Supa L16 Bedienungsanleitung
Contents
Introduction 2
Glossary 2
Away Arming 3
Home Arming 4
System Disarm 5
Bypass Zone
Review Event Memory 7
Walk-Test 8
System Test 8
Panic, Medical, Fire Alarm 9
Duress Alarm 10
Programming User Codes 11
Deleting User Codes 11
Programming User Partition ________________________________ 12
Programming Telephone Numbers 13
Deleting Telephone Numbers 13
Program Timers 14
Rename the Zones ________________________________ 15
Restricting Installer Code 1
Call-In Beeping Tone Menu 17
Call-Out Beeping Tone Menu 18
Call-In Block Diagram 19
Call-Out Block Diagram 20
Quick Operation Reference 21
Disclaimer 22
L16_UM1016-v1.0
1
www.ealarm.com.my
SUPA L16 User Manual
Introduction
Congratulations on your ownership of this security alarm system. You've made a wise decision in
choosing it, for it represents the most innovative, precise and the latest in security protection
technology today. We would like to personally thank you for your purchase and would like to provide
you with additional information on this remarkable unit.
This security alarm system offers interior and perimeter protection. Various sensors are strategically
positioned throughout your premises to perform security monitoring such as detection of movement,
opening of windows and doors, shattering of glass, e cess heat or smoke ….and so on. This alarm
system has 16 zones and can be divide to 4 partitions. Your system may also be programmed to
automatically transmit alarm and status messages to a central monitoring station and also provide
appropriate information in the form of beeping tones during an alarm event, both over the telephone
network.
Please take a few minutes to review the contents of this manual. In order to realize the full potential of
this system it is important that you feel comfortable with its operation. The following pages will
familiarize you with the procedures for operating the security alarm system.
Glossary
●Delay zone allows limited time entry to or e it from the protected premises and to perform
Disarm or Arm respectively before the alarm goes off.
●Instant zone immediately triggers off the alarm if violated during Arm status.
●24 Hour zone generates an alarm at all times regardless of the system Arm or Disarm state.
●Triple reporting allows three types of reporting formats in which the system dials your personal
telephone number, IP reporting address and to a central monitoring station to report of events
and alarms.
●Chime function causes the keypad beeper to sound a tone when zones are opened during
Disarm state.
●Remote arming and disarming allows you to Arm and Disarm your security system using your
mobile phone or local touch tone telephone from anywhere in the world.
●Quick mode function to activate Away, Home, Bypass, Review modes directly without the need
to enter your User code.
●Force arm function allows the system to arm, even if there are zones which are not yet secured
or still open.
●Auto daily test reports to Central monitoring station on the operating condition of the system’s
dialler.
●Key-switch input is connected to a normal switch or e ternal radio remote control to perform
various system operations.
●Beeping tone menu allows you to perform standard functions remotely through a telephone with
an audible low frequency tones as feedback.
●Master User reserves the highest priority over other users. Only Master code is allowed to
program personal telephone numbers, user codes, user partition, timers and rename zone name
during system Disarm. No programming is allowed during system Arm.
L16_UM1016-v1.0
2
www.ealarm.com.my
Away Arming
LCD/LED Keypad display
Press [ # ] + [ AWAY ] / [ 9 ] + [ Partition Select ]
(If Quick Away option is enabled)
Or
Press [ User Code ] + [ 9 ]
☼ The partition armed light turns on on LED keypad and arm light turns on on LCD keypad.
♪ Leave the premises within the E it time. E it beeping will continue until E it time e pires.
☼ The Line light turns on to indicate system dialler performing CMS reporting.
Information
●Away arming will activate all zones of your alarm security system e cept bypassed zones. All
interior and e ternal perimeters are armed. Use this mode when leaving your premises.
●Before arming your system to Away mode, all zones should be closed. There should not be any
movement in the rooms protected by motion detectors and each door or window protected by
reed switches should be properly closed.
