eArc™PV System
Installation Manual
Contents
Purpose of this guide
Features & Benefits
Notices
General safety
Handling safety
Installation safety
Fire safety
Production Identification
Mechanical Installation
Grounding
Electrical installation
Maintenance and care
Disclaimer of liability
Products Data
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 1 / 29
TM
Purpose of this guide
•This guide contains information regarding the installation and safe handling of Sunman (Zhenjiang)
Company Limited eArc PV system. Sunman (Zhenjiang) Company Limited referred to as “SUNMAN”.
•Installers must read and understand this guide prior to installation. For any questions, please contact
SUNMAN’s Customer Service Department “or our local representatives” for more detailed information.
Installers should follow all safety precautions described in this guide as well as local codes when
installing a eArc.
•Before installing a solar photovoltaic system, installers should familiarize themselves with its
mechanical and electrical requirements. Keep this guide in a safe place for future reference (care and
maintenance) and in case of sale or disposal of eArc.
•SUNMAN’s eArc are tested and certified for installations worldwide. Different regions may have
different regulations for solar PV installations.
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 2 / 29
TM
Features & Benefits
•Flexible layouts
•eArcTM PV system can be installed at any shape roofs, which has integrated appearance with buildings.
Providing aesthetic seamless look.
•Maximization installation coverage of panels over any kind of roof.
•Quick installation
•Ultra-thin and light design to save installation labour
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 3 / 29
TM
Notices
This manual contains important installation instructions for the core hardware components required
for eArcTM PV System PV arrays.
Copyright and Trademark Information
Copyright © 2019 by Sunman (Zhenjiang) Company Limited. All rights reserved.
eArc and the SUNMAN logo are trademarks of Sunman (Zhenjiang) Company Limited.
Warranty Warnings
“WARRANTY VOID IF NON-SUNMAN-CERTIFIED HARDWARE IS ATTACHED TO eArcTM PV System.”
For Further Information
For additional technical support documentation, please visit the Support page of the SUNMAN web
site at www.sunman-energy.com
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 4 / 29
TM
General safety
•eArc that fall under this application class may be used in system operation at more than 50V DC or
240W, where general contact access is anticipated. eArc are qualified for safety under IEC 61730-2 and
within this application class are considered to meet the requirements for Safety Class II.
•eArc are qualified for Application Class A(IEC 61730-1).
•Installing solar photovoltaic systems requires specialized skills and knowledge. Installation should only
be performed by qualified personnel.
•Installers should assume all risks of injury that might occur during installation, including, but not limited
to, the risk of electric shock.
•One single eArc may generate more than 30V DC when exposed to direct sunlight. Contact with a DC
voltage of 30V or more is potentially hazardous.
•Do not disconnect during load connection.
•Photovoltaic solar eArc convert light energy to direct current electrical energy. They are designed for
outdoor use. eArc can be ground mounted, mounted on rooftops, vehicles or boats. The proper design
of support structures lies within the responsibility of the system designers and installers.
•Do not use mirrors or other magnifiers to concentrate sunlight onto eArc.
•When installing the system, abide to all local, regional and national statutory regulations. Obtain a
building permit if necessary.
•eArc electrical characteristics are within ±10% of the indicated values of Isc, Voc and Pmax under
standard test conditions (Irradiance of 1000W/m², AM 1.5 spectrum, a cell temperature of 25℃).
•Only use equipment, connectors, wiring and support frames suitable for solar electrical systems.
•“Always use fall protection equipment when working from heights of 6 feet （183cm）or above”.
Follow Occupational Safety and Health Act (OSHA) or local governing safety regulations regarding fall
protection. (UL only)
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 5 / 29
TM
Handling safety
•Do not lift eArc by grasping eArc’junction box or electrical leads.
•Do not stand, step or walk on any side of eArc.
•Do not drop eArc or allow objects to fall on eArc.
•Do not place any heavy objects on eArc.
•Be cautious when placing eArc down onto a surface, particularly when placing it in a corner.
