universe,
and the RDM E1.20 activity.
Advantages
Rack form factor 1U 11 cm deep with protection IP20
Maximum surge protection – power supply optimized for voltage from 90 to 315 VAC
Thru DMX outputs for each input
Smart indication of operating modes
Full RDM support (ANSI E1.20)
Galvanic isolation on all ports
Fastest recovery after short power failure
PowerCON TRUE1 inlet+outlet combination
4
Splitter PRO
LED
Red
Green
Blinks green
Blinks orange
Status
No valid DMX signal on input
Valid signal is detected, no changes in DMX data
Valid signal is detected, DMX data is being changed
RDM activity is detected
Connection scheme
Splitter Pro, Splitter Duo Pro (single input mode)
5Splitter PRO
DMX
DMX
DMX
DMX
Splitter Duo Pro (double input mode)
6
Splitter PRO
Connection scheme
PUSH PUSH PUSH PUSH PUSH
Splitter DUO
PRO
PUSH PUSH PUSH PUSH PUSH PUSH
DMX A
DMX B
DMX COM
DMX RDM
DMX ONLY
SECTION A SECTION B
DMX A DMX B
DMX A
DMX A
DMX B
DMX B
Technical maintenance
Maintenance the device, search and troubleshooting should be performed
by service personnel. The device should be free from dirt, dents, connecting
cables and wires must be intact and securely fastened.
Notes
Please send all your warranty-related questions to [email protected]
All Sundrax products are covered by a 36 months warranty.
7Splitter PRO
Sundrax Electronics
6008, First Central 200
2 Lakeside Drive, Park Royal, London
NW10 7FQ United Kingdom
+ 44 (0) 208 991 33 19
www.sundrax.com