●Key-switch input is available on the control panel and can be used to toggle between Arm and
Disarm.
●If an illegal code is entered to Arm in Away mode, the system responds by a long error beep.
●The system cannot Arm while in other operation mode. Press [ ] + [ ] to e it from other
operation mode first.
Options to be Programmed by Installer
●No Force Arm:
The system will not be allowed to Arm via keypad if an Instant zone is left open but not if it is
a delay zone. A long error beep is issued to warn you of such situation. If you want Force Arm
function, any zones left opened after arming will be automatically bypassed and are reported
as zone bypass. The system will resume monitoring the zone once it is closed again for the
duration of that armed period.
●Force Arm Siren Warning:
The siren will continuously sound or squawk to indicate a Force Arm situation. You should
Disarm the panel, check the premises and then Arm again. Continual warnings could mean
there is a problem with a detection device and that particular zone may have to be manually
bypassed.
●Away Squawk:
Siren will output two squawks upon arming the system in Away mode and output a single
squawk when the system is disarmed.
●No Arm If Battery Low:
You may not Arm the system if the back-up battery is determined as low and A.C power is not
present.
●E it Beep:
Keypad beeper will beep continuously for the duration of E it time.
Please consult your installer to enable the above options.
L16_UM1016-v1.0
3
Away1
Total Open (00) Partition A1 A2 A3 A4
Zone 1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
Away1/Rea y 2/3/4
Total Open (00)
www.ealarm.com.my
Home Arming
LCD Keypad display
Press [ # ] + [ HOME ] + [ Partition Select ]
(If Quick Home option is enabled)
Or
Press [ User Code ] + [ 8 ]
☼ The partition armed light will blink on LED keypad and arm light turns on on LCD keypad.
☼ The Line light turns on to indicate system dialler performing CMS reporting.
Information
●Home Arming will only activate e ternal perimeter portion of your alarm security system. Interior
protection is not armed, which allows movement within premises without causing alarm. Use this
mode when you are in the premises.
●Your installer must program which zones to be active in Home arming mode.
●If an illegal code is entered to Arm in Home mode, the system responds by a long error beep.
●The system cannot Arm in Home mode while in other operation mode. Press [ ] + [ ] to e it
from other operation mode.
Options to be Programmed by Installer
●No Force Arm:
The system will not be allowed to Arm via keypad if an Instant zone is left open but not if it is
a delay zone. A long error beep is issued to warn you of such situation. If you want Force Arm
function, any zones left opened after arming will be automatically bypassed and are reported
as zone bypass. The system will resume monitoring the zone once it is closed again for the
duration of that armed period.
●Force Arm Siren Warning:
The siren will continuously sound or squawk to indicate a Force Arm situation. You should
Disarm the panel, check the premises and then Arm again. Continual warnings could mean
there is a problem with a detection device and that particular zone may have to be manually
bypassed.
●Home Instant:
All zones will automatically convert into Instant zones if you Arm in Home mode.
●Home Squawk:
Siren will output two squawks upon arming the system in Home mode and output a single
squawk when the system is disarmed.
●No Arm If Battery Low:
You may not Arm the system if the back-up battery is considered low and A.C power is not
present.
Please consult your installer to enable the above options.
L8_UM1016-v1.0
4
Home1
Total Open (00)
Home1/Rea y 2/3/4
Total Open (00)
Partition A1 A2 A3 A4
Zone 1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
www.ealarm.com.my
System Disarm
LCD/LED Keypad display
Press [ User Code ] + [ 0 ] + [ Partition Select ]
☼ The Armed light will turn off.
☼ The Line light turns on to indicate system dialler performing CMS reporting.
Information
●Disarming the alarm security system will deactivate all the burglary zones of the system.
●Enter the premises through a programmed delay zone and disarm the system before Entry time is
over. If the system is not disarmed by the end of the Entry time, an alarm will trigger.
