Sunstech TAB87QCBT Bedienungsanleitung
TAB87QCBT
Tablet PC
Android 4.4.2
User Manual
Tablet of Contents
Specifications............................................................................................................................1
Tablet Parts................................................................................................................................2
Getting started.........................................................................................................................3
How to use TF card................................................................................................................7
How to connect with computer.........................................................................................8
Connection to Internet.........................................................................................................8
Camera........................................................................................................................................9
Trouble Shooting..................................................................................................................10
Specifications
Operating System: ANDROID 4.4.2
Display: 8 inch 1280x800 Capacitive multi-touch screen
CPU: A33 Quad-Core A7 1.3GHZ
RAM: 1G DDR III
GPU Mali-400@450Mhz
Internal Storage: 16GB
Micro SD Slot : Up to 32 GB (not supplied)
Wireless: 802.11b/g/n
Bluetooth 4.0
Micro USB 2.0 / OTG
Front camera 0,3 Mpixels. back camera 2 mpixels
Battery : 3500mAh AC
Adapter: DC 5V-2A
Output headphones.
Built-in microphone.
Made in China
What’s Inside The box
Tablet – 1pc
Power Adapter -1pc
USB Cable -1pc
OTG Cable -1pc
Instruction manual - 1pc
Warranty card - 1pc
1
Tablet Part
2
1 ------ Power
2 ------Decrease volume Press the button to decrease the volume
3 ------Increase volume Press the button to increase the volume
4 ------ Earphone jack
5 ----- USB OTG Port
PC connection/peripheral connection through OTG
cable (for example keyboard, USB device)/battery
charge through the supplied adaptor
Getting Started
Battery Charging
The tablet has a built-in rechargeable Li-polymer battery.
3
Name Function
Keep pressed to turn on/off the tablet; shortly
press to activate standby mode
Connect earphone to this standard 3.5mm jack.
6 ----- Micro sd Micro SD Slot : Up to 32 GB (not supplied)
3. The tablet can be used even if the battery is being charged.
the above icons indicate the different level of power left in the battery
4. Do not replace the battery without authorization, or the explosion
hazard might happen.
5. Recharge it for at least half hour if it has been idle for long time and fails
to start itself.
6. Regularly recharge it at least once a month
7. 40°—5° is the optimum temperature for the battery recharging or
the battery performance might deteriorate slightly
Disposal
the battery might contain the polluting material, please give it to the official
recycling-station before disposing the tablet pc, and don’t litter.
Power ON/OFF
ON:
press the button for continuous 5 seconds until the tablet turns “ON”.
OFF:
1.Press the button for continuous 5 seconds and it will appear
2.Select OK to power off the tablet
Screen Lock
This feature locks the screen, at the same time turn OFF the screen’s
backlight after a few seconds.
Screen locks when:
1. System is idle.
2. Manually activated by pressing the Power button once.
Screen unlock :
Home screen
The Home screen will look similar to the picture below. It is actually
five
4
2. The battery icon shows the battery status and charging status
1. To charge connect the AC power adapter to the micro power jack on
the right side of the tablet.
screens, each of which can have a different layout of icons. To switch between
screens, simply slide your finger left or right across the display.
The status bar and navigation buttons are always visible, no matter which
Home screen you can currently viewing.
The Desktop contains shortcuts to your most-used applications and widgets
Touch the screen icon to quickly search the World Wide Web using Google.
The icon will launch the Application menu.
The status bar displays system information, such as current time, wireless
connectivity and battery.
Touch to Expand the status bar for more detailed information.
The button moves back one step to the previous menu/page.
The buttons returns immediately to the Android desktop.
The button display a menu of recently opened applications.
5
The settings menu allows you to adjust Tablet system
configuration. To change settings:
1. Touch the "Settings" menu icon on the Application menu.The
Settings menu will open.
2. Guide your finger up or down the left side of the screen to scroll through
the list of available categories.
3. Touch a category title to view further options on the right side of the
screen.
Wi-Fi - Connect to /disconnect from wireless networks, view connection
status Data usage - Enable / disable mobile data, view current usage, set
mobile data limit (note: this function is available only on devices supplied with
3G card) Sound - Change volume, touch sound, screen lock sounds etc
Display - Change brightness, wallpaper, sleep settings, font size etc
Storage - Manage NAND and Micro SD card, view available capacity etc
Battery - See battery status and powered-on time Apps - Manage applications,
running services etc Accounts - Manage accounts etc
Apps - Manage applications, running services etc
USERS& PROFILES- TO create a new user and profiles.
Accounts & sync - Switch synchronization on /off, manage accounts etc
Location services - Change approximate location detection, improve search
results
Security - Change screen lock type, encryption, password, credential storage
etc Language & input Select language, add to the dictionary, edit on-
screen keyboard settings, vocal search, etc
Backup & reset - Backup & restore data, perform factory reset, etc
Date & time - Set date, time zone, time, clock format etc
Accessibility - Set up large text, auto-rotate screen, speak password etc
Developer options - Advanced functions for Android developers - debugging,
HDCP check etc
About tablet - Information about your Android device
6
Settings Menu
2. A prompt will be seen on the screen saying “ Preparing SD card “
Removing TF card
1. Close all applications and documents which have been opened from the TF
card.
3. Select “Setting” and find “ Storage” then click “Unmount SD card”.
4. A prompt will be seen on the screen saying “ SD card safe to remove”
5. Gently press the TF card to remove and pull out the TF card.
Note: Insert the TF card in correct position, otherwise it will damage the card
and the slot.
Software Keyboard
The tablet has a software keyboard which automatically show up when
you tap the place on screen where text or number are to be entered.
Touch Screen
The touch screen responds to finger touch.
Note: don’t place any object on the touch screen for it may damage or crush
the screen.
Single Click: single click one icon to choose the icon or option you want. Long
Press: press and hold one icon to make appear a menu related
to the executed function (if available).
Drag: drag on the screen and you can move between magic cube sides
or drag the application icons into the shortcut bar.
7
How to Use TF card
1. Insert the TF card into the TF card slot. Gently push TF card into slot until it
clicks into place. Please, see the page 2 about the Microsd slot.
2Press USB connected on the top bar, then click Turn on USB storage, click
OK.
3. Then the USB connection has been successfully.
Connection to Internet
Wireless:
1Select “ Settings”
2Select “Wi-Fi” and slide OFF to ON status.
3All detected wireless networks in the area will be listed, Click to select
desired wireless connection.
4Enter WEP key or network key if necessary.
5Once connected to a wireless network, settings will be saved
6Wireless icon will appear on the taskbar when connected successfully.
Note: when the tablet detects the same wireless network in the future, the
device will connect to the network automatically with same password record.
8
How to connect with computer
Note: Turn on your Tablet before connect the Tablet to PC by USB cable.
1Use USB cable to connect with the computer. System will notice USB
connected on bottom of screen.