•Inappropriate transport and installation may damage eArc panel and void the warranty.
•Do not attempt to disassemble eArc, and do not remove any attached nameplates or components from
eArc.
•Do not apply paint or adhesive to eArc’top surface.
•To avoid damage to the front cover and backsheet: do not scratch, dent or hit the front cover and
backsheet.
•Do not drill holes in the ribs. This may compromise the frame strength, cause corrosion of the ribs and
void the warranty.
•Do not scratch the anodized coating of the ribs (except for grounding connection). It may cause
corrosion of the ribs or compromise the ribs strength.
•A panel with broken front plate or torn back sheet cannot be repaired and must not be used since
contact with any panel surface or the ribs can cause an electric shock.
•Work only under dry conditions, and use only dry tools. Do not handle panels under wet conditions
unless wearing appropriate protective equipment.
•When storing uninstalled panels outdoors for any period of time, always cover the panels and ensure
that the front cover faces down “on a soft flat surface” to prevent water from collecting inside the panel
and causing damage to exposed connectors.
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 6 / 29
TM
Installation safety
•Never open electrical connections or unplug connectors while the circuit is under load.
•Contact with electrically charged parts of the panels, such as terminals, can result in burns, sparks and
lethal shock whether or not the panel is connected.
•Do not touch eArc unnecessarily during installation. The front surface and the ribs may be hot; there is
a risk of burns and electric shock.
•Do not work in the rain, snow or in windy conditions.
•Avoid exposing cables to direct sunlight in order to prevent insulation degradation.
•Keep children well away from the system while transporting and installing mechanical and electrical
components.
•Completely cover eArc with an opaque material during installation to prevent electricity from being
generated.
•Do not wear metallic rings, watchbands, earrings, nose rings, lip rings or other metallic objects while
installing or troubleshooting photovoltaic systems.
•Use only insulated tools that are approved for working on electrical installation.
•Follow the safety regulations for all other system components, including wires and cables, connectors,
charging regulators, inverters, storage batteries, rechargeable batteries, etc.
•Under normal conditions, a photovoltaic eArc is likely to experience conditions that produce more
current and/or voltage than reported at standard test conditions. Accordingly, the values of Isc and Voc
marked on this eArc should be multiplied by a factor of 1.25 when determining component voltage
ratings, conductor current ratings, fuse sizes, and size of controls connected to the PV output.
•Only use same or connectable connectors to connect eArc to form a string, or connect to another device.
Removing the connectors will void the warranty.
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 7 / 29
TM
Fire safety
•Consult your local authority for guidelines and requirements for building or structural fire safety.
•Roof constructions and installations may affect the fire safety of a building; improper installation may
create hazards in the event of a fire.
•Use components such as ground fault circuit breakers and fuses as required by local authority.
•Do not use panels near equipment or in places where flammable gases may be generated.
•eArc have been rated Fire Class C, and are suitable for mounting on to a Class A roof.
© 2021 Sunman (Zhenjiang) Co., Ltd. All rights reserved. Specifications included in this manual are subject to change without notice.
www.sunman-energy.com
version 2021A page 8 / 29
TM
Production Identification
Each eArc has two labels providing the following information:
•Nameplate: describes the product type; rated power, rated current, rated voltage, open circuit voltage,
short circuit current, all as measured under standard test conditions; weight, dimensions etc.; the
maximum system voltage is 1000 volts.
•Barcode: each individual eArc has a unique serial number. The serial number has 18 digits. The 1th to
4th digits are the module type for internal use, and the 5th and the 6th digits are the year code, and
the 7th and 8th digits are the month and the 9th and the 10th digits are the week code, and the 11th
and the 15th digits are order number, and the 16th and the 18th digits are the sequence codes. For
example, XXXX160417XXXXXXXX means the module was made in the 17th week of 2016. Each module
has only one bar code. It is permanently attached to the interior of eArc and is visible from the top front
of eArc. This bar code is inserted prior to lamination.