●During disarmed mode, any violated zones will not enable burglary alarm e cept 24-hour zone.
The 24-hour zones are active irrespective whether the system is under armed or disarmed status.
●Disarming the system also resets triggered siren and strobe light.
●Key-switch input is available on the control panel and can be used to toggle the system to Arm
and Disarm alternately.
●A previously armed system would not Disarm if an illegal User code is entered. You may have up
to 20 tries of continual key entry of the correct 4-digit code in sequence before the keypad goes
into a lock-out period of 10 seconds.
Options to be Programmed by Installer
●Entry Beep:
Keypad beeper will beep continuously for the duration of Entry time.
●Chime:
A beep tone from keypad to indicate a zone is opened during system Disarm state. This
function is temporarily canceled during Arm state.
Please consult your installer to enable the above option.
L8_UM1016-v1.0
5
Rea y1
Total Open (00)
Rea y1/2/3/4
Total Open (00)
Partition A1 A2 A3 A4
Zone 1 2 3 4 5 6 7 8
9 10 11 12 13 14 15 16
www.ealarm.com.my
Bypass Zone
LCD Keypad display
1) Press [ # ] + [ ]
(If Quick Bypass is enabled)
Or
Press [ User Code ] + [ ] + [Partition Select ]
☼ The Line light will blink to indicate Bypass mode.
2) Press [ Zone Number ]
☼ The respective zone light will turn on to indicate the zone is bypassed.
☼ The respective zone light will turn off to indicate the zone is un-bypassed.
3) Press [ ] to e it Bypass mode
☼ The Line light will turn off to indicate e it from Bypass mode.
♪ 3 beeps to indicate e it from Bypass mode.
Information
●Bypass is performed to eliminate burglary zones that are not ready or faulty from activating
burglary alarm. Protection to a bypassed zone is temporarily switched off until the ne t system
arming.
●To un-bypass previously bypassed zones, simply Disarm the system to cancel bypass state of all
zones or enter bypass mode and press the corresponding bypassed zone number to toggle its
bypass state to un-bypass state. After un-bypassing a zone, the bypass indication will be removed
from that particular zone.
●No bypass or un-bypass of zones is allowed during system Arm.
L8_UM1016-v1.0
6
Bypass PtSelect?
P1[] P2[] P3[] P4[]
Bypass Z01-08/Z09-16
– – – – – – – – – – – – – –
www.ealarm.com.my
Review Event Memory
LCD Keypad display
1) Press [ # ] + [ 4 ]
(If Quick Review is enabled)
Or
Press [ User Code ] + [ 4 ] + [ Partition Select ]
☼ The Line light will blink to indicate Review mode.
☼ The Armed light will turn on to indicate events within the latest Arm period.
☼ The Zone light will turn on to indicate any zone triggered.
2) Press [ 4 ] to skip to ne t set of alarm events of previous Arm period.
☼ The Line light will blink to indicate Review mode.
☼ The Armed light will turn on to indicate events within the previous Arm period.
☼ The Zone light will turn on to indicate any zone triggered.
☼ You can press [ 4 ] repeatedly to view all the events.
♪ The panel will emit a long beep, indicating that you've reached end of events.
3) Press [ 0 ] to clear the event memory.
Or
Press [ ] to e it Review mode.
☼ The Line light will turn off to indicate e it from Review mode.
♪ 3 beeps to indicate e it from Review mode.
Information
●In this mode, the keypad can display all faulted zones, AC failure and low battery events,
emergency events (panic, medical, fire) occurring up to 250 events.
●Control panel can record up to 250 events memory.
●If the system memory is full (250 events), the ne t new event will overwrite the earliest event, in a
first in-first out basis.
●Event memory will remain in storage until it is cleared by entering digit ‘0’. Power reset and
defaulting of control panel options back to factory setting will not clear the events memory register
●For LED keypad, light indicator shows the event that occurred.
OFF ☼ ON
Event / LEDs A1/A2/A3/A4 15 16
Arm ☼
Disarm ☼ ☼ ☼
L8_UM1016-v1.0
7
Review PtSelect?
P1[] P2[] P3[] P4[]
Review M000
Event Memory
www.ealarm.com.my
Event/LEDs 9 10 15 16
Panic ☼ ☼
Panic restore ☼ ☼ ☼ ☼
Event/LEDs 11 12 15 16
Me ical ☼ ☼
Me ical restore ☼ ☼ ☼ ☼
Event/LEDs 13 14 15 16
Fire ☼ ☼
Fire restore ☼ ☼ ☼ ☼
Event/LEDs BAT 15 16
Battery fail ☼
Battery restore ☼ ☼ ☼
Event/LEDs AC 15 16
AC fail ☼
AC restore ☼ ☼ ☼
Remarks:
U01 – Master user UXX – User XX U00 – Quick Arm Zone XX – zone XX trigger
L8_UM1016-v1.0
8
www.ealarm.com.my
Walk-Test
LCD Keypad display
1) Press [ User Code ] + [ 5 ]
☼ The Line light will blink to indicate Walk-test mode.
2) Trigger all used zones.
☼ The respective zone light will turn on to indicate the zone is tested.
3) Press [ 1 ] to activate siren (toggle ON/OFF)
[ 2 ] to activate strobe light (toggle ON/OFF)
4) Press [ * ] to e it Walk-test mode
☼ The Line light will turn off to indicate e it from Walk-test mode.
Information
●Walk-test allows all zones, siren and strobe to be tested for functionality. Perform Walk-test
periodically to ensure the system is in a working condition.
●Ensure all zones are closed and there is no one within the premises before conducting Walk-test.
●Walk-test mode is not allowed during system Arm.
System Test
LCD Keypad display
Press [ # ] + [ 3 ]
Or
Press [ User Code ] + [ 3 ] + [ Partition Select ]
☼ The Line light turns on to indicate system dialler performing CMS reporting.
Information
●System test sends a test report to CMS if enabled to do so.
●Please inform your installer to activate this function if you wish to perform this operation.
L8_UM1016-v1.0
9
WTest PtSelect?
P1[] P2[] P3[] P4[]
WalkTest Z01-08/Z09-16
– – – – – – – – – – – – – --
Test PtSelect?
P1[] P2[] P3[] P4[]
www.ealarm.com.my
Panic Alarm
Press [ PANIC ] for 3s
Or
Press [ # ] + [ 1 ] / [ PANIC ]
☼ The Line light turns on to indicate system dialler performing CMS reporting.
☼ The Line light blinks to indicate system dialler performing Personal reporting.
Medical Alarm
Press [ MEDICAL ] for 3s
Or
Press [ # ] + [ 2 ] / [ MEDICAL ]
☼ The Line light turns on to indicate system dialler performing CMS reporting.
☼ The Line light blinks to indicate system dialler performing Personal reporting.
Fire Alarm
Press [ FIRE ] for 3s
Or
Press [ # ] + [ FIRE ]
☼ The Line light turns on to indicate system dialler performing CMS reporting.
☼ The Line light blinks to indicate system dialler performing Personal reporting.
L8_UM1016-v1.0
10
www.ealarm.com.my
Inhaltsverzeichnis
Andere Supa Sicherheitssystem Handbücher
Beliebte Sicherheitssystem Handbücher anderer Marken
EDM
EDM Solution 6+6 Wireless-AE Bedienungsanleitung
Highway Safety Group
Highway Safety Group EA401 Bedienungsanleitung
Siren
Siren LED GSM Bedienungsanleitung
Detection Systems
Detection Systems 7090i Montageanleitung
Se-Kure Controls
Se-Kure Controls MicroMini SK-4841 Bedienungsanleitung
Siemens
Siemens FDM273 Bedienungsanleitung
